LED (該当製品：629 件)

型番	生産状況	仕様書	製品寸法 L×W×H (mm)	色		I_F (mA)	順電圧 Typ(V)	CRI		色度座標		光束 Typ(lm)	放射束 Typ(mW)	光度 Typ(cd)	指向特性 (degree)
型番	生産状況	仕様書	製品寸法 L×W×H (mm)	色		I_F (mA)	順電圧 Typ(V)	Ra Min	R9 Min	X	Y	光束 Typ(lm)	放射束 Typ(mW)	光度 Typ(cd)	指向特性 (degree)
NF2W757H-V2H5			3×3×0.8			65	2.71	80	50	0.3447	0.3553	39			120
NF2W757H-V2H5			3×3×0.8			65	2.71	80	50	0.4338	0.4030	37.5			120
NF2W757H-V2H6 (H6 Series)			3×3×0.8			65	2.71	90	50	0.3447	0.3553	37			120
NF2W757H-V2H6 (H6 Series)			3×3×0.8			65	2.71	90	50	0.4338	0.4030	35.8			120
NF2W757H-V2F1			3×3×0.8			65	2.72	70		0.3447	0.3553	40.3			120
						65	2.72	80	>0	0.3447	0.3553	38.9			120
						65	2.72	70		0.4338	0.4030	38.6			120
						65	2.72	80	>0	0.4338	0.4030	36.2			120
NF2W757H-F1			3×3×0.8			65	2.72	70		0.3447	0.3553	39.6			120
						65	2.72	80	>0	0.3447	0.3553	38.1			120
						65	2.72	90	50	0.3447	0.3553	32.8			120
						65	2.72	70		0.4338	0.4030	38.3			120
						65	2.72	80	>0	0.4338	0.4030	35.8			120
						65	2.72	90	50	0.4338	0.4030	29.8			120
NFSW757H-V2H5			3×3×0.8			65	2.82	80	20	0.3447	0.3553	38.6			120
NFSW757H-V2H5			3×3×0.8			65	2.82	80	20	0.4338	0.4030	37			120
NFSW757H-V2H6 (H6 Series)			3×3×0.8			65	2.82	90	50	0.3447	0.3553	37			120
NFSW757H-V2H6 (H6 Series)			3×3×0.8			65	2.82	90	50	0.4338	0.4030	35.8			120
NFSW757H-V1H6 (H6 Series)			3×3×0.8			65	2.84	90	50	0.3447	0.3553	36.9			120
NFSW757H-V1H6 (H6 Series)			3×3×0.8			65	2.84	90	50	0.4338	0.4030	35.2			120
NFSW757H-V1H6 (Clear White color)			3×3×0.8			65	2.84	90	50	0.3002	0.2950	33.8			120
NFSW757H-V2H6 (Ra≥95, R9>80, TLCI90+)			3×3×0.8			65	2.82	95	80	0.3447	0.3553	32.9			120
NFSW757H-V2H6 (Ra≥95, R9>80, TLCI90+)			3×3×0.8			65	2.82	95	80	0.4338	0.4030	28.5			120
NFSW757H-V1			3×3×0.8			65	2.84	70		0.3447	0.3553	39.5			120
						65	2.84	80	>0	0.3447	0.3553	37.9			120
						65	2.84	90	50	0.3447	0.3553	32.6			120
						65	2.84	70		0.4338	0.4030	37.7			120
						65	2.84	80	>0	0.4338	0.4030	35.6			120
						65	2.84	90	50	0.4338	0.4030	29.8			120
NFSW757H-V1 (Rs060)			3×3×0.8			65	2.84			0.336	0.301	14.9			120
NFSW757H-V1 (Rs060) Hortisolis			3×3×0.8			65	2.84			0.336	0.301				120
NFSW757G-P5H5			3×3×0.65			65	2.89	80	20	0.3447	0.3553	35.6			120
NFSW757G-P5H5			3×3×0.65			65	2.89	80	20	0.4338	0.4030	32.8			120
NFSW757G-P5V1			3×3×0.65			65	2.89	80	>0	0.3447	0.3553	35.3			120
						65	2.89	90	50	0.3447	0.3553	29.6			120
						65	2.89	80	>0	0.4338	0.4030	32.8			120
						65	2.89	90	50	0.4338	0.4030	27.8			120
NFSW757G-P5H6 (H6 Series)			3×3×0.65			65	2.89	90	50	0.3447	0.3553	34.7			120
NFSW757G-P5H6 (H6 Series)			3×3×0.65			65	2.89	90	50	0.4338	0.4030	32.6			120
NFSW757G-P5H6 (TLCI90+)			3×3×0.65			65	2.89	90	50	0.3447	0.3553	33.8			120
NFSW757G-P5H6 (TLCI90+)			3×3×0.65			65	2.89	90	50	0.4338	0.4030	29.7			120
NFSW757G-V3			3×3×0.65			65	2.85	70		0.3447	0.3553	38.4			120
						65	2.85	80	>0	0.3447	0.3553	37			120
						65	2.85	90	50	0.3447	0.3553	31.8			120
						65	2.85	70		0.4338	0.4030	36.6			120
						65	2.85	80	>0	0.4338	0.4030	34.8			120
						65	2.85	90	50	0.4338	0.4030	29			120
NFSW757G-V3 (Rs020)			3×3×0.65			65	2.85			0.336	0.335	22.1			120
NFSW757G-V3 (Rs030)			3×3×0.65			65	2.85			0.3447	0.3553	22.3			120
NFSW757G-V3 (Rs030)			3×3×0.65			65	2.85			0.4338	0.4030	18.9			120
NFSW757G-V3 (Rs060)			3×3×0.65			65	2.85			0.336	0.301	14.5			120
NFSW757G-V3 (Rs060) Hortisolis			3×3×0.65			65	2.85			0.336	0.301	14.5			120
NFSW757G (R95)			3×3×0.65			65	2.88	95		0.3447	0.3553	26			120
NF2W757GR-V5H6 (H6 Series)			3×3×0.65			150	6.2	90	50	0.3447	0.3553	154			120
NF2W757GR-V5H6 (H6 Series)			3×3×0.65			150	6.2	90	50	0.4338	0.4030	145			120
NF2W757GR-V5			3×3×0.65			150	6.2	70		0.3447	0.3553	166			120
						150	6.2	80	>0	0.3447	0.3553	155			120
						150	6.2	70		0.4338	0.4030	160			120
						150	6.2	80	>0	0.4338	0.4030	146			120
NF2W757GR-V4H6 (H6 Series)			3×3×0.65			150	6.2	90	50	0.3447	0.3553	151			120
NF2W757GR-V4H6 (H6 Series)			3×3×0.65			150	6.2	90	50	0.4338	0.4030	143			120
NF2W757GR-V4H6 (Clear White color)			3×3×0.65			150	6.2	90	50	0.3002	0.2950	139			120
NF2W757GR-V4			3×3×0.65			150	6.2	70		0.3447	0.3553	164			120
						150	6.2	80	>0	0.3447	0.3553	153			120
						150	6.2	90	50	0.3447	0.3553	136			120
						150	6.2	70		0.4338	0.4030	158			120
						150	6.2	80	>0	0.4338	0.4030	144			120
						150	6.2	90	50	0.4338	0.4030	126			120
NF2W757GR-V1（R95）			3×3×0.65			150	6.3	95		0.3447	0.3553	110			120
NF2L757GR-V1（R95）			3×3×0.65			150	6.3	95		0.4338	0.4030	100			120
NF2W757GR-V1U4			3×3×0.65			37.5	24.8	70		0.3447	0.3553	129			120
						37.5	24.8	80	>0	0.3447	0.3553	125			120
						37.5	24.8	90	50	0.3447	0.3553	107			120
NF2L757GR-V1U4			3×3×0.65			37.5	24.8	70		0.4338	0.4030	122			120
						37.5	24.8	80	>0	0.4338	0.4030	116			120
						37.5	24.8	90	50	0.4338	0.4030	98			120
NF2W757G-MT (Tunable White. CRI 90)			3×3×0.75			65	2.84	90	50	0.3123	0.3282	27.5			120
NF2W757G-MT (Tunable White. CRI 90)			3×3×0.75			65	2.84	90	50	0.4578	0.4101	26.5			120
NF2W757G-MT (Tunable White. CRI 80)			3×3×0.75			65	2.84	80	>0	0.3123	0.3282	32			120
NF2W757G-MT (Tunable White. CRI 80)			3×3×0.75			65	2.84	80	>0	0.4578	0.4101	31			120
NF2W757G-V3F1			3×3×0.65			65	2.73	70		0.3447	0.3553	38.8			120
						65	2.73	80	>0	0.3447	0.3553	37.3			120
						65	2.73	90	50	0.3447	0.3553	32.3			120
						65	2.73	70		0.4338	0.4030	37.5			120
						65	2.73	80	>0	0.4338	0.4030	35.3			120
						65	2.73	90	50	0.4338	0.4030	29.4			120
NF2W757G-V3F1 (Vitasolis)			3×3×0.65			65	2.73	80	>0	0.3447	0.3553	35.6			120
NF2W757G-V3F1 (Vitasolis)			3×3×0.65			65	2.73	80	>0	0.4338	0.4030				120
NF2W757G-F1 (Optisolis)			3×3×0.65			65	2.9	95	85	0.3447	0.3553	23			120
NF2L757G-F1 (Optisolis)			3×3×0.65			65	2.76	95	80	0.4338	0.4030	24.1			120
NF2W757G-F1 (R95)			3×3×0.65			65	2.76	95		0.3447	0.3553	26.8			120
NF2L757G-F1 (R95)			3×3×0.65			65	2.76	95		0.4338	0.4030	24.1			120
NFSL757G (R95)			3×3×0.65			65	2.88	95		0.4338	0.4030	23.3			120
NFSL757G (Rs075)			3×3×0.65			65	2.88	90		0.4286	0.3919	27.4			120
NF2E757H-F1			3×3×0.8			65	2.74			0.188	0.268	29.5			120
NE2B757G			3×3×0.65			100	2.9			0.133	0.075	8.7			120
NF2E757GR			3×3×0.65			150	6.96			0.095	0.565	83			120
NE2G757G			3×3×0.65			100	3.5			0.17	0.70	33			120
NFSY757G			3×3×0.65			65	2.88			0.4987	0.4946	30.2			120
NE2R757G-P6			3×3×0.65			100	2.13			0.695	0.305	16			120
NSSWT02A-V2			1.2×0.7×0.75			65	2.94	80	>0	0.349	0.361	30.5			>180
NSSWT02A-V2			1.2×0.7×0.75			65	2.94	90		0.349	0.361	25.9			>180
NSSLT02A-V2			1.2×0.7×0.75			65	2.94	80	>0	0.439	0.408	28.5			>180
NSSLT02A-V2			1.2×0.7×0.75			65	2.94	90		0.439	0.408	25			>180
NFSWT03A			1.2×0.7×0.53			65	2.85	80	>0	0.3447	0.3553	32			>180
						65	2.85	90	50	0.3447	0.3553	27.4			>180
						65	2.85	80	>0	0.4338	0.4030	29.8			>180
						65	2.85	90	50	0.4338	0.4030	25.8			>180
NFSWL11A-D6			1.1×1.1×1.24			65	2.8	80	>0	0.3447	0.3553	32.5			>180
						65	2.8	90	50	0.3447	0.3553	28.5			>180
						65	2.8	80	>0	0.4338	0.4030	30.1			>180
						65	2.8	90	50	0.4338	0.4030	26.7			>180
NFSWE11A-V1			1.1×1.1×0.27～0.35			65	2.8	70		0.3447	0.3553	33.3			120
						65	2.8	80	>0	0.3447	0.3553	31			120
						65	2.8	90	50	0.3447	0.3553	26.4			120
						65	2.8	90	80	0.3447	0.3553	25.2			120
						65	2.8	70		0.4338	0.4030	31.7			120
						65	2.8	80	>0	0.4338	0.4030	28.7			120
						65	2.8	90	50	0.4338	0.4030	24.4			120
						65	2.8	90	80	0.4338	0.4030	21.4			120
NFSBE11A-V1L1 (Blue)			1.1×1.1×0.35			65	2.83			0.126	0.078	9.5			120
NFSGE11A-V1 (Green)			1.1×1.1×0.35			65	2.8			0.252	0.651	41.9			120
NFSRE11A-V1 (Brilliant Red)			1.1×1.1×0.35			65	2.8			0.669	0.328	11.5			120
NFSRE11A-V1 (Red)			1.1×1.1×0.35			65	2.8			0.683	0.313	6.5			120
NFSWE11A			1.1×1.1×0.27～0.35			65	2.8	90	80	0.3123	0.3282	25			120
						65	2.8	70		0.3447	0.3553	32.1			120
						65	2.8	80	0	0.3447	0.3553	29.4			120
						65	2.8	90	50	0.3447	0.3553	25.5			120
						65	2.8	70		0.4338	0.4030	30.6			120
						65	2.8	80	0	0.4338	0.4030	27.7			120
						65	2.8	90	50	0.4338	0.4030	23.6			120
						65	2.8	90	80	0.4338	0.4030	20.7			120
NCSWE13A-V1			1.25×1.25×0.27～0.35			350	2.95	80	>0	0.3447	0.3553	146			120
						350	2.95	90	50	0.3447	0.3553	130			120
						350	2.95	90	80	0.3447	0.3553	118			120
						350	2.95	80	>0	0.4338	0.4030	134			120
						350	2.95	90	50	0.4338	0.4030	118			120
						350	2.95	90	80	0.4338	0.4030	100			120
NCSWE17A-V1			1.7×1.7×0.27～0.35			350	2.95	70		0.3447	0.3553	173			120
						350	2.95	80	>0	0.3447	0.3553	163			120
						350	2.95	90	50	0.3447	0.3553	137			120
						350	2.95	90	80	0.3447	0.3553	127			120
