LED (Products：384 Results)

Compare Clear

Part No.	Production Status	Spec.	Size L×W×H (mm)	Color		I_F (mA)	V_F Typ(V)	CRI		Chromaticity Coordinate		Luminous Flux Typ(lm)	Radiant Flux Typ(mW)	Luminous Intensity Typ(cd)	Directivity (degree)
Part No.	Production Status	Spec.	Size L×W×H (mm)	Color		I_F (mA)	V_F Typ(V)	Ra Min	R9 Min	X	Y	Luminous Flux Typ(lm)	Radiant Flux Typ(mW)	Luminous Intensity Typ(cd)	Directivity (degree)
NFSW757H-V2H5			3×3×0.8			65	2.82	80	20	0.3447	0.3553	38.6			120
NFSW757H-V2H5			3×3×0.8			65	2.82	80	20	0.4338	0.4030	37.0			120
NFSW757H-V1H6 (H6 Series)			3×3×0.8			65	2.84	90	50	0.3447	0.3553	36.9			120
NFSW757H-V1H6 (H6 Series)			3×3×0.8			65	2.84	90	50	0.4338	0.4030	35.2			120
NFSW757H-V1			3×3×0.8			65	2.84	70		0.3447	0.3553	39.5			120
						65	2.84	80	>0	0.3447	0.3553	37.9			120
						65	2.84	90	50	0.3447	0.3553	32.6			120
						65	2.84	70		0.4338	0.4030	37.7			120
						65	2.84	80	>0	0.4338	0.4030	35.6			120
						65	2.84	90	50	0.4338	0.4030	29.8			120
NF2W757H-V2F1			3×3×0.8			65	2.72	70		0.3447	0.3553	40.3			120
						65	2.72	80	>0	0.3447	0.3553	38.9			120
						65	2.72	70		0.4338	0.4030	38.6			120
						65	2.72	80	>0	0.4338	0.4030	36.2			120
NF2W757H-F1			3×3×0.8			65	2.72	70		0.3447	0.3553	39.6			120
						65	2.72	80	>0	0.3447	0.3553	38.1			120
						65	2.72	90	50	0.3447	0.3553	32.8			120
						65	2.72	70		0.4338	0.4030	38.3			120
						65	2.72	80	>0	0.4338	0.4030	35.8			120
						65	2.72	90	50	0.4338	0.4030	29.8			120
NF2E757H-F1			3×3×0.8			65	2.74			0.188	0.268	29.5			120
NF2W757GR-V4H6 (H6 Series)			3×3×0.65			150	6.2	90	50	0.3447	0.3553	151			120
NF2W757GR-V4H6 (H6 Series)			3×3×0.65			150	6.2	90	50	0.4338	0.4030	143			120
NF2W757GR-V4			3×3×0.65			150	6.2	70		0.3447	0.3553	164			120
						150	6.2	80	>0	0.3447	0.3553	153			120
						150	6.2	90	50	0.3447	0.3553	136			120
						150	6.2	70		0.4338	0.4030	158			120
						150	6.2	80	>0	0.4338	0.4030	144			120
						150	6.2	90	50	0.4338	0.4030	126			120
NFSW757G-P5V1			3×3×0.65			65	2.89	80	>0	0.3447	0.3553	35.3			120
						65	2.89	90	50	0.3447	0.3553	29.6			120
						65	2.89	80	>0	0.4338	0.4030	32.8			120
						65	2.89	90	50	0.4338	0.4030	27.8			120
NFSW757G-P5H6 (H6 Series)			3×3×0.65			65	2.89	90	50	0.3447	0.3553	34.7			120
NFSW757G-P5H6 (H6 Series)			3×3×0.65			65	2.89	90	50	0.4338	0.4030	32.6			120
NFSW757G-P5H6 (TLCI90+)			3×3×0.65			65	2.89	90	50	0.3447	0.3553	33.8			120
NFSW757G-P5H6 (TLCI90+)			3×3×0.65			65	2.89	90	50	0.4338	0.4030	29.7			120
NF2W757G-MT (Tunable White. CRI 90)			3×3×0.75			65	2.84	90	50	0.3123	0.3282	27.5			120
NF2W757G-MT (Tunable White. CRI 90)			3×3×0.75			65	2.84	90	50	0.4578	0.4101	26.5			120
NF2W757G-MT (Tunable White. CRI 80)			3×3×0.75			65	2.84	80	>0	0.3123	0.3282	32			120
NF2W757G-MT (Tunable White. CRI 80)			3×3×0.75			65	2.84	80	>0	0.4578	0.4101	31			120
NF2W757G-V3F1			3×3×0.65			65	2.73	70		0.3447	0.3553	38.8			120
						65	2.73	80	>0	0.3447	0.3553	37.3			120
						65	2.73	90	50	0.3447	0.3553	32.3			120
						65	2.73	70		0.4338	0.4030	37.5			120
						65	2.73	80	>0	0.4338	0.4030	35.3			120
						65	2.73	90	50	0.4338	0.4030	29.4			120
NF2W757G-V3F1 (Vitasolis)			3×3×0.65			65	2.73	80	>0	0.3447	0.3553	35.6			120
NF2W757G-V3F1 (Vitasolis)			3×3×0.65			65	2.73	80	>0	0.4338	0.4030				120
NF2L757G-F1 (R95)			3×3×0.65			65	2.76	95		0.4338	0.4030	24.1			120
NF2L757G-F1 (Optisolis)			3×3×0.65			65	2.76	95	80	0.4338	0.4030	24.1			120
NF2W757G-F1 (R95)			3×3×0.65			65	2.76	95		0.3447	0.3553	26.8			120
NF2W757G-F1 (Optisolis)			3×3×0.65			65	2.9	95	85	0.3447	0.3553	23			120
NF2L757GR-V1（R95）			3×3×0.65			150	6.3	95		0.4338	0.4030	100			120
NF2W757GR-V1（R95）			3×3×0.65			150	6.3	95		0.3447	0.3553	110			120
NFSW757G-V3 (Rs020)			3×3×0.65			65	2.85			0.336	0.335	22.1			120
NFSW757G-V3 (Rs030)			3×3×0.65			65	2.85			0.3447	0.3553	22.3			120
NFSW757G-V3 (Rs030)			3×3×0.65			65	2.85			0.4338	0.4030	18.9			120
NFSW757G-V3 (Rs060)			3×3×0.65			65	2.85			0.336	0.301	14.5			120
NF2L757GR-V1U4			3×3×0.65			37.5	24.8	70		0.4338	0.4030	122			120
						37.5	24.8	80	>0	0.4338	0.4030	116			120
						37.5	24.8	90	50	0.4338	0.4030	98			120
NF2W757GR-V1U4			3×3×0.65			37.5	24.8	70		0.3447	0.3553	129			120
						37.5	24.8	80	>0	0.3447	0.3553	125			120
						37.5	24.8	90	50	0.3447	0.3553	107			120
NFSWE11A-V1			1.1×1.1×0.27～0.35			65	2.8	70		0.3447	0.3553	33.3			120
						65	2.8	80	>0	0.3447	0.3553	31.0			120
						65	2.8	90	50	0.3447	0.3553	26.4			120
						65	2.8	90	80	0.3447	0.3553	25.2			120
						65	2.8	70		0.4338	0.4030	31.7			120
						65	2.8	80	>0	0.4338	0.4030	28.7			120
						65	2.8	90	50	0.4338	0.4030	24.4			120
						65	2.8	90	80	0.4338	0.4030	21.4			120
NFSWE11A			1.1×1.1×0.27～0.35			65	2.8	90	80	0.3123	0.3282	25.0			120
						65	2.8	70		0.3447	0.3553	32.1			120
						65	2.8	80	0	0.3447	0.3553	29.4			120
						65	2.8	90	50	0.3447	0.3553	25.5			120
						65	2.8	70		0.4338	0.4030	30.6			120
						65	2.8	80	0	0.4338	0.4030	27.7			120
						65	2.8	90	50	0.4338	0.4030	23.6			120
						65	2.8	90	80	0.4338	0.4030	20.7			120
NCSWE17A-V1			1.7×1.7×0.27～0.35			350	2.95	70		0.3447	0.3553	173			120
						350	2.95	80	>0	0.3447	0.3553	163			120
						350	2.95	90	50	0.3447	0.3553	137			120
						350	2.95	90	80	0.3447	0.3553	127			120
						350	2.95	70		0.4338	0.4030	165			120
						350	2.95	80	>0	0.4338	0.4030	147			120
						350	2.95	90	50	0.4338	0.4030	125			120
						350	2.95	90	80	0.4338	0.4030	110			120
NCSLE17A			1.7×1.7×0.27~0.35			350	3.0	70		0.4338	0.4030	161			120
						350	3.0	80	>0	0.4338	0.4030	143			120
						350	3.0	90	50	0.4338	0.4030	120			120
						350	3.0	90	80	0.4338	0.4030	107			120
NCSWE17A			1.7×1.7×0.27			350	3.0	70		0.3447	0.3553	165			120
						350	3.0	80	>0	0.3447	0.3553	158			120
