製品検索

用途	：	照明
		(ダウンライト)

LED (該当製品：189 件)

製品比較クリア

詳細表示

型番	生産状況	仕様書	製品寸法 L×W×H (mm)	色	I_F (mA)	順電圧 Typ(V)	CRI		色度座標		光束 Typ(lm)	放射束 Typ(mW)	光度 Typ(cd)	指向特性 (degree)
型番	生産状況	仕様書	製品寸法 L×W×H (mm)	色	I_F (mA)	順電圧 Typ(V)	Ra Min	R9 Min	X	Y	光束 Typ(lm)	放射束 Typ(mW)	光度 Typ(cd)	指向特性 (degree)
NFSW757H-V2H5			3×3×0.8		65	2.82	80	20	0.3447	0.3553	38.6			120
NFSW757H-V2H5			3×3×0.8		65	2.82	80	20	0.4338	0.4030	37			120
NFSW757H-V2H6 (Ra≥95, R9>80, TLCI90+)			3×3×0.8		65	2.82	95	80	0.3447	0.3553	32.9			120
NFSW757H-V2H6 (Ra≥95, R9>80, TLCI90+)			3×3×0.8		65	2.82	95	80	0.4338	0.4030	28.5			120
NFSW757H-V2H6 (H6 Series)			3×3×0.8		65	2.82	90	50	0.3447	0.3553	37			120
NFSW757H-V2H6 (H6 Series)			3×3×0.8		65	2.82	90	50	0.4338	0.4030	35.8			120
NFSW757H-V1H6 (Clear White color)			3×3×0.8		65	2.84	90	50	0.3002	0.2950	33.8			120
NFSW757H-V1H6 (H6 Series)			3×3×0.8		65	2.84	90	50	0.3447	0.3553	36.9			120
NFSW757H-V1H6 (H6 Series)			3×3×0.8		65	2.84	90	50	0.4338	0.4030	35.2			120
NFSW757H-V1			3×3×0.8		65	2.84	70		0.3447	0.3553	39.5			120
					65	2.84	80	>0	0.3447	0.3553	37.9			120
					65	2.84	90	50	0.3447	0.3553	32.6			120
					65	2.84	70		0.4338	0.4030	37.7			120
					65	2.84	80	>0	0.4338	0.4030	35.6			120
					65	2.84	90	50	0.4338	0.4030	29.8			120
NF2W757H-V2H5			3×3×0.8		65	2.71	80	50	0.3447	0.3553	39			120
NF2W757H-V2H5			3×3×0.8		65	2.71	80	50	0.4338	0.4030	37.5			120
NF2W757H-V2H6 (H6 Series)			3×3×0.8		65	2.71	90	50	0.3447	0.3553	37			120
NF2W757H-V2H6 (H6 Series)			3×3×0.8		65	2.71	90	50	0.4338	0.4030	35.8			120
NF2W757H-V2F1			3×3×0.8		65	2.72	70		0.3447	0.3553	40.3			120
					65	2.72	80	>0	0.3447	0.3553	38.9			120
					65	2.72	70		0.4338	0.4030	38.6			120
					65	2.72	80	>0	0.4338	0.4030	36.2			120
NF2W757H-F1			3×3×0.8		65	2.72	70		0.3447	0.3553	39.6			120
					65	2.72	80	>0	0.3447	0.3553	38.1			120
					65	2.72	90	50	0.3447	0.3553	32.8			120
					65	2.72	70		0.4338	0.4030	38.3			120
					65	2.72	80	>0	0.4338	0.4030	35.8			120
					65	2.72	90	50	0.4338	0.4030	29.8			120
NF2E757H-F1			3×3×0.8		65	2.74			0.188	0.268	29.5			120
NF2W757GR-V5H6 (H6 Series)			3×3×0.65		150	6.2	90	50	0.3447	0.3553	154			120
NF2W757GR-V5H6 (H6 Series)			3×3×0.65		150	6.2	90	50	0.4338	0.4030	145			120
NF2W757GR-V5			3×3×0.65		150	6.2	70		0.3447	0.3553	166			120
					150	6.2	80	>0	0.3447	0.3553	155			120
					150	6.2	70		0.4338	0.4030	160			120
					150	6.2	80	>0	0.4338	0.4030	146			120
NF2W757GR-V4H6 (Clear White color)			3×3×0.65		150	6.2	90	50	0.3002	0.2950	139			120
NF2W757GR-V4H6 (H6 Series)			3×3×0.65		150	6.2	90	50	0.3447	0.3553	151			120
NF2W757GR-V4H6 (H6 Series)			3×3×0.65		150	6.2	90	50	0.4338	0.4030	143			120
NF2W757GR-V4			3×3×0.65		150	6.2	70		0.3447	0.3553	164			120
					150	6.2	80	>0	0.3447	0.3553	153			120
					150	6.2	90	50	0.3447	0.3553	136			120
					150	6.2	70		0.4338	0.4030	158			120
					150	6.2	80	>0	0.4338	0.4030	144			120
					150	6.2	90	50	0.4338	0.4030	126			120
NFSW757G-P5H5			3×3×0.65		65	2.89	80	20	0.3447	0.3553	35.6			120
NFSW757G-P5H5			3×3×0.65		65	2.89	80	20	0.4338	0.4030	32.8			120
NFSW757G-P5V1			3×3×0.65		65	2.89	80	>0	0.3447	0.3553	35.3			120
					65	2.89	90	50	0.3447	0.3553	29.6			120
					65	2.89	80	>0	0.4338	0.4030	32.8			120
					65	2.89	90	50	0.4338	0.4030	27.8			120
NFSW757G-P5H6 (H6 Series)			3×3×0.65		65	2.89	90	50	0.3447	0.3553	34.7			120
NFSW757G-P5H6 (H6 Series)			3×3×0.65		65	2.89	90	50	0.4338	0.4030	32.6			120
NFSW757G-P5H6 (TLCI90+)			3×3×0.65		65	2.89	90	50	0.3447	0.3553	33.8			120
NFSW757G-P5H6 (TLCI90+)			3×3×0.65		65	2.89	90	50	0.4338	0.4030	29.7			120
NF2W757G-MT (Tunable White. CRI 90)			3×3×0.75		65	2.84	90	50	0.3123	0.3282	27.5			120
NF2W757G-MT (Tunable White. CRI 90)			3×3×0.75		65	2.84	90	50	0.4578	0.4101	26.5			120