						350	2.95	70		0.4338	0.4030	165			120
						350	2.95	80	>0	0.4338	0.4030	147			120
						350	2.95	90	50	0.4338	0.4030	125			120
						350	2.95	90	80	0.4338	0.4030	110			120
NCSWE17A-V1 (Rs060)			1.7×1.7×0.3			350	2.95			0.336	0.301	65			120
NCSWE17A-V1 (Rs060) Hortisolis			1.7×1.7×0.3			350	2.95			0.336	0.301				120
NCSEE17A-V1 (Azure)			1.7×1.7×0.35			350	2.95			0.188	0.268	137			120
NCSEE17A-V1L1 (Bluish Green)			1.7×1.7×0.35			350	2.6			0.095	0.565	126			130
NCSGE17A-V1L1 (Green)			1.7×1.7×0.35			350	2.55			0.168	0.729	175			130
NCSGE17A-V1 (Green)			1.7×1.7×0.35			350	2.95			0.252	0.651	221			120
NCSGE17A-V1 (Lime)			1.7×1.7×0.35			350	2.95			0.4140	0.5430	225			120
NCSAE17A-V1 (Amber)			1.7×1.7×0.35			350	2.95			0.567	0.419	131			120
NCSRE17A-V1 (Brilliant Red)			1.7×1.7×0.35			350	2.95			0.669	0.328	60			120
NCSRE17A-V1 (Red)			1.7×1.7×0.35			350	2.95			0.683	0.313	32			120
NCSRE17A-V1 (Deep Red)			1.7×1.7×0.35			350	2.95			0.691	0.301	24			120
NCSCE17A (Royal Blue)			1.7×1.7×0.35			350	3.0			0.157	0.021	18			130
NCSBE17A (Blue)			1.7×1.7×0.35			350	3.0			0.126	0.078	42			130
NCSEE17A (Azure)			1.7×1.7×0.35			350	3.0			0.188	0.268	132			120
NCSGE17A (Green)			1.7×1.7×0.35			350	3.0			0.252	0.651	208			120
NCSGE17A (Lime)			1.7×1.7×0.35			350	3.0			0.4140	0.5430	212			120
NCSAE17A (Amber)			1.7×1.7×0.35			350	3.0			0.567	0.419	124			120
NCSRE17A (Brilliant Red)			1.7×1.7×0.35			350	3.0			0.669	0.328	58			120
NCSRE17A (Red)			1.7×1.7×0.35			350	3.0			0.683	0.313	31			120
NCSWE17A			1.7×1.7×0.27			350	3.0	70		0.3447	0.3553	165			120
						350	3.0	80	>0	0.3447	0.3553	158			120
						350	3.0	90	50	0.3447	0.3553	133			120
						350	3.0	90	80	0.3447	0.3553	123			120
NCSLE17A			1.7×1.7×0.27~0.35			350	3.0	70		0.4338	0.4030	161			120
						350	3.0	80	>0	0.4338	0.4030	143			120
						350	3.0	90	50	0.4338	0.4030	120			120
						350	3.0	90	80	0.4338	0.4030	107			120
NVSWE21A-V1			2.1×2.1×0.27～0.35			700	2.95	70		0.3447	0.3553	336			120
						700	2.95	80	>0	0.3447	0.3553	317			120
						700	2.95	90	50	0.3447	0.3553	273			120
						700	2.95	90	80	0.3447	0.3553	252			120
						700	2.95	70		0.4338	0.4030	323			120
						700	2.95	80	>0	0.4338	0.4030	292			120
						700	2.95	90	50	0.4338	0.4030	246			120
						700	2.95	90	80	0.4338	0.4030	216			120
NVSLE21A			2.1×2.1×0.27~0.35			700	3.0	70		0.4338	0.4030	314			120
						700	3.0	80	>0	0.4338	0.4030	284			120
						700	3.0	90	50	0.4338	0.4030	229			120
						700	3.0	90	80	0.4338	0.4030	214			120
NVSWE21A			2.1×2.1×0.27			700	3.0	70		0.3447	0.3553	327			120
						700	3.0	80	>0	0.3447	0.3553	307			120
						700	3.0	90	50	0.3447	0.3553	265			120
						700	3.0	90	80	0.3447	0.3553	245			120
NVSW219C-V2			3.5×3.5×0.83			700	2.89	70		0.4338	0.4030				120
						700	2.89	80	>0	0.4338	0.4030	285		97	120
						700	2.89	90	50	0.4338	0.4030	242		84	120
						700	2.89	70		0.3818	0.3797	335		114	120
						700	2.89	80	>0	0.3818	0.3797				120
						700	2.89	90	50	0.3818	0.3797				120
NVSC219GL-L1 (Royal Blue)			3.5×3.5×2.3			700	2.90			0.161	0.026		1484		<150
NVSB219GL-L1 (Blue)			3.5×3.5×2.3			700	2.92			0.133	0.070	80		20	<150
NVSE219GL-L1 (Bluish Green)			3.5×3.5×2.3			700	2.71			0.0861	0.5320	262		65	<150
NVSG219GL-L1 (Green)			3.5×3.5×2.3			700	2.66			0.170	0.730	365		90	<150
NVSA219B-V1 (Amber)			3.5×3.5×2			700	2.98			0.568	0.422	240		66	120
NVSA119B-V1 (Amber)			3.5×3.5×2			700	2.98			0.568	0.422	240		66	120
NVSR219GL-L1 (Red)			3.5×3.5×2.3			700	2.30			0.695	0.305	165		49	120
NVSW219F-V2			3.5×3.5×2.3			700	2.89	90	80	0.3287	0.3417	254		80	120
						700	2.89	70		0.3447	0.3553	365		105	120
						700	2.89	80	0	0.3447	0.3553	330		99	120
						700	2.89	90	50	0.3447	0.3553	280		88	120
						700	2.89	70		0.3818	0.3797	365		105	120
						700	2.89	80	0	0.4338	0.4030	310		93	120
						700	2.89	90	50	0.4338	0.4030	262		83	120
NVSW219F-V2 (TLCI90+)			3.5×3.5×2.3			700	2.89	90	80	0.3287	0.3417	254		80	120
NVSW219F-V1			3.5×3.5×2.3			700	2.96	80	>0	0.3447	0.3553	312		94	120
						700	2.96	90	50	0.3447	0.3553	255		80	120
						700	2.96	80	>0	0.4338	0.4030	295		92	120
						700	2.96	90	50	0.4338	0.4030	239		76	120
NVSW119F-V1			3.5×3.5×2.3			700	2.96	80	>0	0.3447	0.3553	312		94	120
						700	2.96	90	50	0.3447	0.3553	255		80	120
						700	2.96	80	>0	0.4338	0.4030	295		92	120
						700	2.96	90	50	0.4338	0.4030	239		76	120
NVSW219F			3.5×3.5×2.3			700	2.96			0.3123	0.3282	333		100	120
						700	2.96	70		0.3447	0.3553	346		103	120
						700	2.96	70		0.3818	0.3797	341		101	120
						700	2.96			0.4806	0.4141	302		92	120
NVSW119F			3.5×3.5×2.3			700	2.96			0.3123	0.3282	333		100	120
						700	2.96	70		0.3447	0.3553	346		103	120
						700	2.96	70		0.3818	0.3797	341		101	120
						700	2.96			0.4806	0.4141	302		92	120
NVSW219C (For Flashlight)			3.5×3.5×2			700	2.98	70		0.3072	0.3126	295		84	130
NVSW219C			3.5×3.5×2			700	2.98			0.3447	0.3553	325		93	130
						700	2.98	70		0.3447	0.3553	322		92	130
						700	2.98	80	>0	0.3447	0.3553	283		84	130
						700	2.98	90	50	0.3447	0.3553	254		75	130
NVSL219C			3.5×3.5×2			700	2.98	70		0.3818	0.3797	320		91	130
						700	2.98	80	>0	0.4073	0.3917	297		88	130
						700	2.98	90	50	0.4073	0.3917	236		72	130
NVSW119C (For Flashlight)			3.5×3.5×2			700	2.98	70		0.3072	0.3126	295		84	130
NVSW119C			3.5×3.5×2			700	2.98			0.3447	0.3553	325		93	130
						700	2.98	70		0.3447	0.3553	322		92	130
						700	2.98	80	>0	0.3447	0.3553	283		84	130
						700	2.98	90	50	0.3447	0.3553	254		75	130
NVSL119C			3.5×3.5×2			700	2.98	70		0.3818	0.3797	320		91	130
						700	2.98	80	>0	0.4073	0.3917	297		88	130
						700	2.98	90	50	0.4073	0.3917	236		72	130
NVSW309B (For Flashlight)			3.5×3.5×2.35			1050	2.98			0.2999	0.3077	487		130	（130）
NVSW309B			3.5×3.5×2.35			1050	2.98			0.3123	0.3282	494		135	（130）
						1050	2.98	70		0.3447	0.3553	512		146	（130）
						1050	2.98	80	>0	0.3447	0.3553	455		124	（130）
						1050	2.98	70		0.3818	0.3797	507		148	（130）
						1050	2.98	80	>0	0.4338	0.4030	430		128	（130）
NVSW319B (For Flashlight)			3.5×3.5×2.35			1050	2.98			0.2999	0.3077	487		130	（130）
NVSW319B			3.5×3.5×2.35			1050	2.98			0.3123	0.3282	494		135	（130）
						1050	2.98	70		0.3447	0.3553	512		146	（130）
						1050	2.98	80	>0	0.3447	0.3553	455		124	（130）
						1050	2.98	70		0.3818	0.3797	507		148	（130）
						1050	2.98	80	>0	0.4338	0.4030	430		128	（130）
NVSW309A			3.5×3.5×2.1			1050	3.02	70		0.3447	0.3553	480		127	135
						1050	3.02	80	>0	0.3447	0.3553	415		114	135
						1050	3.02	70		0.3818	0.3797	474		126	135
						1050	3.02	80	>0	0.4073	0.3917	415		114	135
NVSW319A			3.5×3.5×2.1			1050	3.02	70		0.3447	0.3553	480		127	135
						1050	3.02	80	>0	0.3447	0.3553	415		114	135
						1050	3.02	70		0.3818	0.3797	474		126	135
						1050	3.02	80	>0	0.4073	0.3917	415		114	135
NVSW519A-V1			3.5×3.5×2.35			1400	2.94	90	80	0.3287	0.3417	507			（130）
						1400	2.94	70		0.3447	0.3553	730			（130）
						1400	2.94	80	0	0.3447	0.3553	655			（130）
						1400	2.94	70		0.3818	0.3797	720			（130）
						1400	2.94	80	0	0.4338	0.4030	624			（130）
						1400	2.94	90	80	0.4338	0.4030	428			（130）
NVSW519A-V1 (Ra≥90, R9≥50, TLCI90+)			3.5×3.5×2.35			1400	2.94	90	50	0.3287	0.3417	559			（130）
NVSW519A-V1 (Ra≥90, R9≥80, TLCI90+)			3.5×3.5×2.35			1400	2.94	90	80	0.3287	0.3417	507			（130）
NVSW519A-V1 (For Flashlight)			3.5×3.5×2.35			1400	2.94	70		0.2999	0.3077	697			（130）
NVSW519A			3.5×3.5×2.35			1400	3.03	90	80	0.3287	0.3417	480			（130）
						1400	3.03	70		0.3447	0.3553	680			（130）
						1400	3.03	80	0	0.3447	0.3553	615			（130）
						1400	3.03	70		0.3818	0.3797	667			（130）
						1400	3.03	80	0	0.4338	0.4030	581			（130）
						1400	3.03	90	80	0.4338	0.4030	407			（130）
NVSW519A (TLCI90+)			3.5×3.5×2.35			1400	3.03	90	80	0.3287	0.3417	480			（130）
NVSW519A (For Flashlight)			3.5×3.5×2.35			1400	3.03	70		0.2999	0.3077	646			(130)
NVSW719AC			3.5×3.5×0.88			1050	6.76	80	>0	0.3487	0.3608	742		247	120
						1050	6.76	90	50	0.3494	0.3649	615		213	120
						1050	6.76	80	>0	0.4393	0.4078	705		238	120
						1050	6.76	90	50	0.4373	0.4109	563		197	120
NVSW719AC (For Flashlight)			3.5×3.5×0.88			1050	6.76			0.2999	0.3077	815		263	120
NCSC219B-V1 (Royal Blue)			3.5×3.5×2			350	2.93			0.161	0.026		680		125
NCSC119B-V1 (Royal Blue)			3.5×3.5×2			350	2.93			0.161	0.026		680		125
NCSB219B-V1 (Blue)			3.5×3.5×2			350	3.0			0.133	0.070	40		11.7	125
NCSB119B-V1 (Blue)			3.5×3.5×2			350	3.0			0.133	0.070	40		11.7	125
NCSE219B-V1 (Bluish Green)			3.5×3.5×2			350	3.32			0.095	0.565	108		28	135
NCSE119B-V1 (Bluish Green)			3.5×3.5×2			350	3.32			0.095	0.565	108		28	135
NCSG219B-V1 (Green)			3.5×3.5×2			350	3.38			0.168	0.729	139		35	145