						350	3.0	90	50	0.3447	0.3553	133			120
						350	3.0	90	80	0.3447	0.3553	123			120
NCSAE17A			1.7×1.7×0.35			350	3.0			0.567	0.419	124			120
NCSBE17A			1.7×1.7×0.35			350	3.0			0.126	0.078	42			130
NCSCE17A			1.7×1.7×0.35			350	3.0			0.157	0.021	18			130
NCSEE17A			1.7×1.7×0.35			350	3.0			0.188	0.268	132			120
NCSGE17A (Green)			1.7×1.7×0.35			350	3.0			0.252	0.651	208			120
NCSGE17A (Lime)			1.7×1.7×0.35			350	3.0			0.4140	0.5430	212			120
NCSRE17A-V1 (Brilliant Red)			1.7×1.7×0.35			350	2.95			0.669	0.328	60			120
NCSRE17A (Brilliant Red)			1.7×1.7×0.35			350	3.0			0.669	0.328	58			120
NCSRE17A-V1 (Red)			1.7×1.7×0.35			350	2.95			0.683	0.313	32			120
NCSRE17A (Red)			1.7×1.7×0.35			350	3.0			0.683	0.313	31			120
NVSWE21A-V1			2.1×2.1×0.27～0.35			700	2.95	70		0.3447	0.3553	336			120
						700	2.95	80	>0	0.3447	0.3553	317			120
						700	2.95	90	50	0.3447	0.3553	273			120
						700	2.95	90	80	0.3447	0.3553	252			120
						700	2.95	70		0.4338	0.4030	323			120
						700	2.95	80	>0	0.4338	0.4030	292			120
						700	2.95	90	50	0.4338	0.4030	246			120
						700	2.95	90	80	0.4338	0.4030	216			120
NVSLE21A			2.1×2.1×0.27~0.35			700	3.0	70		0.4338	0.4030	314			120
						700	3.0	80	>0	0.4338	0.4030	284			120
						700	3.0	90	50	0.4338	0.4030	229			120
						700	3.0	90	80	0.4338	0.4030	214			120
NVSWE21A			2.1×2.1×0.27			700	3.0	70		0.3447	0.3553	327			120
						700	3.0	80	>0	0.3447	0.3553	307			120
						700	3.0	90	50	0.3447	0.3553	265			120
						700	3.0	90	80	0.3447	0.3553	245			120
NVSW119F-V1			3.5×3.5×2.3			700	2.96	80	>0	0.3447	0.3553	312		94	120
						700	2.96	90	50	0.3447	0.3553	255		80	120
						700	2.96	80	>0	0.4338	0.4030	295		92	120
						700	2.96	90	50	0.4338	0.4030	239		76	120
NVSW219F-V2			3.5×3.5×2.3			700	2.89	70		0.3447	0.3553	365		105	120
						700	2.89	80	>0	0.3447	0.3553	330		99	120
						700	2.89	90	50	0.3447	0.3553	280		88	120
						700	2.89	70		0.3818	0.3797	365		105	120
						700	2.89	80	>0	0.4338	0.4030	310		93	120
						700	2.89	90	50	0.4338	0.4030	262		83	120
NVSW219F-V1			3.5×3.5×2.3			700	2.96	80	>0	0.3447	0.3553	312		94	120
						700	2.96	90	50	0.3447	0.3553	255		80	120
						700	2.96	80	>0	0.4338	0.4030	295		92	120
						700	2.96	90	50	0.4338	0.4030	239		76	120
NVSW119F			3.5×3.5×2.3			700	2.96			0.3123	0.3282	333		100	120
						700	2.96	70		0.3447	0.3553	346		103	120
						700	2.96	70		0.3818	0.3797	341		101	120
						700	2.96			0.4806	0.4141	302		92	120
NVSW219F			3.5×3.5×2.3			700	2.96			0.3123	0.3282	333		100	120
						700	2.96	70		0.3447	0.3553	346		103	120
						700	2.96	70		0.3818	0.3797	341		101	120
						700	2.96			0.4806	0.4141	302		92	120
NVSW219C (For Flashlight)			3.5×3.5×2			700	2.98	70		0.3072	0.3126	295		84	130
NVSW219C			3.5×3.5×2			700	2.98			0.3447	0.3553	325		93	130
						700	2.98	70		0.3447	0.3553	322		92	130
						700	2.98	80	>0	0.3447	0.3553	283		84	130
						700	2.98	90	50	0.3447	0.3553	254		75	130
NVSL219C			3.5×3.5×2			700	2.98	70		0.3818	0.3797	320		91	130
						700	2.98	80	>0	0.4073	0.3917	297		88	130
						700	2.98	90	50	0.4073	0.3917	236		72	130
NVSW119C (For Flashlight)			3.5×3.5×2			700	2.98	70		0.3072	0.3126	295		84	130
NVSW119C			3.5×3.5×2			700	2.98			0.3447	0.3553	325		93	130
						700	2.98	70		0.3447	0.3553	322		92	130
						700	2.98	80	>0	0.3447	0.3553	283		84	130
						700	2.98	90	50	0.3447	0.3553	254		75	130
NVSL119C			3.5×3.5×2			700	2.98	70		0.3818	0.3797	320		91	130
						700	2.98	80	>0	0.4073	0.3917	297		88	130
						700	2.98	90	50	0.4073	0.3917	236		72	130
NVSW309B (For Flashlight)			3.5×3.5×2.35			1050	2.98			0.2999	0.3077	487		130	（130）
NVSW309B			3.5×3.5×2.35			1050	2.98			0.3123	0.3282	494		135	（130）
						1050	2.98	70		0.3447	0.3553	512		146	（130）
						1050	2.98	80	>0	0.3447	0.3553	455		124	（130）
						1050	2.98	70		0.3818	0.3797	507		148	（130）
						1050	2.98	80	>0	0.4338	0.4030	430		128	（130）
NVSW309A			3.5×3.5×2.1			1050	3.02	70		0.3447	0.3553	480		127	135
						1050	3.02	80	>0	0.3447	0.3553	415		114	135
						1050	3.02	70		0.3818	0.3797	474		126	135
						1050	3.02	80	>0	0.4073	0.3917	415		114	135
NVSW319B (For Flashlight)			3.5×3.5×2.35			1050	2.98			0.2999	0.3077	487		130	（130）
NVSW319B			3.5×3.5×2.35			1050	2.98			0.3123	0.3282	494		135	（130）
						1050	2.98	70		0.3447	0.3553	512		146	（130）
						1050	2.98	80	>0	0.3447	0.3553	455		124	（130）
						1050	2.98	70		0.3818	0.3797	507		148	（130）
						1050	2.98	80	>0	0.4338	0.4030	430		128	（130）
NVSW319A			3.5×3.5×2.1			1050	3.02	70		0.3447	0.3553	480		127	135
						1050	3.02	80	>0	0.3447	0.3553	415		114	135
						1050	3.02	70		0.3818	0.3797	474		126	135
						1050	3.02	80	>0	0.4073	0.3917	415		114	135
NVSW519A-V1			3.5×3.5×2.35			1400	2.94	90	80	0.3287	0.3417	507			（130）
						1400	2.94	70		0.3447	0.3553	730			（130）
						1400	2.94	80	0	0.3447	0.3553	655			（130）
						1400	2.94	70		0.3818	0.3797	720			（130）
						1400	2.94	80	0	0.4338	0.4030	624			（130）
						1400	2.94	90	80	0.4338	0.4030	428			（130）
NVSW519A-V1 (TLCI90+)			3.5×3.5×2.35			1400	2.94	90	80	0.3287	0.3417	507			（130）
NVSW519A-V1 (For Flashlight)			3.5×3.5×2.35			1400	2.94	70		0.2999	0.3077	697			（130）
NVSW519A			3.5×3.5×2.35			1400	3.03	90	80	0.3287	0.3417	480			（130）
						1400	3.03	70		0.3447	0.3553	680			（130）
						1400	3.03	80	0	0.3447	0.3553	615			（130）
						1400	3.03	70		0.3818	0.3797	667			（130）
						1400	3.03	80	0	0.4338	0.4030	581			（130）
						1400	3.03	90	80	0.4338	0.4030	407			（130）
NVSW519A (TLCI90+)			3.5×3.5×2.35			1400	3.03	90	80	0.3287	0.3417	480			（130）
NVSW519A (For Flashlight)			3.5×3.5×2.35			1400	3.03	70		0.2999	0.3077	646			(130)
NV4WB35AM			3.65×3.65×0.73			1400	5.93	90	80	0.3287	0.3417	930		311	120
						1400	5.93	70		0.3447	0.3553	1,236		395	120
						1400	5.93	80	0	0.3447	0.3553	1,150		379	120