NF2W757G-MT (Tunable White. CRI 80)			3×3×0.75		65	2.84	80	>0	0.3123	0.3282	32			120
NF2W757G-MT (Tunable White. CRI 80)			3×3×0.75		65	2.84	80	>0	0.4578	0.4101	31			120
NF2W757G-V3F1			3×3×0.65		65	2.73	70		0.3447	0.3553	38.8			120
					65	2.73	80	>0	0.3447	0.3553	37.3			120
					65	2.73	90	50	0.3447	0.3553	32.3			120
					65	2.73	70		0.4338	0.4030	37.5			120
					65	2.73	80	>0	0.4338	0.4030	35.3			120
					65	2.73	90	50	0.4338	0.4030	29.4			120
NF2W757G-V3F1 (Vitasolis)			3×3×0.65		65	2.73	80	>0	0.3447	0.3553	35.6			120
NF2W757G-V3F1 (Vitasolis)			3×3×0.65		65	2.73	80	>0	0.4338	0.4030				120
NF2L757G-F1 (R95)			3×3×0.65		65	2.76	95		0.4338	0.4030	24.1			120
NF2L757G-F1 (Optisolis)			3×3×0.65		65	2.76	95	80	0.4338	0.4030	24.1			120
NF2W757G-F1 (R95)			3×3×0.65		65	2.76	95		0.3447	0.3553	26.8			120
NF2W757G-F1 (Optisolis)			3×3×0.65		65	2.9	95	85	0.3447	0.3553	23			120
NF2L757GR-V1（R95）			3×3×0.65		150	6.3	95		0.4338	0.4030	100			120
NF2W757GR-V1（R95）			3×3×0.65		150	6.3	95		0.3447	0.3553	110			120
NFSW757G-V3			3×3×0.65		65	2.85	70		0.3447	0.3553	38.4			120
					65	2.85	80	>0	0.3447	0.3553	37			120
					65	2.85	90	50	0.3447	0.3553	31.8			120
					65	2.85	70		0.4338	0.4030	36.6			120
					65	2.85	80	>0	0.4338	0.4030	34.8			120
					65	2.85	90	50	0.4338	0.4030	29			120
NFSW757G-V3 (Rs020)			3×3×0.65		65	2.85			0.336	0.335	22.1			120
NFSW757G-V3 (Rs030)			3×3×0.65		65	2.85			0.3447	0.3553	22.3			120
NFSW757G-V3 (Rs030)			3×3×0.65		65	2.85			0.4338	0.4030	18.9			120
NFSW757G-V3 (Rs060)			3×3×0.65		65	2.85			0.336	0.301	14.5			120
NFSW757G-V3 (Rs060) Hortisolis			3×3×0.65		65	2.85			0.336	0.301	14.5			120
NFSW757H-V1 (Rs060)			3×3×0.8		65	2.84			0.336	0.301	14.9			120
NFSW757H-V1 (Rs060) Hortisolis			3×3×0.8		65	2.84			0.336	0.301				120
NFSW757G (R95)			3×3×0.65		65	2.88	95		0.3447	0.3553	26			120
NFSL757G (R95)			3×3×0.65		65	2.88	95		0.4338	0.4030	23.3			120
NFSL757G (Rs075)			3×3×0.65		65	2.88	90		0.4286	0.3919	27.4			120
NF2L757GR-V1U4			3×3×0.65		37.5	24.8	70		0.4338	0.4030	122			120
					37.5	24.8	80	>0	0.4338	0.4030	116			120
					37.5	24.8	90	50	0.4338	0.4030	98			120
NF2W757GR-V1U4			3×3×0.65		37.5	24.8	70		0.3447	0.3553	129			120
					37.5	24.8	80	>0	0.3447	0.3553	125			120
					37.5	24.8	90	50	0.3447	0.3553	107			120
NFSWL11A-D6			1.1×1.1×1.24		65	2.8	80	>0	0.3447	0.3553	32.5			>180
					65	2.8	90	50	0.3447	0.3553	28.5			>180
					65	2.8	80	>0	0.4338	0.4030	30.1			>180
					65	2.8	90	50	0.4338	0.4030	26.7			>180
NFSWE11A-V1			1.1×1.1×0.27～0.35		65	2.8	70		0.3447	0.3553	33.3			120
					65	2.8	80	>0	0.3447	0.3553	31			120
					65	2.8	90	50	0.3447	0.3553	26.4			120
					65	2.8	90	80	0.3447	0.3553	25.2			120
					65	2.8	70		0.4338	0.4030	31.7			120
					65	2.8	80	>0	0.4338	0.4030	28.7			120
					65	2.8	90	50	0.4338	0.4030	24.4			120
					65	2.8	90	80	0.4338	0.4030	21.4			120
NFSBE11A-V1L1 (Blue)			1.1×1.1×0.35		65	2.83			0.126	0.078	9.5			120
NFSGE11A-V1 (Green)			1.1×1.1×0.35		65	2.8			0.252	0.651	41.9			120
NFSRE11A-V1 (Brilliant Red)			1.1×1.1×0.35		65	2.8			0.669	0.328	11.5			120
NFSRE11A-V1 (Red)			1.1×1.1×0.35		65	2.8			0.683	0.313	6.5			120
NFSWE11A			1.1×1.1×0.27～0.35		65	2.8	90	80	0.3123	0.3282	25			120
					65	2.8	70		0.3447	0.3553	32.1			120
					65	2.8	80	0	0.3447	0.3553	29.4			120
					65	2.8	90	50	0.3447	0.3553	25.5			120
					65	2.8	70		0.4338	0.4030	30.6			120
					65	2.8	80	0	0.4338	0.4030	27.7			120
					65	2.8	90	50	0.4338	0.4030	23.6			120
					65	2.8	90	80	0.4338	0.4030	20.7			120
NCSWE13A-V1			1.25×1.25×0.27～0.35		350	2.95	80	>0	0.3447	0.3553	146			120
					350	2.95	90	50	0.3447	0.3553	130			120
					350	2.95	90	80	0.3447	0.3553	118			120