NCSG119B-V1 (Green)			3.5×3.5×2			350	3.38			0.168	0.729	139		35	145
NCSA219B-V1 (Amber)			3.5×3.5×2			350	2.93			0.568	0.422	118		35	120
NCSA119B-V1 (Amber)			3.5×3.5×2			350	2.93			0.568	0.422	118		35	120
NCSR219B-V1 (Red)			3.5×3.5×2			350	2.2			0.695	0.305	75		19.4	130
NCSR119B-V1 (Red)			3.5×3.5×2			350	2.2			0.695	0.305	75		19.4	130
NCSB119			3.5×3.5×2			350	3.3			0.133	0.075	32		11	120
NCSE119A			3.5×3.5×2			350	3.5			0.095	0.565	98		31	120
NCSG119			3.5×3.5×2			350	3.6			0.189	0.718	128		41	120
NCSA119			3.5×3.5×2			350	3.3			0.56	0.43	80		27	120
NCSR119			3.5×3.5×2.0			350	2.3			0.700	0.299	60		19	120
NWSL229A			4.0×4.0×2.3			1400	3.0	70		0.3818	0.3797	631		162	135
NWSL229A			4.0×4.0×2.3			1400	3.0	80	>0	0.3818	0.3797	574		150	135
NV4WB35AM			3.65×3.65×0.73, 0.76			1400	5.93	90	80	0.3287	0.3417	930		311	120
						1400	5.93	70		0.3447	0.3553	1236		395	120
						1400	5.93	80	0	0.3447	0.3553	1150		379	120
						1400	5.93	70		0.3818	0.3797	1210		391	120
						1400	5.93	80	0	0.4338	0.4030	1040		344	120
						1400	5.93	90	50	0.4338	0.4030	900		300	120
						1400	5.93	90	80	0.4338	0.4030	760		270	120
NV4WB35AM (TLCI90+)			3.65×3.65×0.73			1400	5.93	90	80	0.3287	0.3417	930		311	120
NV4WB35AM (For Flashlight)			3.65×3.65×0.73			1400	5.93			0.2973	0.3176	1275		406	120
NV4WB35AR			3.65×3.65×0.73~0.76			700	11.86	90	80	0.3287	0.3417	930		311	120
						700	11.86	70		0.3447	0.3553	1236		395	120
						700	11.86	80	0	0.3447	0.3553	1150		379	120
						700	11.86	70		0.3818	0.3797	1210		391	120
						700	11.86	80	0	0.4338	0.4030	1040		344	120
						700	11.86	90	50	0.4338	0.4030	900		300	120
						700	11.86	90	80	0.4338	0.4030	760		270	120
NV4WB35AR (TLCI90+)			3.65×3.65×0.73			700	11.86	90	80	0.3287	0.3417	930		311	120
NV4WB35AR (For Flashlight)			3.65×3.65×0.73			700	11.86			0.2973	0.3176	1275		406	120
NV4W144AM-V1			5×5×3.15			1400	5.75	90	80	0.3307	0.3434	1080		280	130
						1400	5.75	70		0.3447	0.3553	1450		360	130
						1400	5.75	80	0	0.3447	0.3553	1310		335	130
						1400	5.75	90	50	0.3447	0.3553	1125		300	130
						1400	5.75	70		0.3818	0.3797	1450		360	130
						1400	5.75	80	0	0.4338	0.4030	1225		330	130
						1400	5.75	90	50	0.4338	0.4030	995		270	130
NV4W144AR-V1			5×5×3.15			700	11.5	90	80	0.3307	0.3434	1080		280	130
						700	11.5	70		0.3447	0.3553	1450		360	130
						700	11.5	80	0	0.3447	0.3553	1310		335	130
						700	11.5	90	50	0.3447	0.3553	1125		300	130
						700	11.5	70		0.3818	0.3797	1450		360	130
						700	11.5	80	0	0.4338	0.4030	1225		330	130
						700	11.5	90	50	0.4338	0.4030	995		270	130
NV4W144AM			5×5×3.15			1400	5.97	70		0.3447	0.3553	1342		351	120
						1400	5.97	80	>0	0.3447	0.3553	1202		330	120
						1400	5.97	90	50	0.3447	0.3553	1030		278	120
						1400	5.97	90	80	0.3307	0.3434	970		269	120
NV4L144AM			5×5×3.15			1400	5.97	70		0.3818	0.3797	1321		355	120
						1400	5.97	80	>0	0.3818	0.3797	1183		337	120
						1400	5.97	90	50	0.3818	0.3797	985		280	120
NV4W144AR			5×5×3.15			700	11.9	70		0.3447	0.3553	1342		351	120
						700	11.9	80	>0	0.3447	0.3553	1202		330	120
						700	11.9	90	50	0.3447	0.3553	1030		278	120
						700	11.9	90	80	0.3307	0.3434	970		269	120
NV4L144AR			5×5×3.15			700	11.9	70		0.3818	0.3797	1321		355	120
						700	11.9	80	>0	0.3818	0.3797	1183		337	120
						700	11.9	90	50	0.3818	0.3797	985		280	120
NV9W149AM			7×7×3.1			2100	9.0	80	>0	0.3307	0.3434	2720			140
						2100	9.0	90	50	0.3307	0.3434	2490			140
						2100	9.0	70		0.3447	0.3553	2900			140
						2100	9.0	80	>0	0.4073	0.3917	2600			140
						2100	9.0	90	50	0.4338	0.4030	2075			140
NFMW488AR-V1			6.5×5.8×0.8			200	44.8	90	50	0.3447	0.3553	1186			120
						200	44.8	70		0.3447	0.3553	1416			120
						200	44.8	80	0	0.3447	0.3553	1325			120
						200	44.8	90	50	0.4338	0.4030	1091			120
						200	44.8	70		0.4338	0.4030	1390			120
						200	44.8	80	0	0.4338	0.4030	1265			120
NFMW488AR			6.5×5.8×0.8			200	45.9	70		0.3447	0.3553	1320			120
						200	45.9	80	>0	0.3447	0.3553	1240			120
						200	45.9	90	50	0.3447	0.3553	1110			120
						200	45.9	70		0.4338	0.4030	1280			120
						200	45.9	80	>0	0.4338	0.4030	1190			120
						200	45.9	90	50	0.4338	0.4030	1030			120
NFMW486AR			6.5×5.8×0.8			200	39.3	70		0.3447	0.3553	1130			120
						200	39.3	80	>0	0.3447	0.3553	1060			120
						200	39.3	90	50	0.3447	0.3553	960			120
						200	39.3	70		0.4338	0.4030	1100			120
						200	39.3	80	>0	0.4338	0.4030	1030			120
						200	39.3	90	50	0.4338	0.4030	890			120
NFMW484AR			6.5×5.8×0.8			200	32.8	70		0.3447	0.3553	970			120
						200	32.8	80	>0	0.3447	0.3553	900			120
						200	32.8	90	50	0.3447	0.3553	800			120
						200	32.8	70		0.4338	0.4030	950			120
						200	32.8	80	>0	0.4338	0.4030	870			120
						200	32.8	90	50	0.4338	0.4030	750			120
NFMW481AR			6.5×5.8×0.8			200	22.9	70		0.3447	0.3553	690			120
						200	22.9	80	>0	0.3447	0.3553	640			120
						200	22.9	90	50	0.3447	0.3553	560			120
						200	22.9	70		0.4338	0.4030	670			120
						200	22.9	80	>0	0.4338	0.4030	610			120
						200	22.9	90	50	0.4338	0.4030	530			120
NF4W585AM-V1			4×3.6×2.05			100	5.49	70		0.3447	0.3553	120.5			140/140
						100	5.49	80	>0	0.3447	0.3553	111.7			140/140
						100	5.49	70		0.4338	0.4030	115.1			140/140
						100	5.49	80	>0	0.4338	0.4030	102.9			140/140
NF3W585AR-V1			4×3.6×2.05			50	8.36	70		0.3447	0.3553	91.5			135/135
						50	8.36	80	>0	0.3447	0.3553	84.9			135/135
						50	8.36	70		0.4338	0.4030	87.4			135/135
						50	8.36	80	>0	0.4338	0.4030	78.7			135/135
NF3W585AR			4×3.6×2.05			50	8.44	70		0.3447	0.3553	87.5			135/135
						50	8.44	80	>0	0.3447	0.3553	82.4			135/135
						50	8.44	70		0.4338	0.4030	83.9			135/135
						50	8.44	80	>0	0.4338	0.4030	76.3			135/135
NF2W585AR-P8 (Disinfection)			4×3.6×2.05			75	6.21	80	>0	0.4073	0.3917	53			125/115
						75	6.21	80	>0	0.3447	0.3553	53			125/115
						75	6.21	80	>0	0.3818	0.3797	53			125/115
NF2W585AR			4×3.6×2.05			75	5.73	70		0.3447	0.3553	87.8			135/125
						75	5.73	80	>0	0.3447	0.3553	82.7			135/125
						75	5.73	70		0.4338	0.4030	85.2			135/125
						75	5.73	80	>0	0.4338	0.4030	76.6			135/125
NF2W385AR-V3			4×3.6×2.05			75	5.73	70		0.3447	0.3553	87			138/118
						75	5.73	80	>0	0.3447	0.3553	79.8			138/118
						75	5.73	90	50	0.3447	0.3553	69.5			138/118
						75	5.73	70		0.4338	0.4030	84.5			138/118
						75	5.73	80	>0	0.4338	0.4030	76.5			138/118
						75	5.73	90	50	0.4338	0.4030	63.8			138/118
NF2W385AR-V2			4×3.6×2.05			200	6.45	70		0.3447	0.3553	205			115/130
						200	6.45	80	>0	0.3447	0.3553	193			115/130
						200	6.45	90	50	0.3447	0.3553	168			115/130
						200	6.45	70		0.4338	0.4030	199			115/130
						200	6.45	80	>0	0.4338	0.4030	181			115/130
						200	6.45	90	50	0.4338	0.4030	153			115/130
NFCWT012B-V4H6 (H6 Series)			15×12×2			70	34.1	90	50	0.3450	0.3602	440			120
NFCWT012B-V4H6 (H6 Series)			15×12×2			70	34.1	90	50	0.4289	0.4026	430			120
NFCWS024B-V5			15×12×2			135	33.6	70		0.3447	0.3553	910			120
						135	33.6	80	>0	0.3447	0.3553	860			120
						135	33.6	90	50	0.3447	0.3553	770			120
						135	33.6	95	80	0.3447	0.3553	650			120
						135	33.6	70		0.4338	0.4030	880			120
						135	33.6	80	>0	0.4338	0.4030	810			120
						135	33.6	90	50	0.4338	0.4030	730			120
						135	33.6	95	80	0.4338	0.4030	600			120
NFCWS024B-V5 (Rs020)			15×12×2			135	33.6			0.3360	0.3335	460			120
NFCWS024B-V5 (Rs020)			15×12×2			135	33.6			0.3882	0.3329	380			120
NFCWS024B-V5 (Rs030)			15×12×2			135	33.6			0.3447	0.3553	550			120
NFCWS024B-V5 (Rs030)			15×12×2			135	33.6			0.4338	0.4030	460			120
NFCWS024B-V5 (Rs060)			15×12×2			135	33.6			0.336	0.301	330			120
NFCWS024B-V5 (Rs060) Hortisolis			15×12×2			135	33.6			0.336	0.301				120
NFCWS024B-V5 (Rs075)			15×12×2			135	33.6	90		0.4286	0.3919	690			120
NFCWS024B-V4H6 (H6 Series)			15×12×2			135	34.0	90	50	0.3450	0.3602	830			120
NFCWS024B-V4H6 (H6 Series)			15×12×2			135	34.0	90	50	0.4289	0.4026	800			120
NTCWS024B-V4			15×12×2			135	34.9	70		0.3447	0.3553	860			120
						135	34.9	80	>0	0.3447	0.3553	815			120
						135	34.9	90	50	0.3447	0.3553	720			120
						135	34.9	95	80	0.3447	0.3553	615			120
						135	34.9	70		0.4338	0.4030	830			120
						135	34.9	80	>0	0.4338	0.4030	770			120
						135	34.9	90	50	0.4338	0.4030	675			120
						135	34.9	95	80	0.4338	0.4030	560			120
NTCWS024B-V3 (Optisolis)			15×12×2			135	34.9	95	80	0.4338	0.4030	515			120
NTCWS024B-V3 (Rs020)			15×12×2			135	34.9			0.3360	0.3335	450			120
NTCWS024B-V3 (Rs020)			15×12×2			135	34.9			0.3882	0.3329	370			120
NTCWS024B-V3 (Rs030)			15×12×2			135	34.9			0.3447	0.3553	520			120
NTCWS024B-V3 (Rs030)			15×12×2			135	34.9			0.4338	0.4030	430			120