						1400	5.93	70		0.3818	0.3797	1,210		391	120
						1400	5.93	80	0	0.4338	0.4030	1,040		344	120
						1400	5.93	90	80	0.4338	0.4030	760		270	120
NV4WB35AM (For Flashlight)			3.65×3.65×0.73			1400	5.93			0.2973	0.3176	1,275		406	120
NV4WB35AM (TLCI90+)			3.65×3.65×0.73			1400	5.93	90	80	0.3287	0.3417	930		311	120
NV4WB35AR			3.65×3.65×0.73			700	11.86	90	80	0.3287	0.3417	930		311	120
						700	11.86	70		0.3447	0.3553	1,236		395	120
						700	11.86	80	0	0.3447	0.3553	1,150		379	120
						700	11.86	70		0.3818	0.3797	1,210		391	120
						700	11.86	80	0	0.4338	0.4030	1,040		344	120
						700	11.86	90	80	0.4338	0.4030	760		270	120
NV4WB35AR (For Flashlight)			3.65×3.65×0.73			700	11.86			0.2973	0.3176	1,275		406	120
NV4WB35AR (TLCI90+)			3.65×3.65×0.73			700	11.86	90	80	0.3287	0.3417	930		311	120
NV4L144AM			5×5×3.15			1400	5.97	70		0.3818	0.3797	1,321		355	120
						1400	5.97	80	>0	0.3818	0.3797	1,183		337	120
						1400	5.97	90	50	0.3818	0.3797	985		280	120
NV4W144AM			5×5×3.15			1400	5.97	70		0.3447	0.3553	1,342		351	120
						1400	5.97	80	>0	0.3447	0.3553	1,202		330	120
						1400	5.97	90	50	0.3447	0.3553	1,030		278	120
						1400	5.97	90	80	0.3307	0.3434	970		269	120
NV4L144AR			5×5×3.15			700	11.9	70		0.3818	0.3797	1,321		355	120
						700	11.9	80	>0	0.3818	0.3797	1,183		337	120
						700	11.9	90	50	0.3818	0.3797	985		280	120
NV4W144AR			5×5×3.15			700	11.9	70		0.3447	0.3553	1,342		351	120
						700	11.9	80	>0	0.3447	0.3553	1,202		330	120
						700	11.9	90	50	0.3447	0.3553	1,030		278	120
						700	11.9	90	80	0.3307	0.3434	970		269	120
NV9W149AM			7×7×3.1			2100	9.0	80	>0	0.3307	0.3434	2,720			140
						2100	9.0	90	50	0.3307	0.3434	2,490			140
						2100	9.0	70		0.3447	0.3553	2,900			140
						2100	9.0	80	>0	0.4073	0.3917	2,600			140
NFMW488AR-V1			6.5×5.8×0.8			200	44.8	90	50	0.3447	0.3553	1,186			120
						200	44.8	70		0.3447	0.3553	1,416			120
						200	44.8	80	0	0.3447	0.3553	1,325			120
						200	44.8	90	50	0.4338	0.4030	1,091			120
						200	44.8	70		0.4338	0.4030	1,390			120
						200	44.8	80	0	0.4338	0.4030	1,265			120
NFMW481AR			6.5×5.8×0.8			200	22.9	70		0.3447	0.3553	690			120
						200	22.9	80	>0	0.3447	0.3553	640			120
						200	22.9	90	50	0.3447	0.3553	560			120
						200	22.9	70		0.4338	0.4030	670			120
						200	22.9	80	>0	0.4338	0.4030	610			120
						200	22.9	90	50	0.4338	0.4030	530			120
NFMW484AR			6.5×5.8×0.8			200	32.8	70		0.3447	0.3553	970			120
						200	32.8	80	>0	0.3447	0.3553	900			120
						200	32.8	90	50	0.3447	0.3553	800			120
						200	32.8	70		0.4338	0.4030	950			120
						200	32.8	80	>0	0.4338	0.4030	870			120
						200	32.8	90	50	0.4338	0.4030	750			120
NFMW486AR			6.5×5.8×0.8			200	39.3	70		0.3447	0.3553	1,130			120
						200	39.3	80	>0	0.3447	0.3553	1,060			120
						200	39.3	90	50	0.3447	0.3553	960			120
						200	39.3	70		0.4338	0.4030	1,100			120
						200	39.3	80	>0	0.4338	0.4030	1,030			120
						200	39.3	90	50	0.4338	0.4030	890			120
NFMW488AR			6.5×5.8×0.8			200	45.9	70		0.3447	0.3553	1,320			120
						200	45.9	80	>0	0.3447	0.3553	1,240			120
						200	45.9	90	50	0.3447	0.3553	1,110			120
						200	45.9	70		0.4338	0.4030	1,280			120
						200	45.9	80	>0	0.4338	0.4030	1,190			120
						200	45.9	90	50	0.4338	0.4030	1,030			120
NF3W585AR-V1			4×3.6×2.05			50	8.36	70		0.3447	0.3553	91.5			135/135
						50	8.36	80	>0	0.3447	0.3553	84.9			135/135
						50	8.36	70		0.4338	0.4030	87.4			135/135
						50	8.36	80	>0	0.4338	0.4030	78.7			135/135
NF2W585AR-P8 (Disinfection)			4×3.6×2.05			75	6.21	80	>0	0.4073	0.3917	53.0			125/115
						75	6.21	80	>0	0.3447	0.3553	53.0			125/115
						75	6.21	80	>0	0.3818	0.3797	53.0			125/115
NF2W385AR-V2			4×3.6×2.05			200	6.45	70		0.3447	0.3553	205			115/130
						200	6.45	80	>0	0.3447	0.3553	193			115/130
						200	6.45	90	50	0.3447	0.3553	168			115/130
						200	6.45	70		0.4338	0.4030	199			115/130
						200	6.45	80	>0	0.4338	0.4030	181			115/130
						200	6.45	90	50	0.4338	0.4030	153			115/130
NF3W585AR			4×3.6×2.05			50	8.44	70		0.3447	0.3553	87.5			135/135
						50	8.44	80	>0	0.3447	0.3553	82.4			135/135
						50	8.44	70		0.4338	0.4030	83.9			135/135
						50	8.44	80	>0	0.4338	0.4030	76.3			135/135
NF2W385AR-V3			4×3.6×2.05			75	5.73	70		0.3447	0.3553	87.0			138/118
						75	5.73	80	>0	0.3447	0.3553	79.8			138/118
						75	5.73	90	50	0.3447	0.3553	69.5			138/118
						75	5.73	70		0.4338	0.4030	84.5			138/118
						75	5.73	80	>0	0.4338	0.4030	76.5			138/118
						75	5.73	90	50	0.4338	0.4030	63.8			138/118
NTCWS024B-V3 (Optisolis)			15×12×2			135	34.9	95	80	0.4338	0.4030	515			120
NTCWS024B-V3 (Rs020)			15×12×2			135	34.9			0.3360	0.3335	450			120
NTCWS024B-V3 (Rs020)			15×12×2			135	34.9			0.3882	0.3329	370			120
NTCWS024B-V3 (Rs030)			15×12×2			135	34.9			0.3447	0.3553	520			120
NTCWS024B-V3 (Rs030)			15×12×2			135	34.9			0.4338	0.4030	430			120
NTCWS024B-V3 (Rs075)			15×12×2			135	34.9	90		0.4286	0.3919	655			120
NFCWS024B-V3 (Optisolis)			15×12×2			120	35.8	94	70	0.3447	0.3553	455			120
NFCWL036B-V3 (Optisolis, White)			19×16×2			180	35.8	94	70	0.3447	0.3553	710			120
NFCWL036B-V3 (Optisolis, Warm White)			19×16×2			260	34.6	95	80	0.4338	0.4030	1,030			120
NFCWL036B-V3 (Rs020)			19×16×2			260	34.6			0.3360	0.3335	900			120
NFCWL036B-V3 (Rs020)			19×16×2			260	34.6			0.3882	0.3329	740			120
NFCWL036B-V3 (Rs030)			19×16×2			260	34.6			0.3447	0.3553	1,030			120
NFCWL036B-V3 (Rs030)			19×16×2			260	34.6			0.4338	0.4030	850			120
NFCWL036B-V3 (Rs075)			19×16×2			260	34.6	90		0.4286	0.3919	1,300			120
NFCWL060B-V3 (Optisolis, White)			19×16×2			300	35.8	94	70	0.3447	0.3553	1,200			120
NFCWL060B-V3 (Optisolis, Warm White)			19×16×2			460	34.8	95	80	0.4338	0.4030				120
NFCWL060B-V3 (Rs020)			19×16×2			460	34.8			0.3360	0.3335	1,600			120