					350	2.95	80	>0	0.4338	0.4030	134			120
					350	2.95	90	50	0.4338	0.4030	118			120
					350	2.95	90	80	0.4338	0.4030	100			120
NCSWE17A-V1			1.7×1.7×0.27～0.35		350	2.95	70		0.3447	0.3553	173			120
					350	2.95	80	>0	0.3447	0.3553	163			120
					350	2.95	90	50	0.3447	0.3553	137			120
					350	2.95	90	80	0.3447	0.3553	127			120
					350	2.95	70		0.4338	0.4030	165			120
					350	2.95	80	>0	0.4338	0.4030	147			120
					350	2.95	90	50	0.4338	0.4030	125			120
					350	2.95	90	80	0.4338	0.4030	110			120
NCSWE17A-V1 (Rs060)			1.7×1.7×0.3		350	2.95			0.336	0.301	65			120
NCSWE17A-V1 (Rs060) Hortisolis			1.7×1.7×0.3		350	2.95			0.336	0.301				120
NCSLE17A			1.7×1.7×0.27~0.35		350	3.0	70		0.4338	0.4030	161			120
					350	3.0	80	>0	0.4338	0.4030	143			120
					350	3.0	90	50	0.4338	0.4030	120			120
					350	3.0	90	80	0.4338	0.4030	107			120
NCSWE17A			1.7×1.7×0.27		350	3.0	70		0.3447	0.3553	165			120
					350	3.0	80	>0	0.3447	0.3553	158			120
					350	3.0	90	50	0.3447	0.3553	133			120
					350	3.0	90	80	0.3447	0.3553	123			120
NCSAE17A-V1 (Amber)			1.7×1.7×0.35		350	2.95			0.567	0.419	131			120
NCSAE17A (Amber)			1.7×1.7×0.35		350	3.0			0.567	0.419	124			120
NCSBE17A (Blue)			1.7×1.7×0.35		350	3.0			0.126	0.078	42			130
NCSCE17A (Royal Blue)			1.7×1.7×0.35		350	3.0			0.157	0.021	18			130
NCSEE17A-V1 (Azure)			1.7×1.7×0.35		350	2.95			0.188	0.268	137			120
NCSEE17A (Azure)			1.7×1.7×0.35		350	3.0			0.188	0.268	132			120
NCSEE17A-V1L1 (Bluish Green)			1.7×1.7×0.35		350	2.6			0.095	0.565	126			130
NCSGE17A-V1L1 (Green)			1.7×1.7×0.35		350	2.55			0.168	0.729	175			130
NCSGE17A-V1 (Green)			1.7×1.7×0.35		350	2.95			0.252	0.651	221			120
NCSGE17A (Green)			1.7×1.7×0.35		350	3.0			0.252	0.651	208			120
NCSGE17A-V1 (Lime)			1.7×1.7×0.35		350	2.95			0.4140	0.5430	225			120
NCSGE17A (Lime)			1.7×1.7×0.35		350	3.0			0.4140	0.5430	212			120
NCSRE17A-V1 (Brilliant Red)			1.7×1.7×0.35		350	2.95			0.669	0.328	60			120
NCSRE17A (Brilliant Red)			1.7×1.7×0.35		350	3.0			0.669	0.328	58			120
NCSRE17A-V1 (Red)			1.7×1.7×0.35		350	2.95			0.683	0.313	32			120
NCSRE17A-V1 (Deep Red)			1.7×1.7×0.35		350	2.95			0.691	0.301	24			120
NCSRE17A (Red)			1.7×1.7×0.35		350	3.0			0.683	0.313	31			120
NVSWE21A-V1			2.1×2.1×0.27～0.35		700	2.95	70		0.3447	0.3553	336			120
					700	2.95	80	>0	0.3447	0.3553	317			120
					700	2.95	90	50	0.3447	0.3553	273			120
					700	2.95	90	80	0.3447	0.3553	252			120
					700	2.95	70		0.4338	0.4030	323			120
					700	2.95	80	>0	0.4338	0.4030	292			120
					700	2.95	90	50	0.4338	0.4030	246			120
					700	2.95	90	80	0.4338	0.4030	216			120
NVSLE21A			2.1×2.1×0.27~0.35		700	3.0	70		0.4338	0.4030	314			120
					700	3.0	80	>0	0.4338	0.4030	284			120
					700	3.0	90	50	0.4338	0.4030	229			120
					700	3.0	90	80	0.4338	0.4030	214			120
NVSWE21A			2.1×2.1×0.27		700	3.0	70		0.3447	0.3553	327			120
					700	3.0	80	>0	0.3447	0.3553	307			120
					700	3.0	90	50	0.3447	0.3553	265			120
					700	3.0	90	80	0.3447	0.3553	245			120
NFMW488AR-V1			6.5×5.8×0.8		200	44.8	90	50	0.3447	0.3553	1186			120
					200	44.8	70		0.3447	0.3553	1416			120
					200	44.8	80	0	0.3447	0.3553	1325			120
					200	44.8	90	50	0.4338	0.4030	1091			120
					200	44.8	70		0.4338	0.4030	1390			120
					200	44.8	80	0	0.4338	0.4030	1265			120
NFMW481AR			6.5×5.8×0.8		200	22.9	70		0.3447	0.3553	690			120
					200	22.9	80	>0	0.3447	0.3553	640			120
					200	22.9	90	50	0.3447	0.3553	560			120
					200	22.9	70		0.4338	0.4030	670			120
					200	22.9	80	>0	0.4338	0.4030	610			120
					200	22.9	90	50	0.4338	0.4030	530			120
NFMW484AR			6.5×5.8×0.8		200	32.8	70		0.3447	0.3553	970			120
					200	32.8	80	>0	0.3447	0.3553	900			120
					200	32.8	90	50	0.3447	0.3553	800			120