NTCWS024B-V3 (Rs075)			15×12×2			135	34.9	90		0.4286	0.3919	655			120
NFCWS024B-V3 (Optisolis)			15×12×2			120	35.8	94	70	0.3447	0.3553	455			120
NFCWL036B-V5			19×16×2			260	34.4	70		0.3447	0.3553	1750			120
						260	34.4	80	>0	0.3447	0.3553	1660			120
						260	34.4	90	50	0.3447	0.3553	1500			120
						260	34.4	95	80	0.3447	0.3553	1270			120
						260	34.4	70		0.4338	0.4030	1690			120
						260	34.4	80	>0	0.4338	0.4030	1570			120
						260	34.4	90	50	0.4338	0.4030	1400			120
						260	34.4	95	80	0.4338	0.4030	1160			120
NFCWL036B-V5 (Rs020)			19×16×2			260	34.4			0.3360	0.3335	900			120
NFCWL036B-V5 (Rs020)			19×16×2			260	34.4			0.3882	0.3329	740			120
NFCWL036B-V5 (Rs030)			19×16×2			260	34.4			0.3447	0.3553	1050			120
NFCWL036B-V5 (Rs030)			19×16×2			260	34.4			0.4338	0.4030	890			120
NFCWL036B-V5 (Rs060)			19×16×2			260	34.4			0.336	0.301	650			120
NFCWL036B-V5 (Rs060) Hortisolis			19×16×2			260	34.4			0.336	0.301				120
NFCWL036B-V5 (Rs075)			19×16×2			260	34.4	90		0.4286	0.3919	1330			120
NFCWL036B-V4H6 (H6 Series)			19×16×2			260	34.6	90	50	0.3450	0.3602	1620			120
NFCWL036B-V4H6 (H6 Series)			19×16×2			260	34.6	90	50	0.4289	0.4026	1570			120
NFCWL036B-V4			19×16×2			260	34.6	70		0.3447	0.3553	1700			120
						260	34.6	80	>0	0.3447	0.3553	1610			120
						260	34.6	90	50	0.3447	0.3553	1430			120
						260	34.6	95	80	0.3447	0.3553	1210			120
						260	34.6	70		0.4338	0.4030	1640			120
						260	34.6	80	>0	0.4338	0.4030	1520			120
						260	34.6	90	50	0.4338	0.4030	1340			120
						260	34.6	95	80	0.4338	0.4030	1110			120
NFCWL036B-V3			19×16×2			260	34.6	70		0.3447	0.3553	1690			120
						260	34.6	80	>0	0.3447	0.3553	1590			120
						260	34.6	90	50	0.3447	0.3553	1400			120
						260	34.6	95	80	0.3447	0.3553	1210			120
						260	34.6	70		0.4338	0.4030	1640			120
						260	34.6	80	>0	0.4338	0.4030	1510			120
						260	34.6	90	50	0.4338	0.4030	1300			120
						260	34.6	95	80	0.4338	0.4030	1110			120
NFCWL036B-V3 (Optisolis, White)			19×16×2			180	35.8	94	70	0.3447	0.3553	710			120
NFCWL036B-V3 (Optisolis, Warm White)			19×16×2			260	34.6	95	80	0.4338	0.4030	1030			120
NFCWL036B-V3 (Rs020)			19×16×2			260	34.6			0.3360	0.3335	900			120
NFCWL036B-V3 (Rs020)			19×16×2			260	34.6			0.3882	0.3329	740			120
NFCWL036B-V3 (Rs030)			19×16×2			260	34.6			0.3447	0.3553	1030			120
NFCWL036B-V3 (Rs030)			19×16×2			260	34.6			0.4338	0.4030	850			120
NFCWL036B-V3 (Rs075)			19×16×2			260	34.6	90		0.4286	0.3919	1300			120
NFCWL048B-V4H6 (H6 Series)			19×16×2			360	34.7	90	50	0.3450	0.3602	2260			120
NFCWL048B-V4H6 (H6 Series)			19×16×2			360	34.7	90	50	0.4289	0.4026	2190			120
NFCWL060B-V5			19×16×2			460	34.5	70		0.3447	0.3553	3120			120
						460	34.5	80	>0	0.3447	0.3553	2930			120
						460	34.5	90	50	0.3447	0.3553	2640			120
						460	34.5	95	80	0.3447	0.3553	2260			120
						460	34.5	70		0.4338	0.4030	3010			120
						460	34.5	80	>0	0.4338	0.4030	2780			120
						460	34.5	90	50	0.4338	0.4030	2480			120
						460	34.5	95	80	0.4338	0.4030	2070			120
NFCWL060B-V5 (Rs020)			19×16×2			460	34.5			0.3360	0.3335	1600			120
NFCWL060B-V5 (Rs020)			19×16×2			460	34.5			0.3882	0.3329	1320			120
NFCWL060B-V5 (Rs030)			19×16×2			460	34.5			0.3447	0.3553	1870			120
NFCWL060B-V5 (Rs030)			19×16×2			460	34.5			0.4338	0.4030	1580			120
NFCWL060B-V5 (Rs060)			19×16×2			460	34.5			0.336	0.301	1150			120
NFCWL060B-V5 (Rs060) Hortisolis			19×16×2			460	34.5			0.336	0.301				120
NFCWL060B-V5 (Rs075)			19×16×2			460	34.5	90		0.4286	0.3919	2350			120
NFCWL060B-V4H6 (H6 Series)			19×16×2			460	34.8	90	50	0.3450	0.3602	2870			120
NFCWL060B-V4H6 (H6 Series)			19×16×2			460	34.8	90	50	0.4289	0.4026	2780			120
NFCWL060B-V4			19×16×2			460	34.8	70		0.3447	0.3553	3020			120
						460	34.8	80	>0	0.3447	0.3553	2840			120
						460	34.8	90	50	0.3447	0.3553	2520			120
						460	34.8	95	80	0.3447	0.3553	2160			120
						460	34.8	70		0.4338	0.4030	2920			120
						460	34.8	80	>0	0.4338	0.4030	2690			120
						460	34.8	90	50	0.4338	0.4030	2370			120
						460	34.8	95	80	0.4338	0.4030	1980			120
NFCWL060B-V3			19×16×2			460	34.8	70		0.3447	0.3553	3000			120
						460	34.8	80	>0	0.3447	0.3553	2830			120
						460	34.8	90	50	0.3447	0.3553	2490			120
						460	34.8	95	80	0.3447	0.3553	2160			120
						460	34.8	70		0.4338	0.4030	2920			120
						460	34.8	80	>0	0.4338	0.4030	2680			120
						460	34.8	90	50	0.4338	0.4030	2310			120
						460	34.8	95	80	0.4338	0.4030	1980			120
NFCWL060B-V3 (Optisolis, White)			19×16×2			300	35.8	94	70	0.3447	0.3553	1200			120
NFCWL060B-V3 (Optisolis, Warm White)			19×16×2			460	34.8	95	80						120
NFCWL060B-V3 (Rs020)			19×16×2			460	34.8			0.3360	0.3335	1600			120
NFCWL060B-V3 (Rs020)			19×16×2			460	34.8			0.3882	0.3329	1320			120
NFCWL060B-V3 (Rs030)			19×16×2			460	34.8			0.3447	0.3553	1840			120
NFCWL060B-V3 (Rs030)			19×16×2			460	34.8			0.4338	0.4030	1530			120
NFCWL060B-V3 (Rs075)			19×16×2			460	34.8	90		0.4286	0.3919	2320			120
NFCWJ108B-V5			24×19×2			860	34.6	70		0.3447	0.3553	5740			120
						860	34.6	80	>0	0.3447	0.3553	5420			120
						860	34.6	90	50	0.3447	0.3553	4890			120
						860	34.6	95	80	0.3447	0.3553	4180			120
						860	34.6	70		0.4338	0.4030	5570			120
						860	34.6	80	>0	0.4338	0.4030	5120			120
						860	34.6	90	50	0.4338	0.4030	4580			120
						860	34.6	95	80	0.4338	0.4030	3840			120
NFCWJ108B-V5 (Rs020)			24×19×2			860	34.6			0.3360	0.3335	2960			120
NFCWJ108B-V5 (Rs020)			24×19×2			860	34.6			0.3882	0.3329	2440			120
NFCWJ108B-V5 (Rs030)			24×19×2			860	34.6			0.3447	0.3553	3450			120
NFCWJ108B-V5 (Rs030)			24×19×2			860	34.6			0.4338	0.4030	2910			120
NFCWJ108B-V5 (Rs060)			24×19×2			860	34.6			0.336	0.301	2120			120
NFCWJ108B-V5 (Rs060) Hortisolis			24×19×2			860	34.6			0.336	0.301				120
NFCWJ108B-V5 (Rs075)			24×19×2			860	34.6	90		0.4286	0.3919	4340			120
NFCWJ108B-V4H6 (H6 Series)			24×19×2			860	34.9	90	50	0.3450	0.3602	5330			120
NFCWJ108B-V4H6 (H6 Series)			24×19×2			860	34.9	90	50	0.4289	0.4026	5170			120
NFCWJ108B-V4			24×19×2			860	34.9	70		0.3447	0.3553	5560			120
						860	34.9	80	>0	0.3447	0.3553	5250			120
						860	34.9	90	50	0.3447	0.3553	4660			120
						860	34.9	95	80	0.3447	0.3553	3990			120
						860	34.9	70		0.4338	0.4030	5390			120
						860	34.9	80	>0	0.4338	0.4030	4960			120
						860	34.9	90	50	0.4338	0.4030	4370			120
						860	34.9	95	80	0.4338	0.4030	3660			120
NFCWJ108B-V3			24×19×2			860	34.9	70		0.3447	0.3553	5560			120
						860	34.9	80	>0	0.3447	0.3553	5230			120
						860	34.9	90	50	0.3447	0.3553	4600			120
						860	34.9	95	80	0.3447	0.3553	3990			120
						860	34.9	70		0.4338	0.4030	5390			120
						860	34.9	80	>0	0.4338	0.4030	4960			120
						860	34.9	90	50	0.4338	0.4030	4270			120
						860	34.9	95	80	0.4338	0.4030	3660			120
NFCWJ108B-V3 (Optisolis, White)			24×19×2			540	35.8	94	70	0.3447	0.3553	2150			120
NFCWJ108B-V3 (Optisolis, Warm White)			24×19×2			860	34.9	95	80	0.4338	0.4030	3380			120
NFCWJ108B-V3 (Rs020)			24×19×2			860	34.9			0.3360	0.3335	2960			120
NFCWJ108B-V3 (Rs020)			24×19×2			860	34.9			0.3882	0.3329	2440			120
NFCWJ108B-V3 (Rs030)			24×19×2			860	34.9			0.3447	0.3553	3410			120
NFCWJ108B-V3 (Rs030)			24×19×2			860	34.9			0.4338	0.4030	2820			120
NFCWJ108B-V3 (Rs075)			24×19×2			860	34.9	90		0.4286	0.3919	4290			120
NFDWJ130B-V5			24×19×2			1150	38.3	70		0.3447	0.3553	8150			120
						1150	38.3	80	>0	0.3447	0.3553	7710			120
						1150	38.3	90	50	0.3447	0.3553	6950			120
						1150	38.3	95	80	0.3447	0.3553	5940			120
						1150	38.3	70		0.4338	0.4030	7920			120
						1150	38.3	80	>0	0.4338	0.4030	7280			120
						1150	38.3	90	50	0.4338	0.4030	6520			120
						1150	38.3	95	80	0.4338	0.4030	5460			120
NFDWJ130B-V5 (Rs020)			24×19×2			1150	38.3			0.3360	0.3335	4200			120
NFDWJ130B-V5 (Rs020)			24×19×2			1150	38.3			0.3882	0.3329	3470			120
NFDWJ130B-V5 (Rs030)			24×19×2			1150	38.3			0.3447	0.3553	4910			120
NFDWJ130B-V5 (Rs030)			24×19×2			1150	38.3			0.4338	0.4030	4140			120
NFDWJ130B-V5 (Rs060)			24×19×2			1150	38.3			0.336	0.301	3020			120
NFDWJ130B-V5 (Rs060) Hortisolis			24×19×2			1150	38.3			0.336	0.301				120
NFDWJ130B-V5 (Rs075)			24×19×2			1150	38.3	90		0.4286	0.3919	6170			120
NFDWJ130B-V4H6 (H6 Series)			24×19×2			1150	38.5	90	50	0.3450	0.3602	7400			120
NFDWJ130B-V4H6 (H6 Series)			24×19×2			1150	38.5	90	50	0.4289	0.4026	7180			120
NFDWJ130B-V4			24×19×2			1150	38.5	70		0.3447	0.3553	7890			120
						1150	38.5	80	>0	0.3447	0.3553	7460			120
						1150	38.5	90	50	0.3447	0.3553	6620			120
						1150	38.5	95	80	0.3447	0.3553	5660			120
						1150	38.5	70		0.4338	0.4030	7660			120