NFCWL060B-V3 (Rs020)			19×16×2			460	34.8			0.3882	0.3329	1,320			120
NFCWL060B-V3 (Rs030)			19×16×2			460	34.8			0.3447	0.3553	1,840			120
NFCWL060B-V3 (Rs030)			19×16×2			460	34.8			0.4338	0.4030	1,530			120
NFCWL060B-V3 (Rs075)			19×16×2			460	34.8	90		0.4286	0.3919	2,320			120
NFCWJ108B-V3 (Optisolis, White)			24×19×2			540	35.8	94	70	0.3447	0.3553	2,150			120
NFCWJ108B-V3 (Optisolis, Warm White)			24×19×2			860	34.9	95	80	0.4338	0.4030	3,380			120
NFCWJ108B-V3 (Rs020)			24×19×2			860	34.9			0.3360	0.3335	2,960			120
NFCWJ108B-V3 (Rs020)			24×19×2			860	34.9			0.3882	0.3329	2,440			120
NFCWJ108B-V3 (Rs030)			24×19×2			860	34.9			0.3447	0.3553	3,410			120
NFCWJ108B-V3 (Rs030)			24×19×2			860	34.9			0.4338	0.4030	2,820			120
NFCWJ108B-V3 (Rs075)			24×19×2			860	34.9	90		0.4286	0.3919	4,290			120
NFDWJ130B-V3 (Optisolis, White)			24×19×2			600	37.4	94	70	0.3447	0.3553	2,560			120
NFDWJ130B-V3 (Optisolis, Warm White)			24×19×2			1150	38.5	95	80	0.4338	0.4030	4,810			120
NFDWJ130B-V3 (Rs020)			24×19×2			1150	38.5			0.3360	0.3335	4,200			120
NFDWJ130B-V3 (Rs020)			24×19×2			1150	38.5			0.3882	0.3329	3,470			120
NFDWJ130B-V3 (Rs030)			24×19×2			1150	38.5			0.3447	0.3553	4,850			120
NFDWJ130B-V3 (Rs030)			24×19×2			1150	38.5			0.4338	0.4030	4,010			120
NFDWJ130B-V3 (Rs075)			24×19×2			1150	38.5	90		0.4286	0.3919	6,090			120
NFCWS024B-V4H6 (H6 Series)			15×12×2			135	34.0	90	50	0.3450	0.3602	830			120
NFCWS024B-V4H6 (H6 Series)			15×12×2			135	34.0	90	50	0.4289	0.4026	800			120
NTCWS024B-V4			15×12×2			135	34.9	70		0.3447	0.3553	860			120
						135	34.9	80	>0	0.3447	0.3553	815			120
						135	34.9	90	50	0.3447	0.3553	720			120
						135	34.9	95	80	0.3447	0.3553	615			120
						135	34.9	70		0.4338	0.4030	830			120
						135	34.9	80	>0	0.4338	0.4030	770			120
						135	34.9	90	50	0.4338	0.4030	675			120
						135	34.9	95	80	0.4338	0.4030	560			120
NFCWL036B-V4H6 (H6 Series)			19×16×2			260	34.6	90	50	0.3450	0.3602	1,620			120
NFCWL036B-V4H6 (H6 Series)			19×16×2			260	34.6	90	50	0.4289	0.4026	1,570			120
NFCWL036B-V4			19×16×2			260	34.6	70		0.3447	0.3553	1,700			120
						260	34.6	80	>0	0.3447	0.3553	1,610			120
						260	34.6	90	50	0.3447	0.3553	1,430			120
						260	34.6	95	80	0.3447	0.3553	1,210			120
						260	34.6	70		0.4338	0.4030	1,640			120
						260	34.6	80	>0	0.4338	0.4030	1,520			120
						260	34.6	90	50	0.4338	0.4030	1,340			120
						260	34.6	95	80	0.4338	0.4030	1,110			120
NFCWL060B-V4H6 (H6 Series)			19×16×2			460	34.8	90	50	0.3450	0.3602	2,870			120
NFCWL060B-V4H6 (H6 Series)			19×16×2			460	34.8	90	50	0.4289	0.4026	2,780			120
NFCWL060B-V4			19×16×2			460	34.8	70		0.3447	0.3553	3,020			120
						460	34.8	80	>0	0.3447	0.3553	2,840			120
						460	34.8	90	50	0.3447	0.3553	2,520			120
						460	34.8	95	80	0.3447	0.3553	2,160			120
						460	34.8	70		0.4338	0.4030	2,920			120
						460	34.8	80	>0	0.4338	0.4030	2,690			120
						460	34.8	90	50	0.4338	0.4030	2,370			120
						460	34.8	95	80	0.4338	0.4030	1,980			120
NFCWJ108B-V4			24×19×2			860	34.9	70		0.3447	0.3553	5,560			120
						860	34.9	80	>0	0.3447	0.3553	5,250			120
						860	34.9	90	50	0.3447	0.3553	4,660			120
						860	34.9	95	80	0.3447	0.3553	3,990			120
						860	34.9	70		0.4338	0.4030	5,390			120
						860	34.9	80	>0	0.4338	0.4030	4,960			120
						860	34.9	90	50	0.4338	0.4030	4,370			120
						860	34.9	95	80	0.4338	0.4030	3,660			120
NFDWJ130B-V4			24×19×2			1150	38.5	70		0.3447	0.3553	7,890			120
						1150	38.5	80	>0	0.3447	0.3553	7,460			120
						1150	38.5	90	50	0.3447	0.3553	6,620			120
						1150	38.5	95	80	0.3447	0.3553	5,660			120
						1150	38.5	70		0.4338	0.4030	7,660			120
						1150	38.5	80	>0	0.4338	0.4030	7,050			120
						1150	38.5	90	50	0.4338	0.4030	6,210			120
						1150	38.5	95	80	0.4338	0.4030	5,200			120
NFEWH306B-V2			38×38×2			1400	51.9	70		0.3447	0.3553	13,120			120
						1400	51.9	80	>0	0.3447	0.3553	12,300			120
						1400	51.9	90	50	0.3447	0.3553	11,040			120
						1400	51.9	95		0.3447	0.3553	9,430			120
						1400	51.9	70		0.4338	0.4030	12,500			120
						1400	51.9	80	>0	0.4338	0.4030	11,640			120
						1400	51.9	90	50	0.4338	0.4030	10,240			120
						1400	51.9	95		0.4338	0.4030	8,320			120
NFEWH306B-V2 (Rs020)			38×38×2			1400	51.9			0.3360	0.3335	6,960			120
NFEWH306B-V2 (Rs020)			38×38×2			1400	51.9			0.3882	0.3329	5,740			120
NFEWH306B-V2 (Rs030)			38×38×2			1400	51.9			0.3447	0.3553	8,030			120
NFEWH306B-V2 (Rs030)			38×38×2			1400	51.9			0.4338	0.4030	6,640			120
NFEWH306B-V2 (Rs075)			38×38×2			1400	51.9	90		0.4286	0.3919	10,090			120
NJNWS012Z-V1MT (Tunable White)			15×12×2			280	17.9	90	50	0.3447	0.3553	630			120
NJNWS012Z-V1MT (Tunable White)			15×12×2			280	17.9	90	50	0.4540	0.4000	460			120
NVCWJ024Z-V1MT (Tunable White)			24×19×2			600	35.4	90	50	0.3447	0.3553	2,730			120
NVCWJ024Z-V1MT (Tunable White)			24×19×2			600	35.4	90	50	0.4540	0.4000	2,080			120
NJCWL024Z-V1MT (Tunable White)			19×16×2			250	35.8	90	50	0.3447	0.3553	1,120			120
NJCWL024Z-V1MT (Tunable White)			19×16×2			250	35.8	90	50	0.4540	0.4000	850			120
NVNWS007Z-V1			15×12×2			580	20.6	70		0.3447	0.3553	1,870			120
						580	20.6	80	>0	0.3447	0.3553	1,750			120
						580	20.6	90	50	0.3447	0.3553	1,580			120
						580	20.6	95	80	0.3447	0.3553	1,400			120
						580	20.6	70		0.4338	0.4030	1,740			120
						580	20.6	80	>0	0.4338	0.4030	1,610			120
						580	20.6	90	50	0.4338	0.4030	1,410			120
						580	20.6	95	80	0.4338	0.4030	1,240			120
NVNWS007Z-V1 (Rs020)			15×12×2			580	20.6			0.3360	0.3335	930			120
NVNWS007Z-V1 (Rs020)			15×12×2			580	20.6			0.3882	0.3329	750			120
NVNWS007Z-V1 (Rs030)			15×12×2			580	20.6			0.3447	0.3553	1,080			120
NVNWS007Z-V1 (Rs030)			15×12×2			580	20.6			0.4338	0.4030	860			120
NVNWS007Z-V1 (Rs075)			15×12×2			580	20.6	90		0.4286	0.3919	1,470			120