					200	32.8	70		0.4338	0.4030	950			120
					200	32.8	80	>0	0.4338	0.4030	870			120
					200	32.8	90	50	0.4338	0.4030	750			120
NFMW486AR			6.5×5.8×0.8		200	39.3	70		0.3447	0.3553	1130			120
					200	39.3	80	>0	0.3447	0.3553	1060			120
					200	39.3	90	50	0.3447	0.3553	960			120
					200	39.3	70		0.4338	0.4030	1100			120
					200	39.3	80	>0	0.4338	0.4030	1030			120
					200	39.3	90	50	0.4338	0.4030	890			120
NFMW488AR			6.5×5.8×0.8		200	45.9	70		0.3447	0.3553	1320			120
					200	45.9	80	>0	0.3447	0.3553	1240			120
					200	45.9	90	50	0.3447	0.3553	1110			120
					200	45.9	70		0.4338	0.4030	1280			120
					200	45.9	80	>0	0.4338	0.4030	1190			120
					200	45.9	90	50	0.4338	0.4030	1030			120
NF4W585AM-V1			4×3.6×2.05		100	5.49	70		0.3447	0.3553	120.5			140/140
					100	5.49	80	>0	0.3447	0.3553	111.7			140/140
					100	5.49	70		0.4338	0.4030	115.1			140/140
					100	5.49	80	>0	0.4338	0.4030	102.9			140/140
NF3W585AR-V1			4×3.6×2.05		50	8.36	70		0.3447	0.3553	91.5			135/135
					50	8.36	80	>0	0.3447	0.3553	84.9			135/135
					50	8.36	70		0.4338	0.4030	87.4			135/135
					50	8.36	80	>0	0.4338	0.4030	78.7			135/135
NF2W585AR-P8 (Disinfection)			4×3.6×2.05		75	6.21	80	>0	0.4073	0.3917	53			125/115
					75	6.21	80	>0	0.3447	0.3553	53			125/115
					75	6.21	80	>0	0.3818	0.3797	53			125/115
NF2W585AR			4×3.6×2.05		75	5.73	70		0.3447	0.3553	87.8			135/125
					75	5.73	80	>0	0.3447	0.3553	82.7			135/125
					75	5.73	70		0.4338	0.4030	85.2			135/125
					75	5.73	80	>0	0.4338	0.4030	76.6			135/125
NF2W385AR-V2			4×3.6×2.05		200	6.45	70		0.3447	0.3553	205			115/130
					200	6.45	80	>0	0.3447	0.3553	193			115/130
					200	6.45	90	50	0.3447	0.3553	168			115/130
					200	6.45	70		0.4338	0.4030	199			115/130
					200	6.45	80	>0	0.4338	0.4030	181			115/130
					200	6.45	90	50	0.4338	0.4030	153			115/130
NF3W585AR			4×3.6×2.05		50	8.44	70		0.3447	0.3553	87.5			135/135
					50	8.44	80	>0	0.3447	0.3553	82.4			135/135
					50	8.44	70		0.4338	0.4030	83.9			135/135
					50	8.44	80	>0	0.4338	0.4030	76.3			135/135
NTCWS024B-V3 (Optisolis)			15×12×2		135	34.9	95	80	0.4338	0.4030	515			120
NTCWS024B-V3 (Rs020)			15×12×2		135	34.9			0.3360	0.3335	450			120
NTCWS024B-V3 (Rs020)			15×12×2		135	34.9			0.3882	0.3329	370			120
NTCWS024B-V3 (Rs030)			15×12×2		135	34.9			0.3447	0.3553	520			120
NTCWS024B-V3 (Rs030)			15×12×2		135	34.9			0.4338	0.4030	430			120
NTCWS024B-V3 (Rs075)			15×12×2		135	34.9	90		0.4286	0.3919	655			120
NFCWS024B-V3 (Optisolis)			15×12×2		120	35.8	94	70	0.3447	0.3553	455			120
NFCWL036B-V3			19×16×2		260	34.6	70		0.3447	0.3553	1690			120
					260	34.6	80	>0	0.3447	0.3553	1590			120
					260	34.6	90	50	0.3447	0.3553	1400			120
					260	34.6	95	80	0.3447	0.3553	1210			120
					260	34.6	70		0.4338	0.4030	1640			120
					260	34.6	80	>0	0.4338	0.4030	1510			120
					260	34.6	90	50	0.4338	0.4030	1300			120
					260	34.6	95	80	0.4338	0.4030	1110			120
NFCWL036B-V3 (Optisolis, White)			19×16×2		180	35.8	94	70	0.3447	0.3553	710			120
NFCWL036B-V3 (Optisolis, Warm White)			19×16×2		260	34.6	95	80	0.4338	0.4030	1030			120
NFCWL036B-V3 (Rs020)			19×16×2		260	34.6			0.3360	0.3335	900			120
NFCWL036B-V3 (Rs020)			19×16×2		260	34.6			0.3882	0.3329	740			120
NFCWL036B-V3 (Rs030)			19×16×2		260	34.6			0.3447	0.3553	1030			120
NFCWL036B-V3 (Rs030)			19×16×2		260	34.6			0.4338	0.4030	850			120
NFCWL036B-V3 (Rs075)			19×16×2		260	34.6	90		0.4286	0.3919	1300			120
NFCWL060B-V3			19×16×2		460	34.8	70		0.3447	0.3553	3000			120
					460	34.8	80	>0	0.3447	0.3553	2830			120
					460	34.8	90	50	0.3447	0.3553	2490			120
					460	34.8	95	80	0.3447	0.3553	2160			120
					460	34.8	70		0.4338	0.4030	2920			120
					460	34.8	80	>0	0.4338	0.4030	2680			120