						1150	38.5	80	>0	0.4338	0.4030	7050			120
						1150	38.5	90	50	0.4338	0.4030	6210			120
						1150	38.5	95	80	0.4338	0.4030	5200			120
NFDWJ130B-V3			24×19×2			1150	38.5	70		0.3447	0.3553	7890			120
						1150	38.5	80	>0	0.3447	0.3553	7430			120
						1150	38.5	90	50	0.3447	0.3553	6540			120
						1150	38.5	95	80	0.3447	0.3553	5660			120
						1150	38.5	70		0.4338	0.4030	7660			120
						1150	38.5	80	>0	0.4338	0.4030	7050			120
						1150	38.5	90	50	0.4338	0.4030	6070			120
						1150	38.5	95	80	0.4338	0.4030	5200			120
NFDWJ130B-V3 (Optisolis, White)			24×19×2			600	37.4	94	70	0.3447	0.3553	2560			120
NFDWJ130B-V3 (Optisolis, Warm White)			24×19×2			1150	38.5	95	80	0.4338	0.4030	4810			120
NFDWJ130B-V3 (Rs020)			24×19×2			1150	38.5			0.3360	0.3335	4200			120
NFDWJ130B-V3 (Rs020)			24×19×2			1150	38.5			0.3882	0.3329	3470			120
NFDWJ130B-V3 (Rs030)			24×19×2			1150	38.5			0.3447	0.3553	4850			120
NFDWJ130B-V3 (Rs030)			24×19×2			1150	38.5			0.4338	0.4030	4010			120
NFDWJ130B-V3 (Rs075)			24×19×2			1150	38.5	90		0.4286	0.3919	6090			120
NFEWH306B-V2			38×38×2			1400	51.9	70		0.3447	0.3553	13120			120
						1400	51.9	80	>0	0.3447	0.3553	12300			120
						1400	51.9	90	50	0.3447	0.3553	11040			120
						1400	51.9	95		0.3447	0.3553	9430			120
						1400	51.9	70		0.4338	0.4030	12500			120
						1400	51.9	80	>0	0.4338	0.4030	11640			120
						1400	51.9	90	50	0.4338	0.4030	10240			120
						1400	51.9	95		0.4338	0.4030	8320			120
NFEWH306B-V2 (Rs020)			38×38×2			1400	51.9			0.3360	0.3335	6960			120
NFEWH306B-V2 (Rs020)			38×38×2			1400	51.9			0.3882	0.3329	5740			120
NFEWH306B-V2 (Rs030)			38×38×2			1400	51.9			0.3447	0.3553	8030			120
NFEWH306B-V2 (Rs030)			38×38×2			1400	51.9			0.4338	0.4030	6640			120
NFEWH306B-V2 (Rs075)			38×38×2			1400	51.9	90		0.4286	0.3919	10090			120
NJNWS012Z-V1MT (Tunable White)			15×12×2			280	17.9	90	50	0.3447	0.3553	630			120
NJNWS012Z-V1MT (Tunable White)			15×12×2			280	17.9	90	50	0.4540	0.4000	460			120
NVCWJ024Z-V1MT (Tunable White)			24×19×2			600	35.4	90	50	0.3447	0.3553	2730			120
NVCWJ024Z-V1MT (Tunable White)			24×19×2			600	35.4	90	50	0.4540	0.4000	2080			120
NJCWL024Z-V1MT (Tunable White)			19×16×2			250	35.8	90	50	0.3447	0.3553	1120			120
NJCWL024Z-V1MT (Tunable White)			19×16×2			250	35.8	90	50	0.4540	0.4000	850			120
NVNWS007Z-V1			15×12×2			580	20.6	70		0.3447	0.3553	1870			120
						580	20.6	80	>0	0.3447	0.3553	1750			120
						580	20.6	90	50	0.3447	0.3553	1580			120
						580	20.6	95	80	0.3447	0.3553	1400			120
						580	20.6	70		0.4338	0.4030	1740			120
						580	20.6	80	>0	0.4338	0.4030	1610			120
						580	20.6	90	50	0.4338	0.4030	1410			120
						580	20.6	95	80	0.4338	0.4030	1240			120
NVNWS007Z-V1 (Rs020)			15×12×2			580	20.6			0.3360	0.3335	930			120
NVNWS007Z-V1 (Rs020)			15×12×2			580	20.6			0.3882	0.3329	750			120
NVNWS007Z-V1 (Rs030)			15×12×2			580	20.6			0.3447	0.3553	1080			120
NVNWS007Z-V1 (Rs030)			15×12×2			580	20.6			0.4338	0.4030	860			120
NVNWS007Z-V1 (Rs075)			15×12×2			580	20.6	90		0.4286	0.3919	1470			120
NJCWS024Z-V1			15×12×2			500	36.0	70		0.3447	0.3553	2580			120
						500	36.0	80	>0	0.3447	0.3553	2410			120
						500	36.0	90	50	0.3447	0.3553	2180			120
						500	36.0	95	80	0.3447	0.3553	1930			120
						500	36.0	70		0.4338	0.4030	2410			120
						500	36.0	80	>0	0.4338	0.4030	2210			120
						500	36.0	90	50	0.4338	0.4030	1940			120
						500	36.0	95	80	0.4338	0.4030	1710			120
NJCWS024Z-V1 (Rs020)			15×12×2			500	36.0			0.3360	0.3335	1290			120
NJCWS024Z-V1 (Rs020)			15×12×2			500	36.0			0.3882	0.3329	1030			120
NJCWS024Z-V1 (Rs030)			15×12×2			500	36.0			0.3447	0.3553	1480			120
NJCWS024Z-V1 (Rs030)			15×12×2			500	36.0			0.4338	0.4030	1190			120
NJCWS024Z-V1 (Rs075)			15×12×2			500	36.0	90		0.4286	0.3919	2030			120
NVEWL016Z-V1			19×16×2			600	47.0	70		0.3447	0.3553	4370			120
						600	47.0	80	>0	0.3447	0.3553	4080			120
						600	47.0	90	50	0.3447	0.3553	3700			120
						600	47.0	95	80	0.3447	0.3553	3260			120
						600	47.0	70		0.4338	0.4030	4080			120
						600	47.0	80	>0	0.4338	0.4030	3750			120
						600	47.0	90	50	0.4338	0.4030	3290			120
						600	47.0	95	80	0.4338	0.4030	2900			120
NVEWL016Z-V1 (Rs020)			19×16×2			600	47.0			0.3360	0.3335	2180			120
NVEWL016Z-V1 (Rs020)			19×16×2			600	47.0			0.3882	0.3329	1750			120
NVEWL016Z-V1 (Rs030)			19×16×2			600	47.0			0.3447	0.3553	2520			120
NVEWL016Z-V1 (Rs030)			19×16×2			600	47.0			0.4338	0.4030	2020			120
NVEWL016Z-V1 (Rs075)			19×16×2			600	47.0	90		0.4286	0.3919	3430			120
NVCWL024Z-V1			19×16×2			1200	35.5	70		0.3447	0.3553	6660			120
						1200	35.5	80	>0	0.3447	0.3553	6220			120
						1200	35.5	90	50	0.3447	0.3553	5620			120
						1200	35.5	95	80	0.3447	0.3553	4980			120
						1200	35.5	70		0.4338	0.4030	6210			120
						1200	35.5	80	>0	0.4338	0.4030	5720			120
						1200	35.5	90	50	0.4338	0.4030	5010			120
						1200	35.5	95	80	0.4338	0.4030	4420			120
NVCWL024Z-V1 (Rs020)			19×16×2			1200	35.5			0.3360	0.3335	3330			120
NVCWL024Z-V1 (Rs020)			19×16×2			1200	35.5			0.3882	0.3329	2680			120
NVCWL024Z-V1 (Rs030)			19×16×2			1200	35.5			0.3447	0.3553	3840			120
NVCWL024Z-V1 (Rs030)			19×16×2			1200	35.5			0.4338	0.4030	3080			120
NVCWL024Z-V1 (Rs075)			19×16×2			1200	35.5	90		0.4286	0.3919	5240			120
NVEWJ048Z-V1			24×19×2			1800	47.0	70		0.3447	0.3553	13120			120
						1800	47.0	80	>0	0.3447	0.3553	12250			120
						1800	47.0	90	50	0.3447	0.3553	11090			120
						1800	47.0	95	80	0.3447	0.3553	9810			120
						1800	47.0	70		0.4338	0.4030	12230			120
						1800	47.0	80	>0	0.4338	0.4030	11280			120
						1800	47.0	90	50	0.4338	0.4030	9870			120
						1800	47.0	95	80	0.4338	0.4030	8720			120
NVEWJ048Z-V1 (Rs020)			24×19×2			1800	47.0			0.3360	0.3335	6570			120
NVEWJ048Z-V1 (Rs020)			24×19×2			1800	47.0			0.3882	0.3329	5270			120
NVEWJ048Z-V1 (Rs030)			24×19×2			1800	47.0			0.3447	0.3553	7560			120
NVEWJ048Z-V1 (Rs030)			24×19×2			1800	47.0			0.4338	0.4030	6070			120
NVEWJ048Z-V1 (Rs075)			24×19×2			1800	47.0	90		0.4286	0.3919	10330			120
NSSM240A		More	2.4×2.4×0.6			20	2.9			0.1330	0.0750			0.64	120
						20	3.3			0.1844	0.7280			2.7	120
						20	2.2			0.6960	0.3030			0.84	120
					B	6	2.9			0.307	0.315			2.7	120
					G	12	3.3			0.307	0.315
					R	18	2.2			0.307	0.315
NSSM340A		More	2.8×2.8×0.6			20	2.9			0.133	0.075			0.64	120
						20	3.3			0.1844	0.7280			2.7	120
						20	2.2			0.696	0.303			0.84	120
					B	6	2.9			0.307	0.315			2.65	120
					G	12	3.3			0.307	0.315
					R	18	2.2			0.307	0.315
NESM238B		More	4.7×1.6×1.3			20	3.2			0.133	0.075			0.33	115
						20	3.4			0.189	0.718			1.8	115
						20	2.2			0.700	0.299			0.87	115
					B	8	3.2			0.307	0.315			2	115
					G	16	3.4			0.307	0.315
					R	12	2.2			0.307	0.315
NESM238A		More	4.7×1.6×1.3			20	3.2			0.133	0.075			0.33	115
						20	3.4			0.189	0.718			1.8	115
						20	2.2			0.700	0.299			0.87	115
					B	8	3.2			0.307	0.315			2	115
					G	16	3.4			0.307	0.315
					R	12	2.2			0.307	0.315
NS6B083			6.5×5.0×1.35			300	3.5			0.133	0.075	16		5.1	120
NS6G083			6.5×5.0×1.35			300	3.5			0.189	0.718	55		18	120
NS6E083A			6.5×5.0×1.35			300	3.8			0.085	0.490	48		16.8	120
NS6A083B			6.5×5.0×1.35			300	3.3			0.56	0.43	55		19	120
NS6A183			6.5×5.0×1.35			700	3.5			0.56	0.43	130		43	120
NSSB100B			3.0×2.0×1.2			20	3.6			0.133	0.075			0.212	115/110
NSSG100B			3.0×2.0×1.2			20	3.5			0.17	0.70			0.7	115/110
NS2B095A			3.0×1.5×1.0			60	3.4			0.133	0.075	4		0.75	150
NS2G095A			3.0×1.5×1.0			60	3.4			0.189	0.718	14		2.5	150
NS2R095A			3.0×1.5×1.0			60	2.1			0.700	0.299	6		0.95	160
NFSB036B			3.5×3.5×0.8			150	3.5			0.133	0.075	4		1.4	120
NFSG036B			3.5×3.5×0.8			150	4			0.200	0.690	12.1		4.5	120
NFSR036C			3.5×3.5×0.8			120	2.2			0.700	0.299	8		2.9	120
NSDW510GS-K1			Round 5			70	3.4			0.31	0.32	25.5		27.5	35
NSDW570GS-K1			Round 5			70	3.4			0.31	0.32	28			140
NSPW500GS-K1			Round 5			20	3.1			0.31	0.32			33	15
NSPW500DS			Round 5			20	3.2			0.31	0.32			27	15
NSPL500DS			Round 5			20	3.2			0.41	0.39			22	15
NSPW510DS-D1			Round 5			20	3.2			0.31	0.32			12.2	30
NSPW510DS			Round 5			20	3.2			0.31	0.32			6.15	45
NSPW510BS			Round 5			20	3.6			0.31	0.32			2.17	50
NSPL510DS			Round 5			20	3.2			0.41	0.39			4.7	50
NSPW570DS			Round 5			20	3.2			0.31	0.32			1.7	120
NSPW515DS			Round 5			20	3.2			0.31	0.32			2.3	65
NSPL515DS			Round 5			20	3.2			0.41	0.39			1.9	70
NSPW300DS			Round 3.1			20	3.2			0.31	0.32			12.9	20
NSPW310DS			Round 3.1			20	3.2			0.31	0.32			6.2	50
NSPW315DS			Round 3.1			20	3.2			0.31	0.32			3.4	60
NSPW315BS			Round 3.1			20	3.6			0.31	0.32			1.1	70
