LD

提供从紫外到红色的波长的多种产品系列
以工业为首，广泛适用于民用、车载等多个领域

多芯片面发射封装

OctoLas™ / QuaLas™

准直化面发光
集成多个LD芯片
兼顾小型化与高功率输出

LEARN MORE

侧引脚封装

Side Lead Package

单光束高功率、高亮度输出
支持大电流驱动
高散热封装结构

LEARN MORE

GigaWhite™

超高亮度白色LD光源
色彩均匀、发光一致性优异
提升灯具设计自由度

LEARN MORE

光纤耦合激光二极管单元

Fiber-Coupled Laser Diode

数百瓦级高输出功率
可耦合至小芯径光纤
配备水冷散热器

LEARN MORE

Automotive RGB Laser Diode

高可靠性・高光输出
随心设计炫彩行车
车载用激光二极管

LEARN MORE

投影

多种光输出、波长和封装的LD系列
满足从大型活动到便携式设备的各种投影需求

LEARN MORE

工业

波长覆盖从紫外到蓝光、绿光、红光、且具备高光功率的LD系列产品
为医疗和工业设备提供所需的高精度和高输出量

LEARN MORE

照明

采用高辉度和高光通量LD，实现灯具的小型化、轻量化和低功耗

LEARN MORE

光学拾取

专为高密度光数据存储而设计的蓝光LD
凭借丰富的量产经验，确保了高光束质量和卓越的可靠性

LEARN MORE

车载

专用于车头灯的高辉度白光LD，以及实现多彩车载投影的RGB LD
符合AEC-Q102标准

LEARN MORE

工业

投影

车载

照明

光学拾取

NICHIA 激光二极管（LD）的特点

波长范围广

NICHIA激光二极管（LD）具有广泛的发射波长，涵盖从紫外领域到可见光（蓝光、绿光、红光）。激光二极管可以应用于民用产品(如投影仪)、工业产品(如曝光机、内窥镜、激光加工等)、以及车载产品(如汽车头灯和车载投影仪等)，在多种领域中都大放异彩，未来还将会有更多的应用场景得到拓展。凭借卓越的性能以及高可靠性，NICHIA 技术在全球范围内享有盛誉。

世界领先的激光二极管

NICHIA 激光二极管具备世界领先的品质以及光功率性能。凭借稳定的震荡特性和卓越的耐久性，即使在工业、医疗、汽车等高负荷的应用环境中，也能确保高度可靠性。目前，我们的激光器也在为各个领域探索新的应用，例如使用我们全球最亮、最高效的蓝色激光器，可以实现铜材料的高速焊接。

小型封装技术

NICHIA 专注于封装技术的开发，致力于实现产品的微型化、高集成度以及低成本化。由此加速了投影、照明、工业、汽车、医疗等广泛应用的发展，并推动了新技术的实现。此外，NICHIA 还在积极探索独有的创新方向，例如尝试将激光二极管封装技术应用于紫外 LED。

通过一体化生产实现高品质 RGB 激光器

NICHIA 构建了独特的一体化生产体系，可在公司内部完成三原色（红、绿、蓝，RGB）半导体激光器芯片的集成制造。借助先进的激光设备与加工验证设备，NICHIA 能够灵活且精确地满足客户多样化需求，并提供在 QCD（质量、成本、交付）方面表现卓越的产品。
【QuaLas™ RGB】激光产品将多个RGB LD 芯片高密度集成于紧凑封装中，被广泛应用于投影设备，为实现投影仪的小型化、高画质及高亮度做出重要贡献。

LED 与 LD 的区别：光输出的指向性、聚光性、单色性及线性度

LED 的光扩散面积较大，而激光二极管（LD）具有发光角度窄和发射面积小的特性，因此是理想的集光元器件。LD的光密度能达到LED的100~1000倍以上，此外，激光二极管的光谱宽度更窄，单色性更佳，因而具备出色的色彩再现能力。与发光二极管相比，LD 还具有优异的光输出线性，可在更宽的电流范围内保持稳定的高输出。

环保的新一代光源

激光二极管（LD）作为汞灯的替代光源，已广泛应用于曝光、投影等各个领域。通过用LD代替汞灯，不仅解决了废弃水银时会带来环境污染的问题，并因其低能耗的特性大幅减少了电能消耗及二氧化碳的排放。此外，超高压汞灯的寿命通常为 3,000 至 6,000 小时，而 LD 的寿命可达约 20,000 小时，大幅降低更换与维护频率，从而减少使用成本与资源浪费。

LEARN MORE