					460	34.8	90	50	0.4338	0.4030	2310			120
					460	34.8	95	80	0.4338	0.4030	1980			120
NFCWL060B-V3 (Optisolis, White)			19×16×2		300	35.8	94	70	0.3447	0.3553	1200			120
NFCWL060B-V3 (Optisolis, Warm White)			19×16×2		460	34.8	95	80						120
NFCWL060B-V3 (Rs020)			19×16×2		460	34.8			0.3360	0.3335	1600			120
NFCWL060B-V3 (Rs020)			19×16×2		460	34.8			0.3882	0.3329	1320			120
NFCWL060B-V3 (Rs030)			19×16×2		460	34.8			0.3447	0.3553	1840			120
NFCWL060B-V3 (Rs030)			19×16×2		460	34.8			0.4338	0.4030	1530			120
NFCWL060B-V3 (Rs075)			19×16×2		460	34.8	90		0.4286	0.3919	2320			120
NFCWJ108B-V3			24×19×2		860	34.9	70		0.3447	0.3553	5560			120
					860	34.9	80	>0	0.3447	0.3553	5230			120
					860	34.9	90	50	0.3447	0.3553	4600			120
					860	34.9	95	80	0.3447	0.3553	3990			120
					860	34.9	70		0.4338	0.4030	5390			120
					860	34.9	80	>0	0.4338	0.4030	4960			120
					860	34.9	90	50	0.4338	0.4030	4270			120
					860	34.9	95	80	0.4338	0.4030	3660			120
NFCWJ108B-V3 (Optisolis, White)			24×19×2		540	35.8	94	70	0.3447	0.3553	2150			120
NFCWJ108B-V3 (Optisolis, Warm White)			24×19×2		860	34.9	95	80	0.4338	0.4030	3380			120
NFCWJ108B-V3 (Rs020)			24×19×2		860	34.9			0.3360	0.3335	2960			120
NFCWJ108B-V3 (Rs020)			24×19×2		860	34.9			0.3882	0.3329	2440			120
NFCWJ108B-V3 (Rs030)			24×19×2		860	34.9			0.3447	0.3553	3410			120
NFCWJ108B-V3 (Rs030)			24×19×2		860	34.9			0.4338	0.4030	2820			120
NFCWJ108B-V3 (Rs075)			24×19×2		860	34.9	90		0.4286	0.3919	4290			120
NFDWJ130B-V3			24×19×2		1150	38.5	70		0.3447	0.3553	7890			120
					1150	38.5	80	>0	0.3447	0.3553	7430			120
					1150	38.5	90	50	0.3447	0.3553	6540			120
					1150	38.5	95	80	0.3447	0.3553	5660			120
					1150	38.5	70		0.4338	0.4030	7660			120
					1150	38.5	80	>0	0.4338	0.4030	7050			120
					1150	38.5	90	50	0.4338	0.4030	6070			120
					1150	38.5	95	80	0.4338	0.4030	5200			120
NFDWJ130B-V3 (Optisolis, White)			24×19×2		600	37.4	94	70	0.3447	0.3553	2560			120
NFDWJ130B-V3 (Optisolis, Warm White)			24×19×2		1150	38.5	95	80	0.4338	0.4030	4810			120
NFDWJ130B-V3 (Rs020)			24×19×2		1150	38.5			0.3360	0.3335	4200			120
NFDWJ130B-V3 (Rs020)			24×19×2		1150	38.5			0.3882	0.3329	3470			120
NFDWJ130B-V3 (Rs030)			24×19×2		1150	38.5			0.3447	0.3553	4850			120
NFDWJ130B-V3 (Rs030)			24×19×2		1150	38.5			0.4338	0.4030	4010			120
NFDWJ130B-V3 (Rs075)			24×19×2		1150	38.5	90		0.4286	0.3919	6090			120
NFCWT012B-V4H6 (H6 Series)			15×12×2		70	34.1	90	50	0.3450	0.3602	440			120
NFCWT012B-V4H6 (H6 Series)			15×12×2		70	34.1	90	50	0.4289	0.4026	430			120
NFCWS024B-V4H6 (H6 Series)			15×12×2		135	34.0	90	50	0.3450	0.3602	830			120
NFCWS024B-V4H6 (H6 Series)			15×12×2		135	34.0	90	50	0.4289	0.4026	800			120
NFCWS024B-V5			15×12×2		135	33.6	70		0.3447	0.3553	910			120
					135	33.6	80	>0	0.3447	0.3553	860			120
					135	33.6	90	50	0.3447	0.3553	770			120
					135	33.6	95	80	0.3447	0.3553	650			120
					135	33.6	70		0.4338	0.4030	880			120
					135	33.6	80	>0	0.4338	0.4030	810			120
					135	33.6	90	50	0.4338	0.4030	730			120
					135	33.6	95	80	0.4338	0.4030	600			120
NFCWS024B-V5 (Rs020)			15×12×2		135	33.6			0.3360	0.3335	460			120
NFCWS024B-V5 (Rs020)			15×12×2		135	33.6			0.3882	0.3329	380			120
NFCWS024B-V5 (Rs030)			15×12×2		135	33.6			0.3447	0.3553	550			120
NFCWS024B-V5 (Rs030)			15×12×2		135	33.6			0.4338	0.4030	460			120
NFCWS024B-V5 (Rs060)			15×12×2		135	33.6			0.336	0.301	330			120
NFCWS024B-V5 (Rs060) Hortisolis			15×12×2		135	33.6			0.336	0.301				120
NFCWS024B-V5 (Rs075)			15×12×2		135	33.6	90		0.4286	0.3919	690			120
NTCWS024B-V4			15×12×2		135	34.9	70		0.3447	0.3553	860			120
					135	34.9	80	>0	0.3447	0.3553	815			120
					135	34.9	90	50	0.3447	0.3553	720			120