NJCWS024Z-V1			15×12×2			500	36.0	70		0.3447	0.3553	2,580			120
						500	36.0	80	>0	0.3447	0.3553	2,410			120
						500	36.0	90	50	0.3447	0.3553	2,180			120
						500	36.0	95	80	0.3447	0.3553	1,930			120
						500	36.0	70		0.4338	0.4030	2,410			120
						500	36.0	80	>0	0.4338	0.4030	2,210			120
						500	36.0	90	50	0.4338	0.4030	1,940			120
						500	36.0	95	80	0.4338	0.4030	1,710			120
NJCWS024Z-V1 (Rs020)			15×12×2			500	36.0			0.3360	0.3335	1,290			120
NJCWS024Z-V1 (Rs020)			15×12×2			500	36.0			0.3882	0.3329	1,030			120
NJCWS024Z-V1 (Rs030)			15×12×2			500	36.0			0.3447	0.3553	1,480			120
NJCWS024Z-V1 (Rs030)			15×12×2			500	36.0			0.4338	0.4030	1,190			120
NJCWS024Z-V1 (Rs075)			15×12×2			500	36.0	90		0.4286	0.3919	2,030			120
NVEWL016Z-V1			19×16×2			600	47.0	70		0.3447	0.3553	4,370			120
						600	47.0	80	>0	0.3447	0.3553	4,080			120
						600	47.0	90	50	0.3447	0.3553	3,700			120
						600	47.0	95	80	0.3447	0.3553	3,260			120
						600	47.0	70		0.4338	0.4030	4,080			120
						600	47.0	80	>0	0.4338	0.4030	3,750			120
						600	47.0	90	50	0.4338	0.4030	3,290			120
						600	47.0	95	80	0.4338	0.4030	2,900			120
NVEWL016Z-V1 (Rs020)			19×16×2			600	47.0			0.3360	0.3335	2,180			120
NVEWL016Z-V1 (Rs020)			19×16×2			600	47.0			0.3882	0.3329	1,750			120
NVEWL016Z-V1 (Rs030)			19×16×2			600	47.0			0.3447	0.3553	2,520			120
NVEWL016Z-V1 (Rs030)			19×16×2			600	47.0			0.4338	0.4030	2,020			120
NVEWL016Z-V1 (Rs075)			19×16×2			600	47.0	90		0.4286	0.3919	3,430			120
NVCWL024Z-V1			19×16×2			1200	35.5	70		0.3447	0.3553	6,660			120
						1200	35.5	80	>0	0.3447	0.3553	6,220			120
						1200	35.5	90	50	0.3447	0.3553	5,620			120
						1200	35.5	95	80	0.3447	0.3553	4,980			120
						1200	35.5	70		0.4338	0.4030	6,210			120
						1200	35.5	80	>0	0.4338	0.4030	5,720			120
						1200	35.5	90	50	0.4338	0.4030	5,010			120
						1200	35.5	95	80	0.4338	0.4030	4,420			120
NVCWL024Z-V1 (Rs020)			19×16×2			1200	35.5			0.3360	0.3335	3,330			120
NVCWL024Z-V1 (Rs020)			19×16×2			1200	35.5			0.3882	0.3329	2,680			120
NVCWL024Z-V1 (Rs030)			19×16×2			1200	35.5			0.3447	0.3553	3,840			120
NVCWL024Z-V1 (Rs030)			19×16×2			1200	35.5			0.4338	0.4030	3,080			120
NVCWL024Z-V1 (Rs075)			19×16×2			1200	35.5	90		0.4286	0.3919	5,240			120
NVEWJ048Z-V1			24×19×2			1800	47.0	70		0.3447	0.3553	13,120			120
						1800	47.0	80	>0	0.3447	0.3553	12,250			120
						1800	47.0	90	50	0.3447	0.3553	11,090			120
						1800	47.0	95	80	0.3447	0.3553	9,810			120
						1800	47.0	70		0.4338	0.4030	12,230			120
						1800	47.0	80	>0	0.4338	0.4030	11,280			120
						1800	47.0	90	50	0.4338	0.4030	9,870			120
						1800	47.0	95	80	0.4338	0.4030	8,720			120
NVEWJ048Z-V1 (Rs020)			24×19×2			1800	47.0			0.3360	0.3335	6,570			120
NVEWJ048Z-V1 (Rs020)			24×19×2			1800	47.0			0.3882	0.3329	5,270			120
NVEWJ048Z-V1 (Rs030)			24×19×2			1800	47.0			0.3447	0.3553	7,560			120
NVEWJ048Z-V1 (Rs030)			24×19×2			1800	47.0			0.4338	0.4030	6,070			120
NVEWJ048Z-V1 (Rs075)			24×19×2			1800	47.0	90		0.4286	0.3919	10,330			120
NSSLT02A-V2			1.2×0.7×0.75			65	2.94	80	>0	0.439	0.408	28.5			>180
NSSLT02A-V2			1.2×0.7×0.75			65	2.94	90		0.439	0.408	25.0			>180
NSSWT02A-V2			1.2×0.7×0.75			65	2.94	80	>0	0.349	0.361	30.5			>180
NSSWT02A-V2			1.2×0.7×0.75			65	2.94	90		0.349	0.361	25.9			>180
NVSA119B-V1			3.5×3.5×2			700	2.98			0.568	0.422	240		66	120
NVSA219B-V1			3.5×3.5×2			700	2.98			0.568	0.422	240		66	120
NE2B757G			3×3×0.65			100	2.9			0.133	0.075	8.7			120
NF2E757GR			3×3×0.65			150	6.96			0.095	0.565	83			120
NE2G757G			3×3×0.65			100	3.5			0.17	0.70	33			120
NFSY757G			3×3×0.65			65	2.88			0.4987	0.4946	30.2			120
NE2R757G-P6			3×3×0.65			100	2.13			0.695	0.305	16			120
NCSC119B-V1			3.5×3.5×2			350	2.93			0.161	0.026		680		125
NCSC219B-V1			3.5×3.5×2			350	2.93			0.161	0.026		680		125
NCSB119B-V1			3.5×3.5×2			350	3.0			0.133	0.070	40		11.7	125
NCSB219B-V1			3.5×3.5×2			350	3.0			0.133	0.070	40		11.7	125
NCSE119B-V1			3.5×3.5×2			350	3.32			0.095	0.565	108		28	135
NCSE219B-V1			3.5×3.5×2			350	3.32			0.095	0.565	108		28	135
NCSG119B-V1			3.5×3.5×2			350	3.38			0.168	0.729	139		35	145
NCSG219B-V1			3.5×3.5×2			350	3.38			0.168	0.729	139		35	145
NCSA119B-V1			3.5×3.5×2			350	2.93			0.568	0.422	118		35	120
NCSA219B-V1			3.5×3.5×2			350	2.93			0.568	0.422	118		35	120
NCSR119B-V1			3.5×3.5×2			350	2.2			0.695	0.305	75		19.4	130
NCSR219B-V1			3.5×3.5×2			350	2.2			0.695	0.305	75		19.4	130
NSSM240A		More	2.4×2.4×0.6			20	2.9			0.1330	0.0750			0.64	120
						20	3.3			0.1844	0.7280			2.7	120
						20	2.2			0.6960	0.3030			0.84	120
					B	6	2.9			0.307	0.315			2.7	120
					G	12	3.3			0.307	0.315
					R	18	2.2			0.307	0.315
NSSM340A		More	2.8×2.8×0.6			20	2.9			0.133	0.075			0.64	120
						20	3.3			0.1844	0.7280			2.7	120
						20	2.2			0.696	0.303			0.84	120
					B	6	2.9			0.307	0.315			2.65	120
					G	12	3.3			0.307	0.315
					R	18	2.2			0.307	0.315
NSSM124F		More	3.3×3.0×0.75			20	2.9			0.133	0.075			0.53	115
						20	3.2			0.189	0.718			2.4	115
						20	2.2			0.700	0.299			0.75	115
					B	9	2.9			0.307	0.315			2.9	115
					G	15	3.2			0.307	0.315
					R	17	2.2			0.307	0.315
NSSM124D		More	3.3×3.0×0.75			20	2.9			0.133	0.075			0.5	115
						20	3.2			0.189	0.718			2.2	115
						20	2.2			0.700	0.299			0.75	115
					B	9	2.9			0.307	0.315			2.8	115
					G	15	3.2			0.307	0.315
					R	17	2.2			0.307	0.315
NESM238B		More	4.7×1.6×1.3			20	3.2			0.133	0.075			0.33	115
						20	3.4			0.189	0.718			1.8	115
						20	2.2			0.700	0.299			0.87	115
					B	8	3.2			0.307	0.315			2.0	115
					G	16	3.4			0.307	0.315
					R	12	2.2			0.307	0.315
NESM238A		More	4.7×1.6×1.3			20	3.2			0.133	0.075			0.33	115
						20	3.4			0.189	0.718			1.8	115
						20	2.2			0.700	0.299			0.87	115