NSPB500AS			Round 5			20	3.2			0.133	0.075			9.3	15
NSPG500DS			Round 5			20	3.2			0.17	0.70			37.7	15
NSPA500CS			Round 5			20	2.9			0.557	0.433			32	13
NSPA500BS			Round 5			20	3.1			0.560	0.435			19.5	13
NSPB510BS			Round 5			20	3.1			0.133	0.075			4.7	30
NSPG510BS			Round 5			20	3.2			0.17	0.70			16	30
NSPG510S			Round 5			20	3.5			0.17	0.70			6	30
NEPG510S			Round 5			20	3.3			0.17	0.70			6.8	30
NSPE510KS			Round 5			10	2.55			0.085	0.490			6.5	30
NEPE510JS			Round 5			10	3.1			0.085	0.490			6.3	30
NSPA510CS			Round 5			20	2.9			0.557	0.433			11	30
NSPA510BS			Round 5			20	3.1			0.560	0.435			7.8	30
NSPR510GS			Round 5			20	2.1			0.700	0.299			6.8	30
NSPB300B			Round 3.1			20	3.2			0.133	0.075			6.55	15
NSPG300D			Round 3.1			20	3.2			0.17	0.70			36.1	15
NSPB310B			Round 3.1			20	3.2			0.133	0.075			2.5	30
NSPG310B			Round 3.1			20	3.2			0.17	0.70			10.8	30
NSPR310S			Round 3.1			20	2.1			0.700	0.299			4.5	30
NSPWR70CS-K1			7.62×7.62×10			50	3.1			0.344	0.355	20		12	80
NSPLR70CS-K1			7.62×7.62×10			50	3.1			0.41	0.39	18		11	70
NSPLR60CS-K1			7.62×7.62×8.7			50	3.1			0.41	0.39	18			150
NSPWR70CS			7.62×7.62×8.6			30	3.4			0.31	0.32	10		3.7	105
NSPLR70CS			7.62×7.62×8.6			30	3.4			0.41	0.39	8		3	110
NSPWR60CS			7.62×7.62×8.7			30	3.4			0.31	0.32	10.5		2.4	150
NSPLR60CS			7.62×7.62×8.7			30	3.4			0.41	0.39	8.4		1.9	150
NSPBR70BS			7.62×7.62×8.6			30	3.4			0.133	0.075	2		0.8	100
NSPGR70BS			7.62×7.62×8.6			30	3.4			0.17	0.70	7		3.1	100
NSPER70BS			7.62×7.62×8.6			30	3.6			0.10	0.57	5.4		2.5	100
NESM180B			1.8×1.8×0.85			10	2.90			0.133	0.075			0.055	105
						20	3.40			0.189	0.718			0.52	105
						20	2.25			0.696	0.303			0.42	105
NESM526B			2.1×2.1×0.9			20	3.10			0.133	0.075			0.15	110
						20	3.40			0.189	0.718			0.75	110
						20	2.25			0.696	0.303			0.55	110
NESM026F			3×3×1.8			20	3.1			0.133	0.075			0.34	115
						20	3.4			0.189	0.718			1.7	115
						20	2.25			0.696	0.303			1	115
NSSM137A			5.3×4.24×1.95			20	2.90			0.133	0.075			0.73	110/65
						20	2.60			0.133	0.075			3.8	110/65
						20	2.15			0.133	0.075			1.65	110/65
NSSM237B			5.3×4.24×2.25			20	2.9			0.133	0.075			1.1	90/45
						20	2.6			0.189	0.718			5.9	90/45
						20	2.2			0.696	0.303			2.1	90/45
NSSM332B			2.8×2.8×2.5			20	2.90			0.133	0.075			0.34	110/105
						20	3.30			0.189	0.718			1.95	110/105
						20	2.15			0.696	0.303			0.85	110/105
NSSM432A			2.8×2.8×2.5			20	2.90			0.133	0.075			0.47	110
						20	3.30			0.189	0.718			2.35	110
						20	2.15			0.696	0.303			1	110
NSPBV13AS			Oval 3.9×3.1			20	2.9			0.133	0.075			4.6	28
NSPGV13AS			Oval 3.9×3.1			20	3.3			0.189	0.718			21	28
NSPRV13AS			Oval 3.9×3.1			20	2.15			0.696	0.303			9.2	28
NSPB336JS			Oval 3.9×3			20	2.9			0.133	0.075			1.5	90/43
NSPG336JS			Oval 3.9×3			20	2.6			0.189	0.718			7.9	90/43
NSPR336JS			Oval 3.9×3			20	2.2			0.696	0.303				90/43
NSPB336GS			Oval 3.9×3			20	2.9			0.133	0.075			1.5	90/43
NSPG336GS			Oval 3.9×3			20	3.3			0.189	0.718			7.2	90/43
NSPR336GS			Oval 3.9×3			20	2.15			0.696	0.303				90/43
NSPB336HS			Oval 3.9×3			20	2.9			0.133	0.075			1.4	90/45
NSPG336HS			Oval 3.9×3			20	2.6			0.189	0.718			7.3	90/45
NSPR336HS			Oval 3.9×3			20	2.2			0.696	0.303			2.9	90/45
NSPB336DS			Oval 3.9×3.0			20	2.9			0.133	0.075			1.4	90/45
NSPG336DS			Oval 3.9×3.0			20	3.3			0.189	0.718			6.5	90/45
NSPR336DS			Oval 3.9×3.0			20	2.15			0.696	0.303			2.6	90/45
NSPB346MS			Oval 3.9×3.0			20	2.9			0.133	0.075			0.95	110/65
NSPG346MS			Oval 3.9×3.0			20	3.2			0.189	0.718			4	110/65
NSPR346MS			Oval 3.9×3.0			20	2.15			0.696	0.303			1.7	110/65
NJSW170G			1.6×1.2×0.75			650	3.25			0.322	0.335	275			120
NJSW170G-SA		More	1.6×1.2×0.75			650	3.25			0.322	0.335	255			120
NJSW170G-SA		More	1.6×1.2×0.75			650	3.25			0.273	0.225	185			120
NJSA170G			1.6×1.2×0.75			650	3.25			0.57	0.42	180			120
NJSW170F			1.6×1.2×0.75			650	3.25			0.322	0.335	260			120
NJSW170F-SA			1.6×1.2×0.75			650	3.25			0.322	0.335	240			120
NJSA170F			1.6×1.2×0.75			650	3.25			0.57	0.42	170			120
NJSW170D		More	1.6×1.2×0.75			650	3.25			0.322	0.335	225			120
NJSW170D		More	1.6×1.2×0.75			650	3.25			0.286	0.240	168			120
NJSW170C			1.6×1.2×0.75			350	3.0			0.322	0.335	130			120
NJSW170C-PB			1.6×1.2×0.75			350	3.0			0.286	0.240	96			120
NJSA170C			1.6×1.2×0.75			350	3.0			0.57	0.42	70			120
NJSW170A			1.6×1.2×0.75			350	3.3			0.344	0.355	110
NCSW170H			1.8×1.45×0.75			1000	3.25			0.325	0.342	475			120
NCSW170H-SA			1.8×1.45×0.75			1000	3.25			0.325	0.342	440			120
NCSW170H-SB			1.8×1.45×0.75			1000	3.25			0.325	0.342	380			120
NC2W170H			1.6×3×0.75			1000	6.5			0.325	0.342	950			120
NCSW170G		More	1.8×1.45×0.75			1000	3.25			0.3292	0.3439	435			120
NCSW170G		More	1.8×1.45×0.75			1000	3.25			0.2860	0.2395	325			120
NCSW170G-SA			1.8×1.45×0.75			1000	3.25			0.3292	0.3439	405			120
NCSW170G-SB			1.8×1.45×0.75			1000	3.25			0.3292	0.3439	350			120
NCSA170G			1.8×1.45×0.75			1000	3.25			0.57	0.42	290			120
NC2W170G			1.6×3×0.75			1000	6.6			0.3292	0.3439	870			120
NCSW170F			1.8×1.45×0.75			1000	3.25			0.3292	0.3439	410			120
NCSW170F-SA			1.8×1.45×0.75			1000	3.25			0.3292	0.3439	380			120
NCSB170F			1.8×1.45×0.75			1000	3.3			0.131	0.067	75			120
NCSE170F			1.8×1.45×0.75			1000	3.9			0.132	0.379	220			120
NCSG170F			1.8×1.45×0.75			1000	3.9			0.170	0.723	315			120
NCSY170F			1.8×1.45×0.75			1000	3.25			0.48	0.50	370			120
NCSA170F			1.8×1.45×0.75			1000	3.25			0.57	0.42	280			120
NCSR170F			1.8×1.45×0.75			1000	3.25			0.665	0.328	111			120
						1000	3.25			0.667	0.323	80			120
						1000	3.25			0.682	0.311	50			120
						1000	3.25			0.691	0.299	38			120
NC2W170F			1.6×3×0.75			1000	6.6			0.3292	0.3439	820			120
NC2A170F			1.6×3×0.75			1000	6.6			0.57	0.42	560			120
NCSW170D		More	1.8×1.45×0.75			1000	3.25			0.3292	0.3439	390			120
NCSW170D		More	1.8×1.45×0.75			1000	3.25			0.286	0.240	300			120
NCSW170D-PCA		More	1.8×1.45×0.75			1000	3.25			0.3292	0.3439	350			120
NCSW170D-PCA		More	1.8×1.45×0.75			1000	3.25			0.286	0.240	270			120
NCSW170D-PCB			1.8×1.45×0.75			1000	3.25			0.3292	0.3439	370			120
NCSA170D			1.8×1.45×0.75			1000	3.25			0.57	0.42	265			120
NC2W170D			1.6×3×0.75			1000	6.6			0.3292	0.3439	780			120
NC2A170D			3×1.6×0.75			1000	6.6			0.57	0.42	530			120
NCSW170C		More	1.8×1.45×0.75			1000	3.25			0.3292	0.3439	350			120
NCSW170C		More	1.8×1.45×0.75			1000	3.25			0.286	0.240	280			120
NCSA170C			1.8×1.45×0.79			1000	3.25			0.57	0.42	230			120
NC2W170C		More	3×1.6×0.75			1000	6.6			0.3292	0.3439	700			120
NC2W170C		More	3×1.6×0.75			1000	6.6			0.286	0.240	560			120
NC2A170C			3×1.6×0.75			1000	6.6			0.57	0.42	460			120
NCSW170B		More	1.8×1.45×0.75			1000	3.4			0.3292	0.3439	315			120
NCSW170B		More	1.8×1.45×0.75			1000	3.4			0.286	0.240	250			120
NCSA170B			1.8×1.45×0.79			1000	3.4			0.57	0.42	170			120
NC2W170B			3×1.6×0.75			1000	6.8			0.3292	0.3439	630			120
NC2W170A			3.0×1.6×0.71			1000	7.2			0.344	0.355	600			120
NC2A170A			3×1.6×0.75			1000	7.2			0.57	0.42	320			120
NCSW131H			1.8×1.45×0.75			1000	3.25			0.325	0.342	475			120
NCSW131H-SA			1.8×1.45×0.75			1000	3.25			0.325	0.342	440			120
NCSW131H-SB			1.8×1.45×0.75			1000	3.25			0.325	0.342	380			120
NCSW131G			1.8×1.45×0.75			1000	3.25			0.3292	0.3439	435			120
NCSW131G-SA			1.8×1.45×0.75			1000	3.25			0.3292	0.3439	405			120
NCSW131G-SB			1.8×1.45×0.75			1000	3.25			0.3292	0.3439	350			120
NCSA131G			1.8×1.45×0.75			1000	3.25			0.57	0.42	290			120
NCSW131F			1.8×1.45×0.75			1000	3.25			0.3292	0.3439	410			120
NCSW131F-SA			1.8×1.45×0.75			1000	3.25			0.3292	0.3439	380			120
NCSB131F			1.8×1.45×0.75			1000	3.3			0.131	0.067	75			120
NCSE131F			1.8×1.45×0.75			1000	3.9			0.132	0.379	220			120
NCSG131F			1.8×1.45×0.75			1000	3.9			0.170	0.723	315			120
NCSY131F			1.8×1.45×0.75			1000	3.25			0.48	0.50	370			120
NCSA131F			1.8×1.45×0.75			1000	3.25			0.57	0.42	280			120
NCSR131F			1.8×1.45×0.75			1000	3.25			0.665	0.328	111			120
						1000	3.25			0.667	0.323	80			120
						1000	3.25			0.682	0.311	50			120
						1000	3.25			0.691	0.299	38			120
NC2W131F			1.6×3×0.75			1000	6.6			0.3292	0.3439	820			120
NC2A131F			3×1.6×0.75			1000	6.6			0.57	0.42	560			120
NCSW131D			1.8×1.45×0.75			1000	3.25			0.3292	0.3439	390			120
NCSW131D-PCA			1.8×1.45×0.75			1000	3.25			0.3292	0.3439	350			120
NCSW131D-PCB			1.8×1.45×0.75			1000	3.25			0.3292	0.3439	370			120
NCSA131D			1.8×1.45×0.75			1000	3.25			0.57	0.42	265			120
NC2W131D			1.6×3×0.75			1000	6.6			0.3292	0.3439	780			120
NC2A131D			3×1.6×0.75			1000	6.6			0.57	0.42	530			120
NCSW131C			1.8×1.45×0.75			1000	3.25			0.3292	0.3439	350			120
NCSA131C			1.8×1.45×0.79			1000	3.25			0.57	0.42	230			120