					135	34.9	95	80	0.3447	0.3553	615			120
					135	34.9	70		0.4338	0.4030	830			120
					135	34.9	80	>0	0.4338	0.4030	770			120
					135	34.9	90	50	0.4338	0.4030	675			120
					135	34.9	95	80	0.4338	0.4030	560			120
NFCWL036B-V4H6 (H6 Series)			19×16×2		260	34.6	90	50	0.3450	0.3602	1620			120
NFCWL036B-V4H6 (H6 Series)			19×16×2		260	34.6	90	50	0.4289	0.4026	1570			120
NFCWL036B-V5			19×16×2		260	34.4	70		0.3447	0.3553	1750			120
					260	34.4	80	>0	0.3447	0.3553	1660			120
					260	34.4	90	50	0.3447	0.3553	1500			120
					260	34.4	95	80	0.3447	0.3553	1270			120
					260	34.4	70		0.4338	0.4030	1690			120
					260	34.4	80	>0	0.4338	0.4030	1570			120
					260	34.4	90	50	0.4338	0.4030	1400			120
					260	34.4	95	80	0.4338	0.4030	1160			120
NFCWL036B-V5 (Rs020)			19×16×2		260	34.4			0.3360	0.3335	900			120
NFCWL036B-V5 (Rs020)			19×16×2		260	34.4			0.3882	0.3329	740			120
NFCWL036B-V5 (Rs030)			19×16×2		260	34.4			0.3447	0.3553	1050			120
NFCWL036B-V5 (Rs030)			19×16×2		260	34.4			0.4338	0.4030	890			120
NFCWL036B-V5 (Rs060)			19×16×2		260	34.4			0.336	0.301	650			120
NFCWL036B-V5 (Rs060) Hortisolis			19×16×2		260	34.4			0.336	0.301				120
NFCWL036B-V5 (Rs075)			19×16×2		260	34.4	90		0.4286	0.3919	1330			120
NFCWL036B-V4			19×16×2		260	34.6	70		0.3447	0.3553	1700			120
					260	34.6	80	>0	0.3447	0.3553	1610			120
					260	34.6	90	50	0.3447	0.3553	1430			120
					260	34.6	95	80	0.3447	0.3553	1210			120
					260	34.6	70		0.4338	0.4030	1640			120
					260	34.6	80	>0	0.4338	0.4030	1520			120
					260	34.6	90	50	0.4338	0.4030	1340			120
					260	34.6	95	80	0.4338	0.4030	1110			120
NFCWL048B-V4H6 (H6 Series)			19×16×2		360	34.7	90	50	0.3450	0.3602	2260			120
NFCWL048B-V4H6 (H6 Series)			19×16×2		360	34.7	90	50	0.4289	0.4026	2190			120
NFCWL060B-V4H6 (H6 Series)			19×16×2		460	34.8	90	50	0.3450	0.3602	2870			120
NFCWL060B-V4H6 (H6 Series)			19×16×2		460	34.8	90	50	0.4289	0.4026	2780			120
NFCWL060B-V5			19×16×2		460	34.5	70		0.3447	0.3553	3120			120
					460	34.5	80	>0	0.3447	0.3553	2930			120
					460	34.5	90	50	0.3447	0.3553	2640			120
					460	34.5	95	80	0.3447	0.3553	2260			120
					460	34.5	70		0.4338	0.4030	3010			120
					460	34.5	80	>0	0.4338	0.4030	2780			120
					460	34.5	90	50	0.4338	0.4030	2480			120
					460	34.5	95	80	0.4338	0.4030	2070			120
NFCWL060B-V5 (Rs020)			19×16×2		460	34.5			0.3360	0.3335	1600			120
NFCWL060B-V5 (Rs020)			19×16×2		460	34.5			0.3882	0.3329	1320			120
NFCWL060B-V5 (Rs030)			19×16×2		460	34.5			0.3447	0.3553	1870			120
NFCWL060B-V5 (Rs030)			19×16×2		460	34.5			0.4338	0.4030	1580			120
NFCWL060B-V5 (Rs060)			19×16×2		460	34.5			0.336	0.301	1150			120
NFCWL060B-V5 (Rs060) Hortisolis			19×16×2		460	34.5			0.336	0.301				120
NFCWL060B-V5 (Rs075)			19×16×2		460	34.5	90		0.4286	0.3919	2350			120
NFCWL060B-V4			19×16×2		460	34.8	70		0.3447	0.3553	3020			120
					460	34.8	80	>0	0.3447	0.3553	2840			120
					460	34.8	90	50	0.3447	0.3553	2520			120
					460	34.8	95	80	0.3447	0.3553	2160			120
					460	34.8	70		0.4338	0.4030	2920			120
					460	34.8	80	>0	0.4338	0.4030	2690			120
					460	34.8	90	50	0.4338	0.4030	2370			120
					460	34.8	95	80	0.4338	0.4030	1980			120
NFCWJ108B-V4H6 (H6 Series)			24×19×2		860	34.9	90	50	0.3450	0.3602	5330			120
NFCWJ108B-V4H6 (H6 Series)			24×19×2		860	34.9	90	50	0.4289	0.4026	5170			120
NFCWJ108B-V5			24×19×2		860	34.6	70		0.3447	0.3553	5740			120
					860	34.6	80	>0	0.3447	0.3553	5420			120
					860	34.6	90	50	0.3447	0.3553	4890			120
					860	34.6	95	80	0.3447	0.3553	4180			120
					860	34.6	70		0.4338	0.4030	5570			120
					860	34.6	80	>0	0.4338	0.4030	5120			120
					860	34.6	90	50	0.4338	0.4030	4580			120
					860	34.6	95	80	0.4338	0.4030	3840			120