					B	8	3.2			0.307	0.315			2.0	115
					G	16	3.4			0.307	0.315
					R	12	2.2			0.307	0.315
NSDW510GS-K1			Round 5			70	3.4			0.31	0.32	25.5		27.5	35
NSDW570GS-K1			Round 5			70	3.4			0.31	0.32	28			140
NSPW500GS-K1			Round 5			20	3.1			0.31	0.32			33	15
NSPW500DS			Round 5			20	3.2			0.31	0.32			27	15
NSPL500DS			Round 5			20	3.2			0.41	0.39			22	15
NSPW510DS-D1			Round 5			20	3.2			0.31	0.32			12.2	30
NSPW510DS			Round 5			20	3.2			0.31	0.32			6.15	45
NSPL510DS			Round 5			20	3.2			0.41	0.39			4.7	50
NSPW570DS			Round 5			20	3.2			0.31	0.32			1.7	120
NSPW515DS			Round 5			20	3.2			0.31	0.32			2.3	65
NSPL515DS			Round 5			20	3.2			0.41	0.39			1.9	70
NSPW300DS			Round 3.1			20	3.2			0.31	0.32			12.9	20
NSPW310DS			Round 3.1			20	3.2			0.31	0.32			6.2	50
NSPW315DS			Round 3.1			20	3.2			0.31	0.32			3.4	60
NSPB500AS			Round 5			20	3.2			0.133	0.075			9.3	15
NSPG500DS			Round 5			20	3.2			0.17	0.70			37.7	15
NSPA500BS			Round 5			20	3.1			0.560	0.435			19.5	13
NSPB510BS			Round 5			20	3.1			0.133	0.075			4.7	30
NSPG510BS			Round 5			20	3.2			0.17	0.70			16	30
NEPE510JS			Round 5			10	3.1			0.085	0.490			6.3	30
NSPE510DS			Round 5			10	3.5			0.085	0.490			5.2	30
NSPA510BS			Round 5			20	3.1			0.560	0.435			7.8	30
NSPR510GS			Round 5			20	2.1			0.700	0.299			6.8	30
NSPB300B			Round 3.1			20	3.2			0.133	0.075			6.55	15
NSPG300D			Round 3.1			20	3.2			0.17	0.70			36.1	15
NSPB310B			Round 3.1			20	3.2			0.133	0.075			2.5	30
NSPG310B			Round 3.1			20	3.2			0.17	0.70			10.8	30
NSPR310S			Round 3.1			20	2.1			0.700	0.299			4.5	30
NESM180A			1.8×1.8×0.85			10	2.9			0.133	0.075			0.045	105
						20	3.5			0.189	0.718			0.44	105
						20	2.1			0.700	0.299			0.28	105
NESM526A			2.1×2.1×0.9			20	3.1			0.133	0.075			0.15	110
						20	3.4			0.189	0.718			0.7	110
						20	2.15			0.696	0.303			0.465	110
NESM026D			3.0×3.0×1.8			20	3.2			0.133	0.075			0.3	115
						20	3.5			0.189	0.718			1.2	115
						20	2.15			0.700	0.299			0.7	115
NSSM332B			2.8×2.8×2.5			20	2.90			0.133	0.075			0.34	110/105
						20	3.30			0.189	0.718			1.95	110/105
						20	2.15			0.696	0.303			0.85	110/105
NSSM432A			2.8×2.8×2.5			20	2.90			0.133	0.075			0.47	110
						20	3.30			0.189	0.718			2.35	110
						20	2.15			0.696	0.303			1.0	110
NSSM228A			3.2×1.35×1.5			20	3.10			0.133	0.075			0.5	115
						20	3.10			0.189	0.718			2.4	115
						20	3.10			0.696	0.303			1.0	115
NSPBV13AS			Oval 3.9×3.1			20	2.9			0.133	0.075			4.6	28
NSPGV13AS			Oval 3.9×3.1			20	3.3			0.189	0.718			21	28
NSPRV13AS			Oval 3.9×3.1			20	2.15			0.696	0.303			9.2	28
NSPB336GS			Oval 3.9×3.0			20	2.9			0.133	0.075			1.5	90/43
NSPG336GS			Oval 3.9×3.0			20	3.3			0.189	0.718			7.2	90/43
NSPR336GS			Oval 3.9×3.0			20	2.15			0.696	0.303			2.9	90/43
NSPB336DS			Oval 3.9×3.0			20	2.9			0.133	0.075			1.4	90/45
NSPG336DS			Oval 3.9×3.0			20	3.3			0.189	0.718			6.5	90/45
NSPR336DS			Oval 3.9×3.0			20	2.15			0.696	0.303			2.6	90/45
NSPB346MS			Oval 3.9×3.0			20	2.9			0.133	0.075			0.95	110/65
NSPG346MS			Oval 3.9×3.0			20	3.2			0.189	0.718			4.0	110/65
NSPR346MS			Oval 3.9×3.0			20	2.15			0.696	0.303			1.7	110/65
NJSW170F			1.6×1.2×0.75			650	3.25			0.322	0.335	260			120
NJSW170F-SA			1.6×1.2×0.75			650	3.25			0.322	0.335	240			120
NJSA170F			1.6×1.2×0.75			650	3.25			0.57	0.42	170			120
NJSW170D		More	1.6×1.2×0.75			650	3.25			0.322	0.335	225			120
NJSW170D		More	1.6×1.2×0.75			650	3.25			0.286	0.240	168			120
NCSW170F			1.8×1.45×0.75			1000	3.25			0.3292	0.3439	410			120
NCSW170F-SA			1.8×1.45×0.75			1000	3.25			0.3292	0.3439	380			120
NCSE170F			1.8×1.45×0.75			1000	3.9			0.132	0.379	220			120
NCSG170F			1.8×1.45×0.75			1000	3.9			0.170	0.723	315			120
NCSY170F			1.8×1.45×0.75			1000	3.25			0.48	0.50	370			120
NCSA170F			1.8×1.45×0.75			1000	3.25			0.57	0.42	280			120
NCSR170F			1.8×1.45×0.75			1000	3.25			0.665	0.328	111			120
						1000	3.25			0.667	0.323	80			120
						1000	3.25			0.682	0.311	50			120
						1000	3.25			0.691	0.299	38			120
NC2W170F			1.6×3×0.75			1000	6.6			0.3292	0.3439	820			120
NC2A170F			1.6×3×0.75			1000	6.6			0.57	0.42	560			120
NCSW170D		More	1.8×1.45×0.75			1000	3.25			0.3292	0.3439	390			120
NCSW170D		More	1.8×1.45×0.75			1000	3.25			0.286	0.240	300			120
NCSW170D-PCA		More	1.8×1.45×0.75			1000	3.25			0.3292	0.3439	350			120
NCSW170D-PCA		More	1.8×1.45×0.75			1000	3.25			0.286	0.240	270			120
NCSW170D-PCB			1.8×1.45×0.75			1000	3.25			0.3292	0.3439	370			120
NCSA170D			1.8×1.45×0.75			1000	3.25			0.57	0.42	265			120
NC2W170D			3×1.6×0.75			1000	6.6			0.3292	0.3439	780			120
NC2A170D			3×1.6×0.75			1000	6.6			0.57	0.42	530			120
NCSW131F			1.8×1.45×0.75			1000	3.25			0.3292	0.3439	410			120
NCSW131F-SA			1.8×1.45×0.75			1000	3.25			0.3292	0.3439	380			120
NCSE131F			1.8×1.45×0.75			1000	3.9			0.132	0.379	220			120
NCSG131F			1.8×1.45×0.75			1000	3.9			0.170	0.723	315			120
NCSY131F			1.8×1.45×0.75			1000	3.25			0.48	0.50	370			120
NCSA131F			1.8×1.45×0.75			1000	3.25			0.57	0.42	280			120
NCSR131F			1.8×1.45×0.75			1000	3.25			0.665	0.328	111			120
						1000	3.25			0.667	0.323	80			120
						1000	3.25			0.682	0.311	50			120
						1000	3.25			0.691	0.299	38			120
NC2W131F			1.6×3×0.75			1000	6.6			0.3292	0.3439	820			120
NC2A131F			3×1.6×0.75			1000	6.6			0.57	0.42	560			120
NCSW131D			1.8×1.45×0.75			1000	3.25			0.3292	0.3439	390			120
NCSW131D-PCA			1.8×1.45×0.75			1000	3.25			0.3292	0.3439	350			120
NCSA131D			1.8×1.45×0.75			1000	3.25			0.57	0.42	265			120
NC2W131D			3×1.6×0.75			1000	6.6			0.3292	0.3439	780			120
NC2A131D			3×1.6×0.75			1000	6.6			0.57	0.42	530			120
NC2W121F			2.6×3.1×0.75			1000	6.5			0.3292	0.3439	820			120
NC3W121F			3.75×3.1×0.75			1000	9.75			0.3292	0.3439	1,230			120
NC4W121F			4.9×3.1×0.75			1000	13.0			0.3292	0.3439	1,640			120