NC2W131C			1.6×3×0.75			1000	6.6			0.3292	0.3439	700			120
NC2W121H			2.6×3.1×0.75			1000	6.5			0.325	0.342	950			120
NC2W121G			2.6×3.1×0.75			1000	6.5			0.3292	0.3439	870			120
NC2W121G-SC			2.6×3.1×0.75			1000	6.5			0.3292	0.3439	705			120
NC2W121F			2.6×3.1×0.75			1000	6.5			0.3292	0.3439	820			120
NC3W121F			3.75×3.1×0.75			1000	9.75			0.3292	0.3439	1230			120
NC4W121F			4.9×3.1×0.75			1000	13.0			0.3292	0.3439	1640			120
NC5W121F			6.05×3.1×0.75			1000	16.25			0.3292	0.3439	2050			120
NC2W121D			2.6×3.1×0.75			1000	6.5			0.3292	0.3439	780			120
NC3W121D			3.75×3.1×0.75			1000	9.8			0.3292	0.3439	1170			120
NC4W121D			4.9×3.1×0.75			1000	13.0			0.3292	0.3439	1560			120
NC5W121D			6.05×3.1×0.75			1000	16.3			0.3292	0.3439	1950			120
NC2W121D-S1			2.6×3.1×0.75			1000	6.5			0.3292	0.3439	740			120
NC3W121D-S1			3.75×3.1×0.75			1000	9.8			0.3292	0.3439	1110			120
NC4W121D-S1			4.9×3.1×0.75			1000	13.0			0.3292	0.3439	1480			120
NC5W121D-S1			6.05×3.1×0.75			1000	16.3			0.3292	0.3439	1850			120
NC5W121A			6.25×2.5×0.75			1000	17			0.327	0.337	1550			120
NCSW193F			11.8×8×1.7			1000	3.25			0.3292	0.3439	410			120
NC2W193F			11.8×8×1.7			1000	6.5			0.3292	0.3439	820			120
NC3W193F			11.8×8×1.7			1000	9.75			0.3292	0.3439	1230			120
NC4W193F			11.8×8×1.7			1000	13.0			0.3292	0.3439	1640			120
NC5W193F			11.8×8×1.7			1000	16.25			0.3292	0.3439	2050			120
NC2W093B			8.5×8×1.5			1200	6.6			0.3292	0.3439	860			120
NC3W093B			8.5×8×1.5			1200	9.9			0.3292	0.3439	1290			120
NC4W093B			8.5×8×1.5			1200	13.2			0.3292	0.3439	1720			120
NC5W093B			8.5×8×1.5			1200	16.5			0.3292	0.3439	2150			120
NC2W093B-S1			8.5×8×1.5			1200	6.6			0.3292	0.3439	800			120
NC3W093B-S1			8.5×8×1.5			1200	9.9			0.3292	0.3439	1200			120
NC4W093B-S1			8.5×8×1.5			1200	13.2			0.3292	0.3439	1600			120
NC5W093B-S1			8.5×8×1.5			1200	16.5			0.3292	0.3439	2000			120
NC3W093A			8.5×8×1.5			1200	9.9			0.3287	0.3417	1200			120
NC3W093A			8.5×8×1.5			1200	9.9			0.322	0.335	1200			120
NC4W093A			8.5×8×1.5			1200	13.2			0.322	0.335	1600			120
NC4W093A			8.5×8×1.5			1200	13.2			0.3287	0.3417	1600			120
NC5W093A			8.5×8×1.5			1200	16.5			0.322	0.335	2000			120
NC5W093A			8.5×8×1.5			1200	16.5			0.3287	0.3417	2000			120
NC2W321G			3.5×3.2×0.75			1000	6.5			0.3292	0.3439	870			120
NC3W321G			3.5×4×0.75			1000	9.75			0.3292	0.3439	1305			120
NC4W321G			3.5×5.1×0.75			1000	13.0			0.3292	0.3439	1740			120
NC5W321G			3.5×6.1×0.75			1000	16.25			0.3292	0.3439	2175			120
NCSW321F			3.05×2.8×0.75			1000	3.25			0.3292	0.3439	410			120
NC2W321F			3.5×3.2×0.75			1000	6.5			0.3292	0.3439	820			120
NC3W321F			3.5×4×0.75			1000	9.75			0.3292	0.3439	1230			120
NC4W321F			3.5×5.1×0.75			1000	13.0			0.3292	0.3439	1640			120
NC5W321F			3.5×6.1×0.75			1000	16.25			0.3292	0.3439	2050			120
NC2W321B			3.5×3.2×0.75			1000	6.5			0.327	0.337	730			120
NC3W321B			3.5×4×0.75			1000	9.8			0.327	0.337	1100			120
NC4W321B			3.5×5.1×0.75			1000	13.0			0.327	0.337	1460			120
NJ2W270B			3.5×3.5×0.75			1500	7.3			0.322	0.335	800			120
NJ3W270B			3.5×3.5×0.75			1500	11.0			0.322	0.335	1200			120
NJ2W270B-PF			3.5×3.5×0.75			1500	7.3			0.322	0.335	760			120
NJ3W270B-PF			3.5×3.5×0.75			1500	11.0			0.322	0.335	1140			120
NV3W470A			8×8×1.35			5000	10.8			0.322	0.335	4000			120
NLSW03A04A			22×36×5.32			5000	10.8			0.322	0.335	4000			120
NFSW172C		More	3×3×0.8			150	3.0			0.331	0.338	70			115
NFSW172C		More	3×3×0.8			150	3.0			0.286	0.240	56			115
NFSA172C			3×3×0.8			150	3.0			0.57	0.42	50			115
NFSR172C			3×3×0.8			150	3.0			0.668	0.328	24			115
						150	3.0			0.677	0.320	20			115
						150	3.0			0.688	0.309	12			115
						150	3.0			0.700	0.297	7			115
NFSW172B		More	3×3×0.8			150	3.0			0.331	0.338	60			115
NFSW172B		More	3×3×0.8			150	3.0			0.286	0.240	48			115
NFSA172B			3×3×0.8			150	3.0			0.57	0.42	43			115
NFSW172A		More	3×3×0.8			150	3.0			0.31	0.32	55			115
NFSW172A		More	3×3×0.8			150	3.0			0.286	0.240	44			115
NFSL172A			3×3×0.8			150	3.0			0.41	0.39	50			115
NFSA172A-V1			3×3×0.8			150	3.0			0.57	0.42	36			115
NFSA172A			3×3×0.8			150	3.0			0.57	0.42	27			115
NJSW172C		More	3×3×0.8			350	3.1			0.331	0.338	155			115
NJSW172C		More	3×3×0.8			350	3.1			0.286	0.240	128			115
NJSA172C			3×3×0.8			350	3.1			0.57	0.42	115			115
NJSR172C			3×3×0.8			350	3.1			0.668	0.328	50			115
						350	3.1			0.677	0.320	40			115
						350	3.1			0.688	0.309	27			115
						350	3.1			0.700	0.297	16			115
NJSW172B		More	3×3×0.8			350	3.1			0.331	0.338	135			115
NJSW172B		More	3×3×0.8			350	3.1			0.286	0.240	106			115
NJSA172B			3×3×0.8			350	3.1			0.57	0.42	100			115
NJSW172A		More	3×3×0.8			350	3.15			0.31	0.32	120			115
NJSW172A		More	3×3×0.8			350	3.15			0.286	0.240	96			115
NJSL172A			3×3×0.8			350	3.15			0.41	0.39	110			115
NJSA172A-V1			3×3×0.8			350	3.15			0.57	0.42	79			115
NJSA172A			3×3×0.8			350	3.15			0.57	0.42	58			115
NFSW123G			3×2×0.7			150	3.0			0.331	0.338	65			115
NFSA123G			3×2×0.7			150	3.0			0.57	0.42	50			115
NFSE123G			3×2×0.7			150	3.45			0.125	0.355	36.5			120
NFSW123F		More	3×2×0.7			150	3.2			0.331	0.338	57			115
						150	3.2			0.286	0.240	45			115
						150	3.2			0.41	0.39	56			115
						150	3.2	80	>0	0.41	0.39	52			115
						150	3.2	90	0	0.41	0.39	44			115
NFSA123F			3×2×0.7			150	3.2			0.57	0.42	39			115
NFSW123D			3×2×0.7			150	3.2			0.331	0.338	51			115
NFSL123D			3×2×0.7			150	3.2			0.41	0.39	49			115
NFSL123D			3×2×0.7			150	3.2	80	>0	0.41	0.39	40			115
NFSA123D			3×2×0.7			150	3.2			0.57	0.42	34			115
NJSW123G			3×2×0.7			350	3.1			0.331	0.338	140			115
NJSA123G			3×2×0.7			350	3.1			0.57	0.42	105			115
NJSW572B			3×3×0.7			150	3.0			0.331	0.338	60			115
NJSA572B			3×3×0.7			150	3.0			0.57	0.42	42			115
NSSW572C			3×3×0.7			80	3.05			0.331	0.338	30.9			115
NSSA572C			3×3×0.7			80	3.05			0.57	0.42	22.4			115
NSSW572C-PJ			3×3×0.7			80	3.05	80	>0	0.3611	0.3658	29.4			115
NJSW572C-PK			3×3×0.7			80	2.85	90	50	0.3611	0.3658	27.5			115
NSSW146A-V1			2.2×1.4×0.7			30	3.0			0.31	0.32			3.2	115
NSSW146A		More	2.2×1.4×0.7			30	3.0			0.31	0.32			3	115
NSSW146A		More	2.2×1.4×0.7			30	3.0			0.41	0.39			3	115
NESW146A			2.2×1.4×0.7			20	3.2			0.31	0.32			1.2	115
NHSW146A			2.2×1.4×0.7			10	3.1			0.31	0.32			0.45	115
NHSW146A-Y1			2.2×1.4×0.7			5	2.9			0.31	0.32			0.25	115
NHSW146AH-PA			2.2×1.4×0.7			5	2.9			0.31	0.32			0.09	115
NHSW146AH			2.2×1.4×0.7			5	2.9			0.31	0.32			0.035	115
NSSB146A			2.2×1.4×0.7			30	3.0			0.133	0.075			0.65	115
NESB146A			2.2×1.4×0.7			20	3.2			0.133	0.075			0.29	115
NHSB146A			2.2×1.4×0.7			10	3.1			0.133	0.075			0.11	115
NHSB146AH			2.2×1.4×0.7			5	2.9			0.133	0.075			0.03	115
NSSC146A			2.2×1.4×0.7			30	3.0			0.156	0.032			0.36	115
NSSG146A			2.2×1.4×0.7			30	3.2			0.17	0.70			2	115
NESG146A			2.2×1.4×0.7			20	3.5			0.17	0.70			1.2	115
NHSG146A			2.2×1.4×0.7			10	3.1			0.17	0.70			0.37	115
NHSY146A			2.2×1.4×0.7			10	3.1			0.421	0.546			0.51	115
NSSA146A-V1			2.2×1.4×0.7			30	3.0			0.55	0.44			2.7	115
NSSA146A-V1			2.2×1.4×0.7			30	3.0			0.57	0.42			2.4	115
NSSA146A			2.2×1.4×0.7			30	3.0			0.55	0.44			2.1	115
NSSA146A			2.2×1.4×0.7			30	3.0			0.57	0.42			2	115
NESA146A			2.2×1.4×0.7			20	3.2			0.55	0.44			0.98	115
NESA146A			2.2×1.4×0.7			20	3.2			0.57	0.42			0.88	115
NHSA146A			2.2×1.4×0.7			10	3.1			0.55	0.44			0.35	115
NHSA146A			2.2×1.4×0.7			10	3.1			0.57	0.42			0.33	115
NSSB146A-N3			2.2×1.4×0.7			30	3.0			0.19	0.29			2	115
NESB146A-N3			2.2×1.4×0.7			20	3.2			0.19	0.29			0.9	115
NHSB146A-N3			2.2×1.4×0.7			10	3.1			0.19	0.29			0.34	115
NHSB146AH-N3			2.2×1.4×0.7			5	2.9			0.19	0.29			0.04	115
NSSB146A-NA			2.2×1.4×0.7			30	3.0			0.19	0.19			1.8	115
NESB146A-NA			2.2×1.4×0.7			20	3.2			0.19	0.19			0.95	115
NHSB146A-NA			2.2×1.4×0.7			10	3.1			0.19	0.19			0.36	115
NHSB146AH-NA			2.2×1.4×0.7			5	2.9			0.19	0.19			0.06	115
NESB146A-ND			2.2×1.4×0.7			20	3.2			0.369	0.595			1.45	115
NHSB146A-ND			2.2×1.4×0.7			10	3.1			0.369	0.595			0.55	115
NESB146A-N8			2.2×1.4×0.7			20	3.2			0.35	0.45			1.6	115
NSSR146A			2.2×1.4×0.7			30	3.0			0.616	0.372			1.5	115
						30	3.0			0.628	0.359			1.2	115
						30	3.0			0.640	0.348			1	115
						30	3.0			0.677	0.320			0.55	115
						30	3.0			0.688	0.309			0.4	115
						30	3.0			0.704	0.292			0.24	115
						30	3.0			0.708	0.289			0.18	115
NESR146A			2.2×1.4×0.7			20	3.2			0.616	0.372			0.8	115
						20	3.2			0.628	0.359			0.58	115
						20	3.2			0.640	0.348			0.48	115
						20	3.2			0.677	0.320			0.27	115
						20	3.2			0.688	0.309			0.2	115
						20	3.2			0.704	0.292			0.12	115
						20	3.2			0.708	0.289			0.09	115
NHSR146A			2.2×1.4×0.7			10	3.1			0.616	0.372			0.3	115