NFCWJ108B-V5 (Rs020)			24×19×2		860	34.6			0.3360	0.3335	2960			120
NFCWJ108B-V5 (Rs020)			24×19×2		860	34.6			0.3882	0.3329	2440			120
NFCWJ108B-V5 (Rs030)			24×19×2		860	34.6			0.3447	0.3553	3450			120
NFCWJ108B-V5 (Rs030)			24×19×2		860	34.6			0.4338	0.4030	2910			120
NFCWJ108B-V5 (Rs060)			24×19×2		860	34.6			0.336	0.301	2120			120
NFCWJ108B-V5 (Rs060) Hortisolis			24×19×2		860	34.6			0.336	0.301				120
NFCWJ108B-V5 (Rs075)			24×19×2		860	34.6	90		0.4286	0.3919	4340			120
NFCWJ108B-V4			24×19×2		860	34.9	70		0.3447	0.3553	5560			120
					860	34.9	80	>0	0.3447	0.3553	5250			120
					860	34.9	90	50	0.3447	0.3553	4660			120
					860	34.9	95	80	0.3447	0.3553	3990			120
					860	34.9	70		0.4338	0.4030	5390			120
					860	34.9	80	>0	0.4338	0.4030	4960			120
					860	34.9	90	50	0.4338	0.4030	4370			120
					860	34.9	95	80	0.4338	0.4030	3660			120
NFDWJ130B-V4H6 (H6 Series)			24×19×2		1150	38.5	90	50	0.3450	0.3602	7400			120
NFDWJ130B-V4H6 (H6 Series)			24×19×2		1150	38.5	90	50	0.4289	0.4026	7180			120
NFDWJ130B-V5			24×19×2		1150	38.3	70		0.3447	0.3553	8150			120
					1150	38.3	80	>0	0.3447	0.3553	7710			120
					1150	38.3	90	50	0.3447	0.3553	6950			120
					1150	38.3	95	80	0.3447	0.3553	5940			120
					1150	38.3	70		0.4338	0.4030	7920			120
					1150	38.3	80	>0	0.4338	0.4030	7280			120
					1150	38.3	90	50	0.4338	0.4030	6520			120
					1150	38.3	95	80	0.4338	0.4030	5460			120
NFDWJ130B-V5 (Rs020)			24×19×2		1150	38.3			0.3360	0.3335	4200			120
NFDWJ130B-V5 (Rs020)			24×19×2		1150	38.3			0.3882	0.3329	3470			120
NFDWJ130B-V5 (Rs030)			24×19×2		1150	38.3			0.3447	0.3553	4910			120
NFDWJ130B-V5 (Rs030)			24×19×2		1150	38.3			0.4338	0.4030	4140			120
NFDWJ130B-V5 (Rs060)			24×19×2		1150	38.3			0.336	0.301	3020			120
NFDWJ130B-V5 (Rs060) Hortisolis			24×19×2		1150	38.3			0.336	0.301				120
NFDWJ130B-V5 (Rs075)			24×19×2		1150	38.3	90		0.4286	0.3919	6170			120
NFDWJ130B-V4			24×19×2		1150	38.5	70		0.3447	0.3553	7890			120
					1150	38.5	80	>0	0.3447	0.3553	7460			120
					1150	38.5	90	50	0.3447	0.3553	6620			120
					1150	38.5	95	80	0.3447	0.3553	5660			120
					1150	38.5	70		0.4338	0.4030	7660			120
					1150	38.5	80	>0	0.4338	0.4030	7050			120
					1150	38.5	90	50	0.4338	0.4030	6210			120
					1150	38.5	95	80	0.4338	0.4030	5200			120
NFEWH306B-V2			38×38×2		1400	51.9	70		0.3447	0.3553	13120			120
					1400	51.9	80	>0	0.3447	0.3553	12300			120
					1400	51.9	90	50	0.3447	0.3553	11040			120
					1400	51.9	95		0.3447	0.3553	9430			120
					1400	51.9	70		0.4338	0.4030	12500			120
					1400	51.9	80	>0	0.4338	0.4030	11640			120
					1400	51.9	90	50	0.4338	0.4030	10240			120
					1400	51.9	95		0.4338	0.4030	8320			120
NFEWH306B-V2 (Rs020)			38×38×2		1400	51.9			0.3360	0.3335	6960			120
NFEWH306B-V2 (Rs020)			38×38×2		1400	51.9			0.3882	0.3329	5740			120
NFEWH306B-V2 (Rs030)			38×38×2		1400	51.9			0.3447	0.3553	8030			120
NFEWH306B-V2 (Rs030)			38×38×2		1400	51.9			0.4338	0.4030	6640			120
NFEWH306B-V2 (Rs075)			38×38×2		1400	51.9	90		0.4286	0.3919	10090			120
NJNWS012Z-V1MT (Tunable White)			15×12×2		280	17.9	90	50	0.3447	0.3553	630			120
NJNWS012Z-V1MT (Tunable White)			15×12×2		280	17.9	90	50	0.4540	0.4000	460			120
NVCWJ024Z-V1MT (Tunable White)			24×19×2		600	35.4	90	50	0.3447	0.3553	2730			120
NVCWJ024Z-V1MT (Tunable White)			24×19×2		600	35.4	90	50	0.4540	0.4000	2080			120
NJCWL024Z-V1MT (Tunable White)			19×16×2		250	35.8	90	50	0.3447	0.3553	1120			120
NJCWL024Z-V1MT (Tunable White)			19×16×2		250	35.8	90	50	0.4540	0.4000	850			120
NVNWS007Z-V1			15×12×2		580	20.6	70		0.3447	0.3553	1870			120
					580	20.6	80	>0	0.3447	0.3553	1750			120
					580	20.6	90	50	0.3447	0.3553	1580			120
					580	20.6	95	80	0.3447	0.3553	1400			120