NC5W121F			6.05×3.1×0.75			1000	16.25			0.3292	0.3439	2,050			120
NC2W121D			3.1×2.6×0.75			1000	6.5			0.3292	0.3439	780			120
NC3W121D			3.1×3.75×0.75			1000	9.8			0.3292	0.3439	1,170			120
NC4W121D			3.1×4.9×0.75			1000	13.0			0.3292	0.3439	1,560			120
NC5W121D			3.1×6.05×0.75			1000	16.3			0.3292	0.3439	1,950			120
NC2W121D-S1			2.6×3.1×0.75			1000	6.5			0.3292	0.3439	740			120
NC3W121D-S1			3.1×3.75×0.75			1000	9.8			0.3292	0.3439	1,110			120
NC4W121D-S1			3.1×4.9×0.75			1000	13.0			0.3292	0.3439	1,480			120
NC5W121D-S1			3.1×6.05×0.75			1000	16.3			0.3292	0.3439	1,850			120
NCSW193F			11.8×8×1.7			1000	3.25			0.3292	0.3439	410			120
NC2W193F			11.8×8×1.7			1000	6.5			0.3292	0.3439	820			120
NC3W193F			11.8×8×1.7			1000	9.75			0.3292	0.3439	1,230			120
NC4W193F			11.8×8×1.7			1000	13.0			0.3292	0.3439	1,640			120
NC5W193F			11.8×8×1.7			1000	16.25			0.3292	0.3439	2,050			120
NC2W093B			8.5×8×1.5			1200	6.6			0.3292	0.3439	860			120
NC3W093B			8.5×8×1.5			1200	9.9			0.3292	0.3439	1,290			120
NC4W093B			8.5×8×1.5			1200	13.2			0.3292	0.3439	1,720			120
NC5W093B			8.5×8×1.5			1200	16.5			0.3292	0.3439	2,150			120
NC2W093B-S1			8.5×8×1.5			1200	6.6			0.3292	0.3439	800			120
NC3W093B-S1			8.5×8×1.5			1200	9.9			0.3292	0.3439	1,200			120
NC4W093B-S1			8.5×8×1.5			1200	13.2			0.3292	0.3439	1,600			120
NC5W093B-S1			8.5×8×1.5			1200	16.5			0.3292	0.3439	2,000			120
NC3W093A			8.5×8×1.5			1200	9.9			0.3287	0.3417	1,200			120
NC3W093A			8.5×8×1.5			1200	9.9			0.322	0.335	1,200			120
NC4W093A			8.5×8×1.5			1200	13.2			0.322	0.335	1,600			120
NC4W093A			8.5×8×1.5			1200	13.2			0.3287	0.3417	1,600			120
NC5W093A			8.5×8×1.5			1200	16.5			0.322	0.335	2,000			120
NC5W093A			8.5×8×1.5			1200	16.5			0.3287	0.3417	2,000			120
NCSW321F			3.05×2.8×0.75			1000	3.25			0.3292	0.3439	410			120
NC2W321F			3.5×3.2×0.75			1000	6.5			0.3292	0.3439	820			120
NC3W321F			3.5×4×0.75			1000	9.75			0.3292	0.3439	1,230			120
NC4W321F			3.5×5.1×0.75			1000	13.0			0.3292	0.3439	1,640			120
NC5W321F			3.5×6.1×0.75			1000	16.25			0.3292	0.3439	2,050			120
NC2W321B			3.5×3.2×0.75			1000	6.5			0.327	0.337	730			120
NC3W321B			3.5×4×0.75			1000	9.8			0.327	0.337	1,100			120
NC4W321B			3.5×5.1×0.75			1000	13.0			0.327	0.337	1,460			120
NJ2W270B			3.5×3.5×0.75			1500	7.3			0.322	0.335	800			120
NJ3W270B			3.5×3.5×0.75			1500	11.0			0.322	0.335	1,200			120
NJ2W270B-PF			3.5×3.5×0.75			1500	7.3			0.322	0.335	760			120
NJ3W270B-PF			3.5×3.5×0.75			1500	11.0			0.322	0.335	1,140			120
NV3W470A			8×8×1.35			5000	10.8			0.322	0.335	4,000			120
NLSW03A04A			22×36×5.32			5000	10.8			0.322	0.335	4,000			120
NFSW172C		More	3×3×0.8			150	3.0			0.331	0.338	70			115
NFSW172C		More	3×3×0.8			150	3.0			0.286	0.240	56			115
NFSA172C			3×3×0.8			150	3.0			0.57	0.42	50			115
NFSR172C			3×3×0.8			150	3.0			0.668	0.328	24			115
						150	3.0			0.677	0.320	20			115
						150	3.0			0.688	0.309	12			115
						150	3.0			0.700	0.297	7.0			115
NFSW172B		More	3×3×0.8			150	3.0			0.331	0.338	60			115
NFSW172B		More	3×3×0.8			150	3.0			0.286	0.240	48			115
NFSA172B			3×3×0.8			150	3.0			0.57	0.42	43			115
NJSW172C		More	3×3×0.8			350	3.1			0.331	0.338	155			115
NJSW172C		More	3×3×0.8			350	3.1			0.286	0.240	128			115
NJSA172C			3×3×0.8			350	3.1			0.57	0.42	115			115
NJSR172C			3×3×0.8			350	3.1			0.668	0.328	50			115
						350	3.1			0.677	0.320	40			115
						350	3.1			0.688	0.309	27			115
						350	3.1			0.700	0.297	16			115
NJSW172B		More	3×3×0.8			350	3.1			0.331	0.338	135			115
NJSW172B		More	3×3×0.8			350	3.1			0.286	0.240	106			115
NJSA172B			3×3×0.8			350	3.1			0.57	0.42	100			115
NFSW123G			3×2×0.7			150	3.0			0.331	0.338	65			115
NFSA123G			3×2×0.7			150	3.0			0.57	0.42	50			115
NFSW123F		More	3×2×0.7			150	3.2			0.331	0.338	57			115
						150	3.2			0.286	0.240	45			115
						150	3.2			0.41	0.39	56			115
						150	3.2	80	>0	0.41	0.39	52			115
						150	3.2	90	0	0.41	0.39	44			115
NFSA123F			3×2×0.7			150	3.2			0.57	0.42	39			115
NFSW123D			3×2×0.7			150	3.2			0.331	0.338	51			115
NFSL123D			3×2×0.7			150	3.2			0.41	0.39	49			115
NFSL123D			3×2×0.7			150	3.2	80	>0	0.41	0.39	40			115
NFSA123D			3×2×0.7			150	3.2			0.57	0.42	34			115
NJSW123G			3×2×0.7			350	3.1			0.331	0.338	140			115
NJSA123G			3×2×0.7			350	3.1			0.57	0.42	105			115
NJSW572B			3×3×0.7			150	3.0			0.331	0.338	60			115
NJSA572B			3×3×0.7			150	3.0			0.57	0.42	42			115
NSSW146A-V1			2.2×1.4×0.7			30	3.0			0.31	0.32			3.2	115
NSSW146A		More	2.2×1.4×0.7			30	3.0			0.31	0.32			3.0	115
NSSW146A		More	2.2×1.4×0.7			30	3.0			0.41	0.39			3.0	115
NESW146A			2.2×1.4×0.7			20	3.2			0.31	0.32			1.2	115
NHSW146A			2.2×1.4×0.7			10	3.1			0.31	0.32			0.45	115
NHSW146A-Y1			2.2×1.4×0.7			5	2.9			0.31	0.32			0.25	115
NHSW146AH-PA			2.2×1.4×0.7			5	2.9			0.31	0.32			0.09	115
NHSW146AH			2.2×1.4×0.7			5	2.9			0.31	0.32			0.035	115
NSSB146A			2.2×1.4×0.7			30	3.0			0.133	0.075			0.65	115
NESB146A			2.2×1.4×0.7			20	3.2			0.133	0.075			0.29	115
NHSB146A			2.2×1.4×0.7			10	3.1			0.133	0.075			0.11	115
NHSB146AH			2.2×1.4×0.7			5	2.9			0.133	0.075			0.03	115
NSSC146A			2.2×1.4×0.7			30	3.0			0.156	0.032			0.36	115
NSSG146A			2.2×1.4×0.7			30	3.2			0.17	0.70			2.0	115
NESG146A			2.2×1.4×0.7			20	3.5			0.17	0.70			1.2	115
NHSG146A			2.2×1.4×0.7			10	3.1			0.17	0.70			0.37	115
NSSA146A-V1			2.2×1.4×0.7			30	3.0			0.55	0.44			2.7	115
NSSA146A-V1			2.2×1.4×0.7			30	3.0			0.57	0.42			2.4	115
NSSA146A			2.2×1.4×0.7			30	3.0			0.55	0.44			2.1	115
NSSA146A			2.2×1.4×0.7			30	3.0			0.57	0.42			2.0	115
NESA146A			2.2×1.4×0.7			20	3.2			0.55	0.44			0.98	115
NESA146A			2.2×1.4×0.7			20	3.2			0.57	0.42			0.88	115
NHSA146A			2.2×1.4×0.7			10	3.1			0.55	0.44			0.35	115
NHSA146A			2.2×1.4×0.7			10	3.1			0.57	0.42			0.33	115
NSSB146A-N3			2.2×1.4×0.7			30	3.0			0.19	0.29			2.0	115