						10	3.1			0.628	0.359			0.24	115
						10	3.1			0.640	0.348			0.19	115
						10	3.1			0.677	0.320			0.1	115
						10	3.1			0.688	0.309			0.07	115
						10	3.1			0.704	0.292			0.045	115
						10	3.1			0.708	0.289			0.03	115
NHSW046A			2.2×1.4×1.3			5	2.9			0.31	0.32			0.27	115
NHSW046			2.2×1.4×1.3			5	2.9			0.31	0.32			0.106	115
NHSW046H			2.2×1.4×1.3			5	2.9			0.31	0.32			0.035	115
NHSL046A			2.2×1.4×1.3			5	2.9			0.41	0.39			0.32	115
NHSL046			2.2×1.4×1.3			5	2.9			0.41	0.39			0.09	115
NHSB046A			2.2×1.4×1.3			5	2.9			0.133	0.075			0.063	115
NHSB046			2.2×1.4×1.3			5	2.9			0.133	0.075			0.031	115
NHSG046			2.2×1.4×1.3			5	3.1			0.17	0.70			0.195	115
NHSA046			2.2×1.4×1.3			5	2.9			0.563	0.428			0.065	115
NHSB046-N2			2.2×1.4×1.3			5	2.9			0.185	0.362			0.065	115
NHSB046A-N3			2.2×1.4×1.3			5	2.9			0.1825	0.2475			0.22	115
NHSB046-N3			2.2×1.4×1.3			5	2.9			0.19	0.29			0.085	115
NHSB046H-N3			2.2×1.4×1.3			5	2.9			0.19	0.29			0.027	115
NHSB046A-N5			2.2×1.4×1.3			5	2.9			0.214	0.394			0.23	115
NHSB046-N5			2.2×1.4×1.3			5	2.9			0.214	0.394			0.075	115
NHSB046A-NA			2.2×1.4×1.3			5	2.9			0.19	0.19			0.23	115
NHSB046-NA			2.2×1.4×1.3			5	2.9			0.19	0.19			0.085	115
NHSB046-N8			2.2×1.4×1.3			5	2.9			0.35	0.45			0.135	115
NSSW063A			3.5×2.8×2			50	2.9			0.31	0.32			6.1	115
NSSC063A			3.5×2.8×2			50	2.9			0.156	0.032			0.76	115
NSSB063A-N3			3.5×2.8×2			50	2.9			0.190	0.290			4.3	115
NSSW064A			3.5×2.8×2			30	2.9			0.31	0.32			3.3	115
NESW064A			3.5×2.8×2			20	3.1			0.31	0.32			1.5	115
NHSW064			3.5×2.8×2			10	3.1			0.31	0.32			0.65	115
NESL064A			3.5×2.8×2			20	3.1			0.41	0.39			1.3	115
NSSB064			3.5×2.8×2			30	3.4			0.133	0.075			0.6	115
NESB064			3.5×2.8×2			20	3.1			0.133	0.075			0.31	115
NHSB064			3.5×2.8×2			10	3.1			0.133	0.075			0.155	115
NESG064			3.5×2.8×2			20	3.1			0.17	0.70			0.87	115
NHSG064			3.5×2.8×2			10	3.1			0.17	0.70			0.5	115
NESA064			3.5×2.8×2			20	3.1			0.563	0.428			0.69	115
NSSB064A-N2			3.5×2.8×2			30	2.9			0.185	0.362			1.9	115
NESB064-N2			3.5×2.8×2			20	3.1			0.185	0.362			0.62	115
NSSB064A-N3			3.5×2.8×2			30	2.9			0.19	0.29			2.1	115
NESB064-N3			3.5×2.8×2			20	3.1			0.19	0.29			0.75	115
NHSB064-N3			3.5×2.8×2			10	3.1			0.19	0.29			0.43	115
NHSB064H-N3			3.5×2.8×2			10	3.1			0.19	0.29			0.106	115
NSSB064A-NA			3.5×2.8×2			30	2.9			0.19	0.19			1.8	115
NESB064A-NA			3.5×2.8×2			20	3.1			0.19	0.19			1	115
NHSB064-NA			3.5×2.8×2			10	3.1			0.19	0.19			0.45	115
NHSB064H-NA			3.5×2.8×2			10	3.1			0.19	0.19			0.1	115
NHSB064-ND			3.5×2.8×2			10	3.1			0.369	0.595			0.635	115
NSSW088B			3.5×1.4×1.2			30	3.0			0.31	0.32			3	115
NSSW088A			3.5×1.4×1.2			20	3.2			0.31	0.32			1.6	115
NSSW088A			3.5×1.4×1.2			20	3.2			0.28	0.27			1.5	115
NSSL088A			3.5×1.4×1.2			20	3.2			0.41	0.39			1.4	115
NSSW129			4×4×3.6			30	2.9			0.31	0.32			3.3	115
NSSM313A-V1			3.3×3.3×1.8			20	2.90			0.153	0.026			0.3	115
						20	2.90			0.131	0.070			0.55	115
						20	3.20			0.171	0.72			2.35	115
						20	2.15			0.699	0.299			1.1	115
NSSM313A			3.3×3.3×1.8			20	2.90			0.153	0.026			0.24	115
						20	2.90			0.131	0.070			0.45	115
						20	3.15			0.171	0.720			1.8	115
						20	2.35			0.695	0.303			0.95	115
NSSM438A-V1			4.7×1.6×1.8			20	2.90			0.153	0.026			0.29	115
						20	2.90			0.131	0.070			0.52	115
						20	3.20			0.171	0.72			2.23	115
						20	2.15			0.699	0.299			1.05	115
NSSM438A			4.7×1.6×1.8			20	2.90			0.153	0.026			0.2	115
						20	3.15			0.171	0.720			1.4	115
						20	2.35			0.695	0.303			0.8	115
NS2W566H-HG			4.2×0.85×0.6			20	5.6			0.277	0.260	18		6.09
NS2W566H-HS			4.2×0.85×0.6			20	5.6			0.277	0.260	17.6		5.97
NJ2W257KR-HG			4×1.4×0.6			120	5.86			0.277	0.260	98		32.1
NSSW506H-HG			3×0.85×0.6			20	2.8			0.277	0.260	9.2		3.07
NSSW506H-HS			3×0.85×0.6			20	2.8			0.277	0.260	9		3
NS2W806H-B2			2.5×0.66×0.6			20	2.75			0.277	0.260	10.6			120
NS2W806H-B2			2.5×0.66×0.6			10	2.33			0.277	0.260	10.6			120
NS2W765F-HG			3.1×0.65×0.5			22	5.6			0.277	0.260	18.2		5.84	120
NS2W765F-HS			3.1×0.65×0.5			22	5.6			0.277	0.260	17.8		5.78
NS2W765D-HS			3.1×0.65×0.5			22	5.6			0.277	0.260	17.3		5.52
NS2W765D-HG			3.1×0.65×0.5			22	5.6			0.277	0.260	17.7		5.66	120
NS2W764F-HG			3.1×0.7×0.4			22	5.6			0.277	0.260	16.6		5.44	120
NS2W763F-HG			3.1×0.65×0.3			22	5.6			0.277	0.260	15.6		4.99	120
NF2W158B-HG			3×1.4×0.6			120	2.8			0.277	0.260	47.5
NS2W266G-HG			4.2×1×0.6			20	5.65			0.277	0.260	16.3		5.53	120
NS2W266G			4.2×1×0.6			20	5.65			0.290	0.275	17		5.71	120
NS2W364G-HG			3.8×0.85×0.4			20	5.75			0.292	0.270	13.8		4.59	120
NS2W364G			3.8×0.85×0.4			20	5.75			0.290	0.275	15.6		5.18	120
NSSW306G-HS			3×0.85×0.6			20	2.82			0.283	0.270	8.67		2.91
NSSW306G-HG			3×0.85×0.6			20	2.82			0.283	0.270	8.85		2.97	120
NSSW306G			3×0.85×0.6			20	2.82			0.290	0.275	9.5		3.15	120
NSSW306F-HG			3×0.85×0.6			20	2.85			0.277	0.260	8.1		2.72	120
NSSW306F			3×0.85×0.6			20	2.85			0.290	0.275	9.1		3.02	120
NSSW304H-HG			3×0.85×0.4			20	2.9			0.292	0.270	7.97		2.63	120
NSSW304G-HG			3×0.85×0.4			20	3.0			0.292	0.270	7.2		2.37	120
NSSW304G			3×0.85×0.4			20	3.0			0.290	0.275	8.3		2.7	120
NSSW304F-HG			3×0.85×0.4			20	2.9			0.277	0.260	6.8		2.23	120
NFSW157K-HG			3×1.4×0.6			80	2.9			0.277	0.260	34		11.1	120
NJSW157K-HG			3×1.4×0.6			120	2.93			0.277	0.260	49.5		16.2	120
NFSW157K			3×1.4×0.6			80	2.9			0.290	0.275	37.1		12.1	120
NJSW157K			3×1.4×0.6			120	2.93			0.290	0.275	55		18	120
NFSW157J-HG			3×1.4×0.6			80	2.95			0.277	0.260	33		11	120
NJSW157J-HG			3×1.4×0.6			120	3.0			0.277	0.260	48.5		16	120
NFSW157J			3×1.4×0.6			80	2.95			0.290	0.275	36		11.8	120
NJSW157J			3×1.4×0.6			120	3.0			0.290	0.275	53.5		17.5	120
NSSW157H-HG			3×1.4×0.52			80	3.0			0.277	0.260	31.5		10.3	120
NFSW157H-HG			3×1.4×0.52			120	3.0			0.277	0.260	46		15.1	120
NSSW157H			3×1.4×0.52			80	3.0			0.290	0.275	34.5		11.3	120
NFSW157H			3×1.4×0.52			120	3.0			0.290	0.275	51		16.7	120
NSSW157F-HG			3×1.4×0.52			80	3.0			0.277	0.260	30		9.8	120
NFSW157F-HG			3×1.4×0.52			120	3.0			0.277	0.260	44		14.4	120
NSSW157F			3×1.4×0.52			80	3.0			0.290	0.275	33		10.8	120
NFSW157F			3×1.4×0.52			120	3.0			0.290	0.275	48.5		15.9	120
NESW157D			3×1.4×0.52			40	3.0			0.290	0.275	16		5.2	120
NSSW157D			3×1.4×0.52			80	3.0			0.290	0.275	31.5		10.3	120
NFSW157D			3×1.4×0.52			120	3.0			0.290	0.275	46		15	120

UV-LED (該当製品：36 件)

製品比較クリア

型番	生産状況	仕様書	製品寸法 L×W×H (mm)	色	ピーク波長	放射束 Typ(mW)	順電圧 Typ(V)		指向特性 (degree)	I_F (mA)
型番	生産状況	仕様書	製品寸法 L×W×H (mm)	色	ピーク波長	放射束 Typ(mW)	Typ.(V)	Max(V)	指向特性 (degree)	I_F (mA)
NCSU434D (280nm)			3.5×3.5×1.72		280	135	5.2	6.0	110	350
NCSU434C (280nm)			3.5×3.5×1.72		280	110	5.8	6.5	110	350
NCSU434B (280nm)			3.5×3.5×1.72		280	62	5.7	6.5	110	350
NCSU434B (308nm)			3.5×3.5×1.72		308	90	5.0	5.5	110	350
NCSU434B (330nm)			3.5×3.5×1.72		330	100	5.0	5.5	110	350
NCSU434A (280nm)			3.5×3.5×1.72		280	17.5	5.3	6.0	110	100
NC4U334BR (280nm)			6.8×6.8×2.1		280	200	22.5	25.	110	350
NCSU334B (280nm)			6.8×6.8×2.1		280	70	5.5	6.5	115	350
NWSU333B (365nm)			6.8×6.8×1.9		365	4900	3.85	4.2	120	3500
NWSU333B (385nm)			6.8×6.8×1.9		385	5500	3.70	4.2	120	3500
NVSU233B (365nm)			3.5×3.5×1.23		365	1450	3.85	4.2	120	1000
NVSU233B (385nm)			3.5×3.5×1.23		385	1730	3.70	4.2	120	1000
NVSU233B (395nm)			3.5×3.5×1.23		395	1650	3.65	4.2	120	1000
NVSU233C (405nm)			3.5×3.5×1.23		405	1610	3.6	4.0	120	1000
NVSU233C-D4 (365nm)			3.5×3.5×2.73		365	1450	3.85	4.2	60	1000
NVSU233C-D4 (385nm)			3.5×3.5×2.73		385	1730	3.70	4.2	60	1000
NVSU233C-D4 (395nm)			3.5×3.5×2.73		395	1650	3.65	4.2	60	1000
NVSU233C-D4 (405nm)			3.5×3.5×2.73		405	1610	3.60	4.2	60	1000
NCSU033D (365nm)			6.8×6.8×1.9		365	800	3.65	4.4	115	500
NCSU034D (385nm)			6.8×6.8×1.9		385	860	3.5	4.3	115	500
NCSU035D (405nm)			6.8×6.8×1.9		405	860	3.35	3.9	115	500
NCSU033C (365nm)			6.8×6.8×1.9		365	750	3.8	4.4	115	500
NCSU034C (385nm)			6.8×6.8×1.9		385	830	3.55	4.3	115	500
NCSU276C (365nm)			3.5×3.5×2		365	1050	3.8	4.4	120	500
NVSU119C (375nm)			3.5×3.5×2		375	1160	3.40	3.8	135	700
NVSU119C (385nm)			3.5×3.5×2		385	1450	3.35	3.8	135	700
NVSU119C (395nm)			3.5×3.5×2		395	1450	3.30	3.8	135	700
NVSU119C (405nm)			3.5×3.5×2		405	1420	3.10	3.8	140	700
NVSU219C (405nm)			3.5×3.5×2		405	1420	3.1	3.6	140	700
NSSU123 (375nm)			3×2×0.7		375	17.6	3.3	4	125	20
NSSU100C (365nm)			3×2×1.2		365	4.8	3.4	4	110	20
NSSU100D (375nm)			3×2×1.2		375	9.9	3.3	4	110	20
NSPU510CS (375nm)			Round 5		375	15.1	3.3	4	40	15
NVSU279A (385nm)			1.8×2.6×0.63		385	1650	3.50	4.0	135	1000
NVSU279A (395nm)			1.8×2.6×0.63		395	1650	3.45	4.0	135	1000
NVSU279A (405nm)			1.8×2.6×0.63		405	1600	3.2	4.0	140	1000