					580	20.6	70		0.4338	0.4030	1740			120
					580	20.6	80	>0	0.4338	0.4030	1610			120
					580	20.6	90	50	0.4338	0.4030	1410			120
					580	20.6	95	80	0.4338	0.4030	1240			120
NVNWS007Z-V1 (Rs020)			15×12×2		580	20.6			0.3360	0.3335	930			120
NVNWS007Z-V1 (Rs020)			15×12×2		580	20.6			0.3882	0.3329	750			120
NVNWS007Z-V1 (Rs030)			15×12×2		580	20.6			0.3447	0.3553	1080			120
NVNWS007Z-V1 (Rs030)			15×12×2		580	20.6			0.4338	0.4030	860			120
NVNWS007Z-V1 (Rs075)			15×12×2		580	20.6	90		0.4286	0.3919	1470			120
NJCWS024Z-V1			15×12×2		500	36.0	70		0.3447	0.3553	2580			120
					500	36.0	80	>0	0.3447	0.3553	2410			120
					500	36.0	90	50	0.3447	0.3553	2180			120
					500	36.0	95	80	0.3447	0.3553	1930			120
					500	36.0	70		0.4338	0.4030	2410			120
					500	36.0	80	>0	0.4338	0.4030	2210			120
					500	36.0	90	50	0.4338	0.4030	1940			120
					500	36.0	95	80	0.4338	0.4030	1710			120
NJCWS024Z-V1 (Rs020)			15×12×2		500	36.0			0.3360	0.3335	1290			120
NJCWS024Z-V1 (Rs020)			15×12×2		500	36.0			0.3882	0.3329	1030			120
NJCWS024Z-V1 (Rs030)			15×12×2		500	36.0			0.3447	0.3553	1480			120
NJCWS024Z-V1 (Rs030)			15×12×2		500	36.0			0.4338	0.4030	1190			120
NJCWS024Z-V1 (Rs075)			15×12×2		500	36.0	90		0.4286	0.3919	2030			120
NVEWL016Z-V1			19×16×2		600	47.0	70		0.3447	0.3553	4370			120
					600	47.0	80	>0	0.3447	0.3553	4080			120
					600	47.0	90	50	0.3447	0.3553	3700			120
					600	47.0	95	80	0.3447	0.3553	3260			120
					600	47.0	70		0.4338	0.4030	4080			120
					600	47.0	80	>0	0.4338	0.4030	3750			120
					600	47.0	90	50	0.4338	0.4030	3290			120
					600	47.0	95	80	0.4338	0.4030	2900			120
NVEWL016Z-V1 (Rs020)			19×16×2		600	47.0			0.3360	0.3335	2180			120
NVEWL016Z-V1 (Rs020)			19×16×2		600	47.0			0.3882	0.3329	1750			120
NVEWL016Z-V1 (Rs030)			19×16×2		600	47.0			0.3447	0.3553	2520			120
NVEWL016Z-V1 (Rs030)			19×16×2		600	47.0			0.4338	0.4030	2020			120
NVEWL016Z-V1 (Rs075)			19×16×2		600	47.0	90		0.4286	0.3919	3430			120
NVCWL024Z-V1			19×16×2		1200	35.5	70		0.3447	0.3553	6660			120
					1200	35.5	80	>0	0.3447	0.3553	6220			120
					1200	35.5	90	50	0.3447	0.3553	5620			120
					1200	35.5	95	80	0.3447	0.3553	4980			120
					1200	35.5	70		0.4338	0.4030	6210			120
					1200	35.5	80	>0	0.4338	0.4030	5720			120
					1200	35.5	90	50	0.4338	0.4030	5010			120
					1200	35.5	95	80	0.4338	0.4030	4420			120
NVCWL024Z-V1 (Rs020)			19×16×2		1200	35.5			0.3360	0.3335	3330			120
NVCWL024Z-V1 (Rs020)			19×16×2		1200	35.5			0.3882	0.3329	2680			120
NVCWL024Z-V1 (Rs030)			19×16×2		1200	35.5			0.3447	0.3553	3840			120
NVCWL024Z-V1 (Rs030)			19×16×2		1200	35.5			0.4338	0.4030	3080			120
NVCWL024Z-V1 (Rs075)			19×16×2		1200	35.5	90		0.4286	0.3919	5240			120
NVEWJ048Z-V1			24×19×2		1800	47.0	70		0.3447	0.3553	13120			120
					1800	47.0	80	>0	0.3447	0.3553	12250			120
					1800	47.0	90	50	0.3447	0.3553	11090			120
					1800	47.0	95	80	0.3447	0.3553	9810			120
					1800	47.0	70		0.4338	0.4030	12230			120
					1800	47.0	80	>0	0.4338	0.4030	11280			120
					1800	47.0	90	50	0.4338	0.4030	9870			120
					1800	47.0	95	80	0.4338	0.4030	8720			120
NVEWJ048Z-V1 (Rs020)			24×19×2		1800	47.0			0.3360	0.3335	6570			120
NVEWJ048Z-V1 (Rs020)			24×19×2		1800	47.0			0.3882	0.3329	5270			120
NVEWJ048Z-V1 (Rs030)			24×19×2		1800	47.0			0.3447	0.3553	7560			120
NVEWJ048Z-V1 (Rs030)			24×19×2		1800	47.0			0.4338	0.4030	6070			120
NVEWJ048Z-V1 (Rs075)			24×19×2		1800	47.0	90		0.4286	0.3919	10330			120
NE2B757G			3×3×0.65		100	2.9			0.133	0.075	8.7			120
NF2E757GR			3×3×0.65		150	6.96			0.095	0.565	83			120
NE2G757G			3×3×0.65		100	3.5			0.17	0.70	33			120
NFSY757G			3×3×0.65		65	2.88			0.4987	0.4946	30.2			120
NE2R757G-P6			3×3×0.65		100	2.13			0.695	0.305	16			120