NESB146A-N3			2.2×1.4×0.7			20	3.2			0.19	0.29			0.9	115
NHSB146A-N3			2.2×1.4×0.7			10	3.1			0.19	0.29			0.34	115
NHSB146AH-N3			2.2×1.4×0.7			5	2.9			0.19	0.29			0.04	115
NSSB146A-NA			2.2×1.4×0.7			30	3.0			0.19	0.19			1.8	115
NESB146A-NA			2.2×1.4×0.7			20	3.2			0.19	0.19			0.95	115
NHSB146A-NA			2.2×1.4×0.7			10	3.1			0.19	0.19			0.36	115
NHSB146AH-NA			2.2×1.4×0.7			5	2.9			0.19	0.19			0.06	115
NESB146A-ND			2.2×1.4×0.7			20	3.2			0.369	0.595			1.45	115
NHSB146A-ND			2.2×1.4×0.7			10	3.1			0.369	0.595			0.55	115
NESB146A-N8			2.2×1.4×0.7			20	3.2			0.35	0.45			1.6	115
NSSR146A			2.2×1.4×0.7			30	3.0			0.616	0.372			1.5	115
						30	3.0			0.628	0.359			1.2	115
						30	3.0			0.640	0.348			1.0	115
						30	3.0			0.677	0.320			0.55	115
						30	3.0			0.688	0.309			0.4	115
						30	3.0			0.704	0.292			0.24	115
						30	3.0			0.708	0.289			0.18	115
NESR146A			2.2×1.4×0.7			20	3.2			0.616	0.372			0.8	115
						20	3.2			0.628	0.359			0.58	115
						20	3.2			0.640	0.348			0.48	115
						20	3.2			0.677	0.320			0.27	115
						20	3.2			0.688	0.309			0.2	115
						20	3.2			0.704	0.292			0.12	115
						20	3.2			0.708	0.289			0.09	115
NHSR146A			2.2×1.4×0.7			10	3.1			0.616	0.372			0.3	115
						10	3.1			0.628	0.359			0.24	115
						10	3.1			0.640	0.348			0.19	115
						10	3.1			0.677	0.320			0.1	115
						10	3.1			0.688	0.309			0.07	115
						10	3.1			0.704	0.292			0.045	115
						10	3.1			0.708	0.289			0.03	115
NSSW088A			3.5×1.4×1.2			20	3.2			0.31	0.32			1.6	115
NSSW088A			3.5×1.4×1.2			20	3.2			0.28	0.27			1.5	115
NSSL088A			3.5×1.4×1.2			20	3.2			0.41	0.39			1.4	115
NS2W566H-HG			4.2×0.85×0.6			20	5.6			0.277	0.260	18		6.09
NS2W566H-HS			4.2×0.85×0.6			20	5.6			0.277	0.260	17.6		5.97
NJ2W257KR-HG			4×1.4×0.6			120	5.86			0.277	0.260	98.0		32.1
NSSW506H-HG			3×0.85×0.6			20	2.8			0.277	0.260	9.2		3.07
NSSW506H-HS			3×0.85×0.6			20	2.8			0.277	0.260	9.0		3.0
NS2W765F-HG			3.1×0.65×0.5			22	5.6			0.277	0.260	18.2		5.84	120
NS2W765F-HS			3.1×0.65×0.5			22	5.6			0.277	0.260	17.8		5.78
NS2W765D-HS			3.1×0.65×0.5			22	5.6			0.277	0.260	17.3		5.52
NS2W765D-HG			3.1×0.65×0.5			22	5.6			0.277	0.260	17.7		5.66	120
NS2W764F-HG			3.1×0.7×0.4			22	5.6			0.277	0.260	16.6		5.44	120
NS2W763F-HG			3.1×0.65×0.3			22	5.6			0.277	0.260	15.6		4.99	120
NF2W158B-HG			3×1.4×0.6			120	2.8			0.277	0.260	47.5
NS2W266G-HG			4.2×1×0.6			20	5.65			0.277	0.260	16.3		5.53	120
NS2W266G			4.2×1×0.6			20	5.65			0.290	0.275	17		5.71	120
NSSW306G-HS			3×0.85×0.6			20	2.82			0.283	0.270	8.67		2.91
NSSW306G-HG			3×0.85×0.6			20	2.82			0.283	0.270	8.85		2.97	120
NSSW306G			3×0.85×0.6			20	2.82			0.290	0.275	9.5		3.15	120
NSSW304H-HG			3×0.85×0.4			20	2.9			0.292	0.270	7.97		2.63	120
NSSW304G-HG			3×0.85×0.4			20	3.0			0.292	0.270	7.2		2.37	120
NSSW304G			3×0.85×0.4			20	3.0			0.290	0.275	8.3		2.7	120
NFSW157K-HG			3×1.4×0.6			80	2.9			0.277	0.260	34		11.1	120
NJSW157K-HG			3×1.4×0.6			120	2.93			0.277	0.260	49.5		16.2	120
NFSW157K			3×1.4×0.6			80	2.9			0.290	0.275	37.1		12.1	120
NJSW157K			3×1.4×0.6			120	2.93			0.290	0.275	55.0		18	120
NFSW157J-HG			3×1.4×0.6			80	2.95			0.277	0.260	33		11	120
NJSW157J-HG			3×1.4×0.6			120	3.0			0.277	0.260	48.5		16	120
NFSW157J			3×1.4×0.6			80	2.95			0.290	0.275	36		11.8	120
NJSW157J			3×1.4×0.6			120	3.0			0.290	0.275	53.5		17.5	120
NSSW157H-HG			3×1.4×0.52			80	3.0			0.277	0.260	31.5		10.3	120
NFSW157H-HG			3×1.4×0.52			120	3.0			0.277	0.260	46		15.1	120
NSSW157H			3×1.4×0.52			80	3.0			0.290	0.275	34.5		11.3	120
NFSW157H			3×1.4×0.52			120	3.0			0.290	0.275	51		16.7	120

UV-LED (Products：32 Results)

Compare Clear

Part No.	Production Status	Spec.	Size L×W×H (mm)	Color	Peak Wevelength	Radiant Flux Typ(mW)	V_F Typ(V)		Directivity (degree)	I_F (mA)
Part No.	Production Status	Spec.	Size L×W×H (mm)	Color	Peak Wevelength	Radiant Flux Typ(mW)	Typ.(V)	Max(V)	Directivity (degree)	I_F (mA)
NC4U334BR (280nm)			6.8×6.8×2.1		280	200	22.5	25.	110	350
NCSU334B (280nm)			6.8×6.8×2.1		280	70	5.5	6.5	115	350
NCSU434B (280nm)			3.5×3.5×1.72		280	62	5.7	6.5	110	350
NCSU434A (280nm)			3.5×3.5×1.72		280	17.5	5.3	6.0	110	100
NWSU333B-D4 (367nm)			6.8×6.8×4.6		367	4900	3.85	4.2	60	3500
NWSU333B (365nm)			6.8×6.8×1.9		365	4900	3.85	4.2	120	3500
NWSU333B (385nm)			6.8×6.8×1.9		385	5500	3.70	4.2	120	3500
NVSU233B (365nm)			3.5×3.5×1.23		365	1450	3.85	4.2	120	1000
NVSU233B (385nm)			3.5×3.5×1.23		385	1730	3.70	4.2	120	1000
NVSU233B (395nm)			3.5×3.5×1.23		395	1650	3.65	4.2	120	1000
NVSU233B-D4 (365nm)			3.5×3.5×2.73		365	1450	3.85	4.2	60	1000
NVSU233B-D4 (385nm)			3.5×3.5×2.73		385	1730	3.70	4.2	60	1000
NVSU233B-D4 (395nm)			3.5×3.5×2.73		395	1650	3.65	4.2	60	1000
NVSU233B-D4 (405nm)			3.5×3.5×2.73		405	1400	3.45	4.2	60	1000
NVSU233C (405nm)			3.5×3.5×1.23		405	1610	3.6	4.0	120	1000
NCSU033C (365nm)			6.8×6.8×1.9		365	750	3.8	4.4	115	500
NCSU034C (385nm)			6.8×6.8×1.9		385	830	3.55	4.3	115	500
NCSU035D (405nm)			6.8×6.8×1.9		405	860	3.35	3.9	115	500
NCSU276C (365nm)			3.5×3.5×2		365	1050	3.8	4.4	120	500
NVSU119C (375nm)			3.5×3.5×2		375	1160	3.40	3.8	135	700
NVSU119C (385nm)			3.5×3.5×2		385	1450	3.35	3.8	135	700
NVSU119C (395nm)			3.5×3.5×2		395	1450	3.30	3.8	135	700
NVSU119C (405nm)			3.5×3.5×2		405	1420	3.1	3.8	140	700
NVSU219C (405nm)			3.5×3.5×2		405	1420	3.1	3.6	140	700
NSSU123 (375nm)			3×2×0.7		375	17.6	3.3	4	125	20
NSSU100C (365nm)			3×2×1.2		365	4.8	3.4	4	110	20
NSSU100D (375nm)			3×2×1.2		375	9.9	3.3	4	110	20
NSPU510CS (375nm)			Round 5		375	15.1	3.3	4	40	15
NSHU551C (365nm)			Round 4.7		365	5.4	3.4	4	110	20
NSHU551C (375nm)			Round 4.7		375	12.3	3.3	4	110	20
NSHU591C (365nm)			Round 4.7		365	4	3.4	4	10	20
NSHU591C (375nm)			Round 4.7		375	9	3.3	4	10	20
NSHU591C (375nm)			Round 4.7		375	9	3.3	4	10	20
